- Page 1 XOMAX Users Manual XM-VRSU311BT Micro FM RADIO ENGLISH...
- Page 2 Users Manual XOMAX XM-VRSU311BT Thank you for purchasing one of our XOMAX products! We appreciate your confi- dence. Enjoy your brand new multimedia unit! Please read the following manual carefully before you install and use the unit. Please save this manual in case you will need to clarify further possible ques- tions regarding installation and usage of our product.
-
Page 3: Table Of Contents
AMS Automatic frequency scan ..24 Usage of the remote control ....17 Switch the frequency bands ....24 Replacement of the battery .....17 LOC signal sensitivity .....24 Unit on/off ........18 RDS functions .......24 XOMAX X M - V R S U 3 1 1 B T... - Page 4 Disposal of an old unit ....36 GOTO function ......28 Disposal of the battery ....36 Switch the subtitles .......29 OSD inforamtion ......29 Picture viewer Picture viewer interface ....30 Slide show play/pause ....30 XOMAX X M - V R S U 3 1 1 B T...
-
Page 5: Safety Instructions And Precautions
Do not use the unit any further since you detect any kind of technical problems. Leave all the repair opera- XOMAX X M - V R S U 3 1 1 B T... - Page 6 To avoid the danger of fire or the electric shock do not put the unit in to the moist environment (e.g. adverse weather conditions, inappropriate wet cleaning etc.) XOMAX X M - V R S U 3 1 1 B T...
-
Page 7: Introduction
USB flash drive or SD-/ SDHC-/SDXC-cards. S/N ratio ........... 85 dB Stereo channel separation ....80 dB The XOMAX XM-VRSU311BT has a micro SD card slot, a regular USB plug and a Display regular audio input plug. -
Page 8: Package Content
The images serve as example. Optically the may vary from the original. remote control with battery fixation metall sheet installation manual ISO port adapter cable 1DIN installation frame (on unit) extraction key faceplate (on unit) XOMAX X M - V R S U 3 1 1 B T... -
Page 9: Operating Elements
4/RDM AF, TA, REG, EON, PTY). Within the selected Random/stored radio stations option rotate the button to maximaze/minimize [Playback] random playback corresponding factor. [Radio] Stored station "4" XOMAX X M - V R S U 3 1 1 B T... - Page 10 FAT32- or [Telephone] to accept/start a call. exFat- file system. Maximal supported volume: 32 GB. USB USB plug The USB plug is added for reading of USB flash XOMAX X M - V R S U 3 1 1 B T...
-
Page 11: Remote Control
[Playback] Repeat for the entry of a decimal ST/PRG track number for an immediately [Radio] Stereo on/off access [Playback] to program a playlist XOMAX X M - V R S U 3 1 1 B T... -
Page 12: Installation
The detailed installation manual » The connection cables may not be cutted you can find on our homepage www. or short-circuited. Otherwise the warranty xomax.de. becomes invalid. The printed version of a common » Before the installation please make installation manual you can find in sure that your vehicle has the 12 Volt the package. - Page 13 » To avoid a rogue and hazardous short circuit do not lay the yellow cable XOMAX X M - V R S U 3 1 1 B T...
-
Page 14: Connection Schedule - Cinch
Connection schedule – cinch rear view camera (optional) e.g. headrest- or ceiling display external display (optional) rear left e.g. front left front right (optional) rear right loud speakers XOMAX X M - V R S U 3 1 1 B T... -
Page 15: Connection Schedule - Iso Plug / Socket
Topic: Connection schedule – ISO plug / socket Connection schedule – ISO plug / socket rear left front left front right rear right XOMAX X M - V R S U 3 1 1 B T... -
Page 16: Iso Plug / Socket Pin Assignment
If these problems appear the connec- nments a simple plug'n'play connection tions A4 and A7 should be interchanged. may lead to grievous errors. XOMAX X M - V R S U 3 1 1 B T... -
Page 17: Startup Operations
3. Insert the battery compartment As soon as the remote control does back into the remote control till it not work proper the battery should be clicks into place. replaced. XOMAX X M - V R S U 3 1 1 B T... -
Page 18: Unit On/Off
FAT32 or exFat. Other types will not be supported. The playback control can be achieved via external device only. XOMAX X M - V R S U 3 1 1 B T... -
Page 19: Basic Functions
You can also use fro that the button several times to switch between follo- on the remote control. VOL- VOL+ wing settings: XOMAX X M - V R S U 3 1 1 B T... -
Page 20: Preset Equalizer
To set the backlight color press the rotary buttons on the remote control VOL+ or the button on the remote button to define the RED color intensity. Then XOMAX X M - V R S U 3 1 1 B T... -
Page 21: Osd
» further formats could possibly be playable The max. supported video resolution is 720 x 480 pixels. Audio » MP3 files (with ID3-support) » WMA audio format XOMAX X M - V R S U 3 1 1 B T... -
Page 22: Video Format - Best Practise
» frame rate: max. 30fps Case. 2 » resolution: up to 720 x 480 pixels » codec: MPEG-1/2 video » format: .MPG » audio: MPEG audio layer 1/2/3 XOMAX X M - V R S U 3 1 1 B T... -
Page 23: Radio Mode
2 seconds to switch to manual station searching mode. Now using the buttons you can search for radio stations stepwise into correspon- ding direction on the frequency scale. XOMAX X M - V R S U 3 1 1 B T... -
Page 24: Ams Automatic Frequency Scan
Now rotate the button or searching starts each time you drive use the buttons on the VOL- VOL+ through the tunnel. remote control to switch between the function ON / OFF. XOMAX X M - V R S U 3 1 1 B T... -
Page 25: Usb And Sd Mode
Only the supported formats will appear, all the other files will be hidden. Choose the file Use the arrow keys on the remote XOMAX X M - V R S U 3 1 1 B T... -
Page 26: Music Playback
Next / Previous Title Brief press the buttons for that. Fast forward / rewind Press and hold the buttons find the required passage, then release the buttons. XOMAX X M - V R S U 3 1 1 B T... -
Page 27: Id3 Tag (Song/Interpreter/Album)
This function is available only during the MP3 files playback; the tags should be stored in these files first. XOMAX X M - V R S U 3 1 1 B T... -
Page 28: Video Playback
(x2). Repeat the manipulation to upshift to the next level and so on. XOMAX X M - V R S U 3 1 1 B T... -
Page 29: Switch The Subtitles
Only the *.SRT files are supported. OSD inforamtion To view the OSD information press the button on the remote control. Press it again to hide it. XOMAX X M - V R S U 3 1 1 B T... -
Page 30: Picture Viewer
You can rotate or mirror the picture using the arrow keys on the remote control. Next / previous picture Use the buttons to skip the pictures back and forth. XOMAX X M - V R S U 3 1 1 B T... -
Page 31: Audio/Video Input
The Bluetooth function should be "ON" both on the external device and on the unit. XOMAX X M - V R S U 3 1 1 B T... -
Page 32: Hand-Free Phone Call
Use the By incoming call press the BND/� arrow keys of the remote control to button on the front panel to accept it. choose the letters A-Z. XOMAX X M - V R S U 3 1 1 B T... -
Page 33: Setup
Parameters: Bass, Treble, Balance, Fade, Loudness Video Parameters: Brightness, Contrast, Hue, Saturation, Sharpness. Time Parameters: Year, Month, Day, Hours, Minutes. Default Reset the system, back to the factory settings. XOMAX X M - V R S U 3 1 1 B T... -
Page 34: Common Solutions
Common solutions Common solutions The following advices are generally valid and refer to diverse Xomax models with the similar characteristics. Please note that some articles may refer not to your model exactly and may contain the describtion of features and functions that your model does not support. - Page 35 Thus in case of mismatch of connections due to different pin assignments a simple plug'n'play connection may lead to grievous errors. XOMAX X M - V R S U 3 1 1 B T...
-
Page 36: Recycling Information
The proper disposal of these products XOMAX in the world wide web contributes to environment protection. To find the nearest collection point XOMAX manufacturer's information: or recycling yard please consult your http://www.xomax.de...
