- Page 1 User Manual PCE-TC 30N Thermal Imaging Camera User manuals in various languages (français, italiano, español, português, nederlands, türk, polski, русский, 中文) can be found by using our product search on: www.pce-instruments.com Last change: 5 March 2021 v1.0 © PCE Instruments...
-
Page 2: Table Of Contents
Control panel ........................7 Menu ....................... 8 Image overlapping ......................8 Show saved images ......................8 Colour palettes ......................... 9 Emissivity ........................10 Settings ...........................11 Maintenance ..................15 Cleaning ..........................15 Troubleshooting .................. 15 Warranty ....................16 Disposal ....................16 © PCE Instruments... -
Page 3: Safety Notes
We expressly point to our general guarantee terms which can be found in our general terms of business. If you have any questions please contact PCE Instruments. The contact details can be found at the end of this manual. © PCE Instruments... -
Page 4: Specifications
Operation: 0 ... +45 °C Temperature Storage: -20 ... +60 °C Relative humidity < 85 % r. RH (non-condensing) Dimensions 96 x 72 x 226 mm / 3.8 x 4.1 x 8.9 in Weight 389 g / / <1 lb © PCE Instruments... -
Page 5: 2.2 Delivery Scope
2.2 Delivery scope 1 x thermal imaging camera PCE-TC 30N 1 x USB cable 1 x USB mains adaptor 1 x user manual 1 x carrying bag © PCE Instruments... -
Page 6: System Description
1. Display 2. control panel 3. Handle 6. Micro USB connector under protective cap 7. infrared bolometer 8. Digital camera 9. LED light 10. Save screen capture / switch LED on or off 11. Internal rechargeable battery © PCE Instruments... -
Page 7: Getting Started
3.2.1 Charging the battery The PCE-TC 30N thermal imaging camera has a built-in rechargeable Li-Ion battery. If the battery level is low, this is indicated by the symbol at the top right of the screen. Charge the thermal imaging camera via the micro USB interface. -
Page 8: Display Description
Minimum temperature in the current image section The green mark appears where the lowest temperature is measured in the current image section. At the same time, this is shown in the lower left area of the display. © PCE Instruments... -
Page 9: Control Panel
To do this, press the upper navigation key in normal measuring mode. In addition to the minimum or maximum measured temperature, the current time is also shown or hidden in the lower right corner of the display. © PCE Instruments... -
Page 10: Menu
Navigation key left or right: view previous or next image • Navigation key to: delete current image; confirm dialogue window with menu key; cancel with select/enter key • Select/enter key: Exit view Navigation key left: Exit submenu Menu key: back to measuring mode © PCE Instruments... -
Page 11: Colour Palettes
The following functions are available: Navigation key up or down: scroll through the list Select/enter key: apply currently selected colour palette Navigation key left: exit submenu Menu key: back to measuring mode © PCE Instruments... -
Page 12: Emissivity
When selecting individual emissivity, the emissivity can be set between 0 ... 1 with the navigation keys up or down; the decimal place can be changed with the navigation keys left or right; to accept, press the select/enter key. © PCE Instruments... -
Page 13: Settings
German Celsius Setting the temperature unit Unit Fahrenheit 24 hours Setting the time format Time format AM/PM Year Month Setting the date and time Time setting Hour Minute Second Setting autom. spots Spot maximum or minimum temperature © PCE Instruments... - Page 14 All available settings are displayed here in a list. Navigation key up or down: scroll through the list Select/enter key: accept current selection Navigation key left: exit submenu Menu key: back to measuring mode © PCE Instruments...
- Page 15 • Navigation key up or down: change number at marked decimal place • Navigation key left or right: change decimal place • Select/enter key: save edit Navigation key left: exit submenu Menu key: back to measuring mode © PCE Instruments...
- Page 16 All available settings are displayed here in a list. Navigation key up or down: scroll through the list Select/enter key: accept current selection Navigation key left: exit submenu Menu key: back to measuring mode © PCE Instruments...
-
Page 17: Maintenance
The lens should be completely dry before the meter is used again. Do not immerse the instrument in water. Troubleshooting The following problems may occur during operation of the thermal imaging camera. If the suggested solutions are not helpful, please contact PCE Instruments. Problem Cause Solution... -
Page 18: Warranty
For countries outside the EU, batteries and devices should be disposed of in accordance with your local waste regulations. If you have any questions, please contact PCE Instruments. © PCE Instruments... - Page 19 PCE Instruments contact information Germany France Spain PCE Deutschland GmbH PCE Instruments France EURL PCE Ibérica S.L. Im Langel 4 23, rue de Strasbourg Calle Mayor, 53 D-59872 Meschede 67250 Soultz-Sous-Forets 02500 Tobarra (Albacete) Deutschland France España Tel.: +49 (0) 2903 976 99 0 Téléphone: +33 (0) 972 3537 17...
