- Page 1 Stenorette Sh 23 Steno-Cassette 30 ENGLISH www.grundig-gbs.com...
- Page 2 Sh 23 The product is in accordance with following EC-Directives: “89/336/CEE, 73/23/CEE, 93/68/CEE“...
- Page 3 I N D E X V O L D I C T. M I C . ßI ß? ß` ßQ ßW...
- Page 4 DIN 32 750-T steno-cassette 30 Batterien Batterijen Batteries Batterier Pile Batterierne Piles Pilas Akkuset 662 Rechargeable batteries Accumulatori 662 Accumulateurs 662 Akku´s 662 Ackumulator 662 Akkumulator 662 Baterias 662 Netzbetrieb Mains operation Funzionamento con la rete Fonctionnament sur secteur Gebruik met de adapter Nätdrift Netdrift Funcionamiento a red...
-
Page 5: Supply Voltage
Supply Voltage Battery, rechargeable battery, mains operation Battery/rechargeable battery condition indicator (plus recording indicator): Lights up when recording. Goes out when the batteries/rechargeable batteries are weak. Recording is still possible until the motor stops (sound signal). Battery operation with two 1.5V/LR 6/AA batte- ries (alkaline-manganese), leak-proof. -
Page 6: Controls And Sockets
Controls and Sockets Please open folder at beginning of booklet! Playback volume control (turn) DICT. indication Lights up during recording. Microphone Recording button Press the “ - DICTATE” button (locks in). Loudspeaker Switch-on lock red green Prevents accidental switching on. Slide-switch Fast forward (search) Stop... - Page 7 Accessories indicated in the text are not sup- plied with the unit. The features indicated by Grundig apply only when using original Grundig accessories. Defects due to the use of accessories which are not original Grundig accessories or which...
- Page 8 General Automatic switch-off If the machine remains switched on inadver- tently, the current function is continued till the end of the cassette. After emitting several sound signals, the machine switches off. To put the machine into operation again, set the slide-switch to “...
- Page 9 Recording Microphone and recording indicator Conference recordings The housing base is designed so that the dicta- tion machine can vertically be placed on a table. Dictation Speak over the dictation machine. The figure shows the optimum position of the dictation machine. The high-quality micropho- ne allows also for recordings over greater distances.
- Page 10 Recording Recording pause Set the sliding switch to “ STOP”: – “DICT.” goes out. – Recording button “ - DICTATE” remains locked in. Set sliding switch to “ START”: – “DICT.” lights up; tape runs. Text correction Switch the sliding switch to » REWIND«. –...
- Page 11 Recording Concluding recording Briefly move sliding switch to “ REWIND” (or “ FFWD”): – The “ - DICTATE” button unlocks. Set the sliding switch to “ STOP”. Recording with accessories, e.g. … – Pen-type microphone 761 (accessories). – From telephone with acoustic coupler AKS 20 (accessories).
- Page 12 Playback Playback Starting playback Set sliding switch to “ START”: – A warning signal sounds if no steno-cassette is fitted. Adjust desired volume (turn). During playback, you can mark positions requiring correction. During “ START”: briefly press the “INDEX” button at the text passage to be corrected.
- Page 13 During “ FFWD” forward wind and “ REWIND”, the unit stops for approx. 1 s at these markings. These markings are recogni- zed by every GRUNDIG dictating machine with search function. Rewind and fast forward without search function Move the sliding switch briefly to the desired function (“...
- Page 14 Fast Forward Wind/Rewind Fast forward wind with search Keep sliding switch in “ FFWD” position. At letter ends marked by the “INDEX”button, the unit stops for approx. 1 s after the marking. Release sliding switch, or, if you wish to continue fast forward winding, keep sliding switch in “...
-
Page 15: Care And Maintenance
Care and Maintenance The housing should only be cleaned with a soft cloth which picks up dust. Polishing or clea- ning agents may damage the surface. Parts contacting the tape should be checked from time to time for contamination by tape abrasion, see illustration at the end of this booklet. - Page 16 Headset 561, dual speaker system. Acoustic coupler AKS 20, for recording telephone calls (as telephone adapter), for transmitting com- plete dictations via the telephone, and for use as headphone. Copying cable 765, for copying onto Grundig dicta- ting machines with telephone socket.
-
Page 17: Warranty, Service, Sales
If there is no specialized dealer in your region, please contact one of the following addresses. Grundig Business Systems (UK) Ltd. Jubilee House, 3 The Drive Great Warley, Brentwood, Essex, CM13 3FR Tel.: 01277-725 013... - Page 18 Figure to text "tape contacting parts" , page...
- Page 19 Grundig Business Systems GmbH Weiherstraße 10 D - 95448 Bayreuth Germany 36151 941 0201 Printed in Germany...
