FolDING FRAMe

Following the following steps to folding you bike into its folded state:
1. Locate pedals and fold pedals up (Optionally remove seat for more space)
2. Locate the clamp section on the frame and check the bike if turned off
3. Undo black safety latch and open lever lock
4. Using two hands rotate open the frame
5. Continue to rotate the frame around ensuring no cables get caught in the process.
6. Lay bike onto support fram below crank set
16
Step 1: Push pedal into the crank and rotate
Step 2 and 3: Undo Safety Latch
pleASe NoTe
Ensure that the bike is turned off by pressing the controller button
beofre attempting to fold the bike.
