1.2 Side Panel

Please refer to the following interface for side panel dimension information. The unit is mm. See
Figure 1-2.

1.3 Front Panel

Please refer to the following interface for the front panel information. The unit is mm. See Figure
1-3.
GND
Figure 1-2
Please make sure the
device is securely
earthed to prevent the
thunderstorm strike.
5
