Table of Contents GENERAL INTRODUCTION ................1 Overview ..............................1 Features ..............................1 Dimensions ............................. 1 HOUSING INSTALLATION INSTRUCTION GUIDE ........... 3 Lock/Unlock Housing ..........................3 Camera Installation ..........................3 Cable Connection ..........................4 BRACKET INSTALLATION GUIDE ..............6 General Bracket Installation ......................... 6 Special Bracket Installation (Compact design, concealed cable exit) ...........
Page 3
Welcome Thank you for purchasing our housing! Please read the following safeguards and warnings carefully before you install or use the product!
Page 4
Important Safeguards and Warnings 1.Electrical safety All installation and operation here should conform to your local electrical safety codes. We assume no liability or responsibility for all the fires or electrical shock caused by improper handling or installation. 2.Transportation security Heavy stress, violent vibration or water splash are not allowed during transportation, storage and installation.
1 General Introduction 1.1 Overview The light–duty housing (“housing”) adopts all-weather compact design. It can install camera and lens of various dimensions. It has built-in camera mounting plate. The IP66 compliance is suitable for various environments. 1.2 Features Compact design, concealed cable exit. ...
Page 6
Figure 1-2 The dimensions of PFH610N-W and PFH610N-IR-W are shown as below. The unit is mm. See Figure 1-3. Figure 1-3...
2 Housing Installation Instruction Guide 2.1 Lock/Unlock Housing You can use inner hex wrench (5.0mm) to fix or loosen the two M6 screws on both sides of the housing to lock or unlock the housing. See Figure 2-1. Figure 2-1 Important Before you lock the housing, please make sure the waterproof gasket is in the right position.
The camera lens shall be as near as to the inside of the glass (Recommended distance is 1- 3mm.) in case it affect the lens view angle. The camera bracket supports upside down installation Please refer to the following sheet for detailed information. Name Camera Screws to secure the camera bracket.
Page 9
Port Port Function 3.4± 0.1V. The voltage is 0V when the IR light is off. CAM1/CAM2 Power output port. It is the same as the voltage of the external power supplying source. AC24V/DC12V Power input port. Connect to external power sourcing. Figure 2-4...
3 Bracket Installation Guide 3.1 General Bracket Installation The housing can use the bracket of the thread hole to install. The general bracket thread hole (M6) on the housing is shown as below. See Figure 3-1. Figure 3-1 3.2 Special Bracket Installation (Compact design, concealed cable exit) Step 1: Pull the cable through the inside of the bracket.
Figure 3-3 Figure 3-4 3.3 Bracket Types You can refer to the following sheet for different bracket models if you want to use different mount modes. Installation Reference Figure Bracket Model Mode Ceiling PFB600W Mount...
Installation Reference Figure Bracket Model Mode Wall Mount 1 PFB602W Pedestal PFA160 Mount Pedestal The bracket and the housing installation PFB601W Mount position adopt symmetric design. The bracket can be installed upside-down. Pedestal PFB601W+PFA112 Mount (200mm)or PFA113 (400mm) The bracket is not a standard accessory of the housing. Please contact your local retailer for more information.
Appendix Toxic or Hazardous Materials or Elements Toxic or Hazardous Materials or Elements Component Name Cr VI PBDE ○ ○ ○ ○ ○ ○ Sheet Metal ○ ○ ○ ○ ○ ○ Plastic Parts ○ ○ ○ ○ ○ ○ Connection ○...
