Paxar Pathfinder TC6035AN Application Notes

Dos-based system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MONARCH
DOS-based
PATHFINDER Ultra
System
TC6035AN Rev. A 7/98
©1998 Monarch Marking Systems, Inc. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pathfinder TC6035AN and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Paxar Pathfinder TC6035AN

Summary of Contents for Paxar Pathfinder TC6035AN

  • Page 1 MONARCH DOS-based PATHFINDER Ultra System TC6035AN Rev. A 7/98 ©1998 Monarch Marking Systems, Inc. All rights reserved.
  • Page 2 Each product and program carries a respective written warranty, the only warranty on which the customer can rely. Monarch reserves the right to make changes in the product and the programs and their availability at any time and without notice. Although Monarch has made every effort to provide complete and accurate information in this manual, Monarch shall not be liable for any omissions or inaccuracies.
  • Page 4 Each product and program carries a respective written warranty, the only warranty on which the customer can rely. Monarch reserves the right to make changes in the product and the programs and their availability at any time and without notice. Although Monarch has made every effort to provide complete and accurate information in this manual, Monarch shall not be liable for any omissions or inaccuracies.

  • Page 5: Table Of Contents

    T A B L E O F C O N T E N T S Introduction ... 1-1 About this Manual ... 1-1 Related Documentation ... 1-2 Using Memory Cards ... 2-1 Configuring Memory Cards ... 2-1 Using Radio Cards ... 3-1 Configuring Radio Cards ...
  • Page 6 ii Application Notes 7/21/98...

  • Page 7: Introduction

    C/C++ 1.52 (described in the Programmer’s Manual), it can communicate with a host via a serial communications port. use international configurations for its keypad and display. The printer has one un-buffered PC-card slot. With it, the printer can use extra memory. communicate over a wireless network.

  • Page 8: Related Documentation

    R e l a t e d D o c u m e n t a t i o n The following table describes other manuals for the printer. Manual ROM-DOS User Manual Equipment Manual Programmer’s Manual MPCLII Packet Reference...

  • Page 9: Using Memory Cards

    U S I N G M E M O R Y C A R D S You can use an AT-Attachment (ATA) memory card with the appropriate device drivers to add memory to the printer. The card goes in the printer’s PC-card slot. The application treats the memory card as another disk drive.
  • Page 10 Enter the following lines in the application’s CONFIG.SYS file: DEVICE=SSELAN.EXE DEVICE=CS.EXE DEVICE=CSALLOC.EXE DEVICE=ATADRV.EXE DEVICE=CARDID.EXE Create the disk image and load it into the printer. Reboot the printer. 2-2 Application Notes 7/21/98...

  • Page 11: Using Radio Cards

    U S I N G R A D I O C A R D S You can use a radio card with the appropriate device drivers to enable a printer to run radio-frequency (RF) communications, which allow the printers to use wireless radio networks. The card goes in the printer’s PC-card slot.
  • Page 12 Enter the following lines in the application’s CONFIG.SYS file: DEVICE=SSELAN.EXE DEVICE=CS.EXE DEVICE=CSALLOC.EXE Create the application’s disk image and load it into the printer. Reboot the printer. For updated radio card files, contact the radio vendor (Proxim, Symbol, or Aironet). 3-2 Application Notes Description SystemSoft Socket Services .

  • Page 13: Serial Communications

    S E R I A L C O M M U N I C AT I O N S The printer has one RS-232 serial communications port located on the printer’s side. The port is 16450 UART-compatible and supports up to 115k baud.

  • Page 14: Using I/O Routines

    U s i n g I / O R o u t i n e s The SDK does not provide routines for reading and writing to the serial port. Application developers can write their own routines. These routines must use interrupt 14hex. use third-party products such as Greenleaf CommLib .

  • Page 15: International Configurations

    I N T E R N AT I O N A L C O N F I G U R AT I O N S To configure the printer for international use, you must configure the keypad and display. C o n f i g u r i n g t h e D i s p l a y To configure the display for international use, put a reference to the DISPLAY.SYS driver in CONFIG.SYS, specifying the appropriate code...

  • Page 16: Configuring The Keypad

    “International Keypad Maps”). Create a disk image for the application. Include KEYBOARD.SYS, AUTOEXEC.BAT, and KEYB.COM in it. Load the disk image into the printer. Reboot the printer. To switch temporarily from an international map to the default map, press a and f at the same time, then 1. To switch back, press a and f at the same time, then 2.

  • Page 17: Universal Pathfinder Map (Country Code Up)

    I n t e r n a t i o n a l K e y p a d M a p s Below are diagrams showing the characters for the international keypad maps. Each square in the diagram represents a key. The lower-left character in the square is from the default map.

  • Page 18: Turkish Map (Country Code Tr)

    Turkish Map (Country Code TR) Ü ü 5-4 Application Notes Ç ç Ö ö 7/21/98...
  • Page 19 A type of memory written to (or over) in large units. Memory Card A type of PC card that provides extra memory for the printer. Radio Card A type of PC card that enables the printer to communicate with an access point via a radio. 7/21/98 Glossary 1...
  • Page 20 2 Application Notes 7/21/98...
