Specification

Lens of the thermal camera
Field of view (FOV)
Microbolometer of the thermal camera
IR resolution of the thermal camera
Geometrical resolution /IFOV
Spectral range
Thermal sensitivity
Pixel pitch
Focal Plane Array (FPA)
Image representation of the thermal camera
Modes
Display
Zoom
Digital camera
Focus
Refresh rate
Measurement with the thermal camera
Object temperature range
Accuracy
Measuring spot
Measuring area
Line profile
Hot / cold spot
Emissivity
Quantity of color palettes
Image storage of the thermal camera
Storage medium
Storage capacity
Storage format
Laser pointer of the thermal camera
Type
Power supply of the thermal camera
Battery type
Battery life
AC power supply
Power off
Manual
21 ° x 16 ° / 0,4 m
38 ° x 28 ° / 0.3 m (optional available)
11 ° x 8.5 ° / 1.2 m (optional available)
384 x 288 Pixel
1.2 mRad
8 ... 14 µm
<0.65 mK at 30 °C
25 µm
uncooled microbolometer
IR image, real-image, thermal Fusion, picture-in-
3.5 " color LCD, 270 º, rotatable
digital, 1 ... 8 x (continuously variable)
3.0 MP (permanently installed in thermal
camera)
auto / motorised
50 Hz (PAL) / 60 Hz (NTSC)
-20 ... +250 °C
±2 °C oder ±2 %
4 adjustable measuring spots
3 adjustable measuring areas (max., min., avg.)
horizontal / vertical
max., min. and avg. temperature
0.01 ... 1.0
6
SD card, attached flash memory
2 GB SD card (5000 images)
Flash (600 images)
JPEG
class II, 1 mW / 35 nm
Li-Ion rechargeable battery
more than 3 hours of continuous use
110 ... 240 V AC, 50/60 Hz, output 5 V DC
adjustable
