FRoNT Wheel

Simply insert the front wheel into the front forks, with the brake disk lined up to fit into
the brake calipers. Insert the washer on both sides of the wheel such that the 'hook' part
of the wheel fits into the slot where the axle enters. Screw on nuts and tighten with 15mm
spanner.
Note: It may be easier to do this step with the bike flipped over on its seat and handlebars. Just
be careful of the display on the ground you are constructing on.
Wheel is place into the axle slot on the front forks
Washer is place on axle as shown above and the nut is fastened securely
