MO9740 Manual
Proprietary Statement
This manual contains proprietary information of Paxar UK Ltd. It is intended solely for the
information and use of parties operating and maintaining the equipment described herein. Such
proprietary information may not be used, reproduced, or disclosed to any other parties for any other
purpose without the expressed written permission of Paxar UK Ltd.
MO 9742
Product Improvements
Continuous improvement of products is a policy of Paxar UK Ltd. All specifications and signs are
subject to change without notice.
FCC Compliance Statement
NOTE:
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that the interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
■ Reorient or relocate the receiving antenna.
■ Increase the separation between the equipment and the receiver.
■ Connect the equipment into an outlet on a circuit different than that to which the receiver is
connected.
■ Consult the dealer or an experience Radio/TV technician for help
.
NOTE: This unit was tested with shielded cables on the peripheral devices. Shielded cables must be
used with the unit to insure compliance. The user is cautioned that any changes or modifications not
expressly approved by Paxar UK Ltd. could void the user's authority to operate the equipment.
Liability Disclaimer
Paxar UK Ltd takes steps to assure that its published engineering specifications and manuals are
correct; however, errors do occur. Paxar UK Ltd. reserves the right to correct any such errors and
disclaims liability resulting there from.
No Liability for Consequential Damage
In no event shall Paxar UK Ltd. or anyone else involved in the creation, production, or delivery of the
Operators Manual
accompanying product (including hardware and software) be liable for any damages whatsoever
(including, without limitation, damages for loss of business profits, business interruption, loss of
business information, or other pecuniary loss) arising out of the use of or the results of use of or
inability to use such product, even if Paxar UK Ltd. has been advised of the possibility of such
damages.
Rev 1.1
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Paxar MO 9742
Summary of Contents for Paxar MO 9742
-
Page 1: Fcc Compliance Statement
No Liability for Consequential Damage In no event shall Paxar UK Ltd. or anyone else involved in the creation, production, or delivery of the Operators Manual accompanying product (including hardware and software) be liable for any damages whatsoever... -
Page 2: Table Of Contents
A Letter to Our Customers Dear Customer, Congratulation on selecting this Paxar 9740 series printer! This manual is intended for helping you to get to know your printer and optimise its performance for your application. Basically, this booklet contains two parts: operation guidance and related valuable information. -
Page 3: Checking Your Box
Having performed the primary inspections. Please check whether you have received the following accessories together with the printer. (See page 2) If there is any item missing, please contact your local Paxar distributor. MO9740 Manual MO9740 Manual Printer Sample Media User’s Manual... -
Page 4: Power Supply
AREA WHERE THEY CAN GET WET. 1. The Power Adapter has a barrel connector at one end that must be inserted into the power jack on the back of the printer. 2. Plug the other end of the cord into an appropriate AC electrical outlet. -
Page 5: Loading The Ribbon
MO9740 Manual MO9740 Manual 4. Loading the Ribbon Note: Media Hanger This section is not applicable to the direct thermal printing. Release Levers 1. Lift the top cover to expose the media compartment. Ribbon Supply Holder Ribbon Pick-up Holder Thermal Printhead... - Page 6 Unlatch the print head module by pushing the two release buttons on the sides, down. Turn over the print head module to expose the ribbon supply holder. Media Compartment Release Lever Ribbon Supply Holder MO9740 Manual 4. Unwrap the ribbon roll pack and separate the ribbon roll and the empty cardboard core.
- Page 7 7. Turn back the print head module and then insert the empty core into the pick-up holder. (First snap in the left side, then the right side.) MO9740 Manual 8. Turn the wheel of the print head module to ensure the ribbon is tightly wound.
-
Page 8: Loading The Media
5. Loading the Media The Paxar 9742 printer can be operated in three different options: standard, peel-off, or with a cutter. - Standard mode allows you to collect each label freely. - Peel-off mode, the backing material is peeled away from the label as it is printed. - Page 9 6. Lead the label through the media guides with one hand and adjust the centre-justified guides for the appropriate supply width. MO9740 Manual 7. When supply loading is complete, press the print head module down firmly on both sides until you hear a positive click from both sides.
-
Page 10: Peel Off Mode
MO9740 Manual MO9740 Manual 8. Close the top cover and turn on the printer or press the feed Peel Off Mode button if the printer is already on. 1. Loosen the two screws on the back of the peeler cover. - Page 11 3. Plug in the dispenser connecter. 4. Mount the dispenser module. Dispenser Module MO9740 Manual 5. Secure the two screws on the back of peeler cover. 6. Lead the label through the media guides and dispenser. Dispenser Connecter MO9740 Manual Screw Media Guides Dispenser...
- Page 12 7. Press down the print head module firmly until you hear a positive click from both sides. 8. Close the top cover and turn on the printer or press the feed button if the printer is already on. MO9740 Manual 9.
-
Page 13: Cutter Mode
1. First plug cutter baby board in JP29 on the main board. 2. Loose two attached screws on the back of peeler cover. 3. Remove the peeler cover. Peeler Cover MO9740 Manual 4. Loosen the screw on the printer module. 5. Remove the dispenser bar. Screw Dispenser Bar MO9740 Manual... - Page 14 6. Plug in the cutter connecter. 7. Secure the screw of cutter module. MO9740 Manual 8. Lead the label through the media guides and the slot of cutter. 9. Press down the print head module firmly on both sides until you hear a positive click from both sides.
-
Page 15: Operator Controls
10. Close the top cover and turn on the printer or press the feed button if the printer is already on. Note: The feed button will not drive the printer to cut. The cutting function can be executed only when the software setting is ready. -
Page 16: Performing Calibration
7. Performing Calibration 1. Hold down the feed button while turning on the power, until the printing motor becomes activated. 2. The calibration has been performed while the printer automatically feed label stock for certain length. Note: This step is very important and must always be carried out whenever media is being changed. -
Page 17: Printing Configuration Report
3. While both indicators are lit again, release the feed button. 4. At this point, the printer will begin to feed the label stock for approximately 12 inches in length, and return to the factory default settings. -
Page 18: Connecting The Printer And Computer
Parallel Port the back of the printer. The other end of this signal interface cable connects to a serial port at the host computer. For technical and pin-out information, please refer to the Reference Technical Information-Interface Specification on page 55 of this booklet. -
Page 19: Contents
The required cable (IEEE 1284-compliant is recommended) must have a standard 36-pin parallel connector on one end, which is plugged into the parallel port located on the back of the printer. The other end of the parallel interface cable connects to the printer connector at the host computer. - Page 20 Installing USB Driver (Windows 98 only) Install USB driver Properties menu → Right click to get pop-up menu. Notes: Uninstall printer driver before installing USB driver. → Select "Driver". → Click “Update Driver”. MO9740 Manual → Click “Next “. → Select "Specify a location".
-
Page 21: Installing Printer Driver
“USB002” . 9. After the related files have been copied to your system, the installation is complete. 10. If you need to print from the label printer, set "Label Dr. 200"(or Label Dr.300) as the Default Printer. MO9740 Manual Notes : 1. -
Page 22: Set The Parameters
Label Dr. The parameters include: Ports Select the IO port to link with the printer. The port may be parallel (LPT), serial (COM), network port or file. Paper size Select the proper size on the menu. If there is no desired size, select "Custom"... - Page 23 MO9740 Manual Output bin (Accessory setting) Properties menu → Click "Paper". → Click "more option". → Select Enable/without cutter, peeler. → Click "OK". Print quality (Speed) Properties menu → Click "Device Options". → Select parameters. → Click "OK". Create a new size Properties menu →...
- Page 24 For Win 2000 Ports Properties menu → Click "Ports". → Select the IO port. → Click "OK". Paper source (Media type) Back to Printers menu → Right click to get pop-up menu. → Select "Printing Reference". → Click "Paper Quality" select media type.
- Page 25 MO9740 Manual Create a new size Printer menu → Right click to get pop- up menu on empty space. → Select "Server Properties". → Enter a form name for the new form in "Form description for". → Reset the paper size in the specific squares ".
- Page 26 MO9740 Manual Paper/Output (Speed) Print quality (Darkness) Default Document menu lick "Advanced". → C lick each item to → C select desired parameter. lick "OK". → C Create a new size Please refer to the procedure of create a new size on Win 2000. For Win XP Ports Properties menu...
- Page 27 → Click "Advanced" button. → Click each item to select the parameters. → Click "OK". MO9740 Manual Create a new size Printer menu → Right click to get pop-up menu in blank space. → Select "Server Properties". → Enter a form name for the new form in "Form name”.
-
Page 28: Troubleshooting
12. Troubleshooting If the printer is in an abnormal condition, the power LED will keep blinking. The printer is working but communication between the host and printer will stop. To understand the problem, please check both LEDs first: A. Power and Ready LEDs blink at the same tempo... - Page 29 LED has still not illuminated, check the fuse inside the power adapter case. The data has been sent, but there is no output from the printer. Check the active printer driver, if Label Dr. for your Windows system and the label printer has been selected.
-
Page 30: Caring For Your Printer
13. Caring for Your Printer Clean the following areas of the printer after 8 rolls of label stocks have been used. In each case, use a cotton bud dampened with alcohol. Do not soak the cotton bud excessively. Note : Always switch off the power before cleaning. -
Page 31: Technical Specifications
5. Plug the 2 print head cables into the new print head. 6. Screw the new print head onto print head module (12,13). 7. Put the new print head module back onto the printer chassis in the same way, which you released it from printer chassis. -
Page 32: Fonts, Bar Codes And Graphics Specification
Korean and Japanese) Fonts, Bar Codes and Graphics Specification The specifications of fonts, bar codes and graphics depend on the printer emulation. The emulation PPLB is a printer programming language, through which the host can communicate with your printer. Printer Programming Language B, PPLB... -
Page 33: Interface Specifications
2. Since this printer uses band buffer technology, if you just print texts or barcodes the maximum length can be more than 30 inches, whereas if you print many graphics the maximum length can only be few inches under standard onboard RAM.(The extension RAM, font board and flash... -
Page 34: Connection With Host
Printer 9P Handshaking : XON/XOFF as well as CTS/RTS (hardware flow If you run an application with the bundled printer driver under Windows and use the serial port, you should check the above parameters and set the flow control to "Xon/Xoff "or "hardware". -
Page 35: Parallel (Centronics)
PC via different port. However as no port contention is made for this printer, if both PC transmit data at the same time to this printer, the data may become damaged in the receiving buffer.
