  • Page 1 Model 6530 Three-Phase Power Analyzer User’s Manual...
  • Page 2 While every precaution has been exercised in the compilation of this document to ensure the accuracy of its contents, Magtrol, Inc. assumes no responsibility for errors or omissions. Additionally, no liability is assumed for any damages that may result from the use of the information contained within this publication.

  • Page 3: Safety Precautions

    STOP personal safety and proper operation. 2. Securely ground the 6530 Power Analyzer case by connecting a good earth ground at the ground stud located on the rear panel of the unit. Use a number 12 AWG, or larger wire.

  • Page 4: Revisions To This Manual

    The contents of this manual are subject to change without prior notice. Should revisions be necessary, updates to all Magtrol User’s Manuals can be found at Magtrol’s web site at www.magtrol.com/support/manuals.htm. Please compare the date of this manual with the revision date on the web site, then refer to the manual’s Table of Revisions for any changes/updates that have been made since this edition.

  • Page 5: Table Of Contents

    CONVENTIONS USED IN THIS MANUAL ........................viii 1. INTRODUCTION ..........................1 1.1 UNPACKING YOUR 6530 POWER ANALYZER ....................... 1 1.2 NEW FEATURES OF THE 6530 POWER ANALYZER ....................1 1.3 DATA SHEET ................................2 2. CONTROLS ............................5 2.1 FRONT PANEL ................................5 2.2 FRONT PANEL CONTROLS AND BUTTONS ......................

  • Page 6: Table Of Contents

    5.2 ABOUT THE RS-232 INTERFACE ..........................43 5.2.1 Connection ..............................43 5.2.2 Communication Parameters ........................... 44 5.2.3 Baud Rate ............................... 44 5.3 CHECKING THE 6530-TO-PC CONNECTION ......................44 5.4 DATA FORMAT ................................45 5.4.1 OT Example ..............................45 5.4.2 OE Example ..............................46 5.4.3 OA/OV/OW/OF Example ..........................
  • Page 7 Magtrol Model 6530 Three-Phase Power Analyzer Table of Contents 8. TROUBLESHOOTING ........................58 APPENDIX A: SCHEMATICS ....................... 59 A.1 MAIN BOARD - DSP, RAM, FLASH ........................59 A.2 MAIN BOARD - INPUT/OUTPUT, GPIB, RS-232 ....................60 A.3 MAIN BOARD - FPGA ............................... 61 A.4 INPUT MODULE - CURRENT ..........................

  • Page 8: Table Of Figures

    Table of Contents Magtrol Model 6530 Three-Phase Power Analyzer TABLE OF FIGURES CHAPTER 2 Figure 2–1 Front Panel ............................. 5 Figure 2–2 Secondary Function Menu ........................6 Figure 2–3 Device Setup Menu ..........................9 Figure 2–4 Rear Panel ............................10 Figure 2–5...

  • Page 9: Preface

    WHO SHOULD USE THIS MANUAL This manual is intended for those operators who are planning to use the Model 6530 Power Analyzer for power measurement purposes either as a stand-alone instrument or in conjunction with any Magtrol Hysteresis, Eddy-Current or Powder Brake Dynamometer, any Magtrol Dynamometer Controller and M-TEST Motor Testing Software.

  • Page 10: Conventions Used In This Manual

    Preface Magtrol Model 6530 Three-Phase Power Analyzer CONVENTIONS USED IN THIS MANUAL The following symbols and type styles may be used in this manual to highlight certain parts of the text: Note: This is intended to draw the operator’s attention to complementary information or advice relating to the subject being treated.

  • Page 11: Introduction

    Save all shipping cartons and packaging material for reuse when returning the instrument for calibration or servicing. NEW FEATURES OF THE 6530 POWER ANALYZER Magtrol's new Model 6530 Power Analyzer is an upgraded, three-phase version of the 6510. The new features that make the unit unique include: •...

  • Page 12: Data Sheet

    Chapter 1 – Introduction Magtrol Model 6530 Three-Phase Power Analyzer DATA SHEET...
  • Page 13 Magtrol Model 6530 Three-Phase Power Analyzer Chapter 1 – Introduction...
  • Page 14 Chapter 1 – Introduction Magtrol Model 6530 Three-Phase Power Analyzer...

  • Page 15: Controls

    2. Controls FRONT PANEL The front panel provides a power switch, sixteen control buttons and a Vacuum Fluorescent Display (VFD). MODEL 6530 POWER ANALYZER ENTER USER MENU DISPLAY PEAK-CF PEAK-CF SOURCE PEAK HOLD SHIFT PHASE AUTO AUTO CYC-CONT W-VA-PF HOLD...

  • Page 16: Enabling Secondary Functions

    Chapter 2 – Controls Magtrol Model 6530 Three-Phase Power Analyzer 2.2.1 NABLING ECONDARY UNCTIONS To enable the secondary function of the double-function control buttons: 1. Press the blue SHIFT button and release it. The word “SHIFT” appears in the display:...
  • Page 17 Magtrol Model 6530 Three-Phase Power Analyzer Chapter 2 – Controls 2.2.2.2 Double-Function Buttons o i t o l l • ↑ • n i / • o l l • ↑ • a t l n i / •...

  • Page 18: Vacuum Fluorescent Display (Vfd)

    ONTRAST ETTINGS The 6530 Power Analyzer is shipped with the Contrast Setting on low in order to prolong display life. If it is necessary to increase the Contrast for improved readability, execute the following steps using the USER MENU located on the front panel of the unit.

  • Page 19: Display Guide

    2.3.2 ISPLAY UIDE Following is a reference for symbols, abbreviations and messages that are used in the 6530. Symbol/Abbreviation/Message Meaning SHIFT Shift button was pressed...

  • Page 20: Rear Panel

    Chapter 2 – Controls Magtrol Model 6530 Three-Phase Power Analyzer REAR PANEL The rear panel provides connectors and receptacles for connecting to appropriate equipment. VOLTS AMPS VOLTS AMPS VOLTS AMPS CAUTION: DOUBLE POLE FUSING 20VA 50/60Hz EARTH 750 V 20 A...

  • Page 21: Figure 2-6 Rs-232C Interface

    Magtrol Model 6530 Three-Phase Power Analyzer Chapter 2 – Controls ANALOG Connects strip chart recorder or data acquisition system. OUTPUT Provides 12 analog outputs, 3 for each phase and 3 for summation. Volts 1, 2, 3, Σ (optional) • Amps 1, 2, 3, Σ...
  • Page 22 Chapter 2 – Controls Magtrol Model 6530 Three-Phase Power Analyzer POWER Attach power cord here. EARTH Attach earth ground here. GROUND WARNING: MAKE SURE THAT ALL MAGTROL STOP DYNAMOMETERS AND ELECTRONIC STOP PRODUCTS ARE EARTH-GROUNDED, TO ENSURE PERSONAL SAFETY AND PROPER OPERATION.

  • Page 23: Installation/Configuration

    The 6530 will operate from 85 to 264 VAC on a 50/60 Hz line voltage. 3.1.2 After turning the power on to the 6530, the display panel will show all segments of the VFD (series of rectangles), indicating that the 6530 is downloading the program.

  • Page 24: Main Menu

    Figure 3–3 Revision Display 3.1.3 When the 6530 is completely powered up and ready for use, the main menu will appear on the display. The main menu is defined by the last configuration that was used. This could include one of three different menus: phase, summation or custom.

  • Page 25: Protecting Your 6530

    If a circuit breaker is installed, it must be installed on the load side of the 6530 (downstream). This will keep the low impedance of the input line connected to the 6530 for surge suppression. If the line side must also contain a breaker, it should be delayed in operation to open after the load side breaker has opened.

  • Page 26: Circuit Breakers

    The voltage sense lines are connected at the line side of the circuit breaker to help prevent inductive transients from entering the 6530 as the circuit breaker opens. Make sure that connections from the circuit breaker to the load are heavy conductors and short as possible.

  • Page 27: Testing Instrumentation Setup

    Before the 6530 can be utilized, it must be configured and connected to the devices intended for power measurement. 3.3.1 IRING The 6530 has the ability to support a combination of up to 3 phases, therefore, there are a number of different ways in which the unit can be wired. 3.3.1.1 Hardware Connections The wiring mode selections include: •...

  • Page 28: Figure 3-8 Single-Phase, Two-Wire Wiring Schematic

    Chapter 3 – Installation/Configuration Magtrol Model 6530 Three-Phase Power Analyzer 1-Phase, 2-Wire • Measures single-phase power. • Can be wired on any input module. • The Power Factor is derived from the following equations: Amps Σ = A , Volts Σ = V Active Power = W Ø...

  • Page 29: Figure 3-10 Single-Phase, Three-Wire Wiring Schematic

    Magtrol Model 6530 Three-Phase Power Analyzer Chapter 3 – Installation/Configuration 1-Phase, 3-Wire • Measures single-phase power. • Utilizes input modules one and three. • The Power Factor is derived from the following equations: Amps Σ = (A )/2, Volts Σ = (V Active Power = ΣW = W...

  • Page 30: Figure 3-12 Three-Phase, Three-Wire Wiring Schematic

    Chapter 3 – Installation/Configuration Magtrol Model 6530 Three-Phase Power Analyzer 3-Phase, 3-Wire • Measures three-phase power. • Utilizes input modules one and three. • The Power Factor is derived from the following equations: Amps Σ = (A )/2, Volts Σ = (V Active Power = ΣW = W...

  • Page 31: Figure 3-14 Three-Phase, Four-Wire Wiring Schematic

    Magtrol Model 6530 Three-Phase Power Analyzer Chapter 3 – Installation/Configuration 3-Phase, 4-Wire • Measures three-phase power. • Utilizes all three phases. • The Power Factor is derived from the following equations: Amps Σ = (A )/3, Volts Σ = (V Active Power = ΣW = W...

  • Page 32: Figure 3-16 Three-Voltage, Three-Ampere Wiring Schematic

    Chapter 3 – Installation/Configuration Magtrol Model 6530 Three-Phase Power Analyzer 3-Volt, 3-Amp • Measures three-phase power. • Utilizes all three phases. • The Power Factor is derived from the following equations: Amps Σ = (A )/3, Volts Σ = (V Active Power = ΣW = W...

  • Page 33: Measurement Filter

    3.3.1.2 Software Configuration To configure the 6530 to coincide with the wiring on the rear panel, complete the following steps utilizing the USER MENU located on the front panel of the unit. 1. Turn on the 6530. See Section 3.1 – Powering Up the 6530.

  • Page 34: External Sensor

    Chapter 3 – Installation/Configuration Magtrol Model 6530 Three-Phase Power Analyzer 3.3.3 XTERNAL ENSOR If currents continuously reach above 20 amps, an external sensor must be used. 3.3.3.1 Hardware Connection In any of the wiring modes, any one of the amp meters may be replaced. The following diagram illustrates the connection.

  • Page 35: Figure 3-20 External Sensor Scale Factor Setup Menu

    Chapter 3 – Installation/Configuration 3.3.3.2 Software Configuration To configure the 6530 external sensor, complete the following steps utilizing the USER MENU located on the front panel of the unit. 1. Turn on the 6530. See Section 3.1 – Powering Up the 6530.

  • Page 36: Amp Scaling

    3.3.4.2 Software Configuration To configure the 6530 amp scaling for a current transformer, complete the following steps utilizing the USER MENU located on the front panel of the unit. 1. Turn on the 6530. See Section 3.1 – Powering Up the 6530.

  • Page 37: Figure 3-23 Amp/Volt Scaling Activated

    Magtrol Model 6530 Three-Phase Power Analyzer Chapter 3 – Installation/Configuration 5. To set the amp scaling for phase 1, press the RMS button under A1 and use the buttons in the USER MENU to adjust the value. 6. To turn phase 1 scaling ON, press the PEAK-CF button under OFF until ON is reached.

  • Page 38: Volts Scaling

    3.3.5.2 Software Configuration To configure the 6530 volt scaling for a potential transformer, complete the following steps utilizing the USER MENU located on the front panel of the unit. 1. Turn on the 6530. See Section 3.1 – Powering Up the 6530.

  • Page 39: Phase Setup

    Magtrol Model 6530 Three-Phase Power Analyzer Chapter 3 – Installation/Configuration 3.3.6 HASE ETUP Once the wiring mode, measurement filter, external sensor, amp scaling and volt scaling have been connected and configured, the unit is ready to be configured for each individual phase.

  • Page 40: Special Functions

    Chapter 3 – Installation/Configuration Magtrol Model 6530 Three-Phase Power Analyzer a.2. A source now needs to be selected. Press SHIFT button and release, then press SOURCE button. Keep repeating until desired source selection is reached. Selections include V1, A1, V2, A2, V3, A3, EXT and LINE.

  • Page 41: Figure 3-28 Peak Hold Clear Display

    Magtrol Model 6530 Three-Phase Power Analyzer Chapter 3 – Installation/Configuration 3.3.7.3 Peak Hold • Clears peak hold/inrush reading. • To enable, press SHIFT button and release, then press PEAK HOLD. The display will flash the following, then return to the main menu.

  • Page 42: Operating Principles

    4. Operating Principles ANALOG PROCESSING 4.1.1 OLTS The volts signal is brought in through a precision voltage divider of 2 M and 2.4 k resistors. The gain is 0.0012. This signal is buffered (GAIN = 1) and passed into a programmable gain section. The gains for the voltage ranges are given below.

  • Page 43: Amps

    Magtrol Model 6530 Three-Phase Power Analyzer Chapter 4 – Operating Principles 4.1.2 The amps signal is brought in through a precision shunt of 0.012 ohms. This signal is amplified by 2 and passed into a programmable gain section. The gains for the voltage ranges are given below.

  • Page 44: External Shunt

    Chapter 4 – Operating Principles Magtrol Model 6530 Three-Phase Power Analyzer 4.1.3 XTERNAL HUNT The external shunt signal is brought in through a precision voltage divider of 9.1 k and 9.1 k resistors. The gain is 0.50. This signal is buffered and passed into a programmable gain section. The gains for the voltage ranges are given below.

  • Page 45: Ac Details

    Magtrol Model 6530 Three-Phase Power Analyzer Chapter 4 – Operating Principles 4.2.1 AC D ETAILS 4.2.1.1 Interrupt Driven The power analyzer will automatically update its data every 4.469 microseconds by completing the following sequence of events: • The volts input is read and checked for an over range condition. The offset is then added to the reading and the reading is negated and saved.
  • Page 46 Chapter 4 – Operating Principles Magtrol Model 6530 Three-Phase Power Analyzer 4.2.1.2 Main Program The main program reads that a sample is ready. Divide the V² register by 256. Store V² in a 24-bit register. (See Section 4.2.3 – Round-Off Error).

  • Page 47: Dc Details

    Magtrol Model 6530 Three-Phase Power Analyzer Chapter 4 – Operating Principles 4.2.2 DC D ETAILS 4.2.2.1 Interrupt Driven The power analyzer will automatically update its data every 4.469 microseconds by completing the following sequence of events: • The volts input is read and checked for an over range condition. The offset is then added to the reading and the reading is negated and saved.
  • Page 48 Chapter 4 – Operating Principles Magtrol Model 6530 Three-Phase Power Analyzer 4.2.2.2 Main Program The main program reads that a sample is ready. Divide the V register by 256. Store V in a 24-bit register. The result is appended to a 32 word circular buffer.

  • Page 49: Round-Off Error

    Magtrol Model 6530 Three-Phase Power Analyzer Chapter 4 – Operating Principles 4.2.3 OUND RROR The interrupt routine adds 256 56-bit squared readings. This reading is then divided by 256 and put into a 24-bit register. Some error occurs during the move to the 24-bit register. The result of the 16- bit A/D conversion is put into the high 16 bits of a 24-bit register.

  • Page 50: Peak Hold / Inrush Current

    NRUSH URRENT Peak hold/inrush current allows the 6530 to store the highest value read in a designated period of time, the designated period of time being the time span since the last peak hold clear occurred. Values include amps, watts and volts in any preferred combination. See Section 3.3.7.3 – Peak Hold.

  • Page 51: Rms

    Magtrol Model 6530 Three-Phase Power Analyzer Chapter 4 – Operating Principles 4.3.4 See Section 4.2.1 – AC Details 4.3.5 REST ACTOR The crest factor measurement is determined by dividing the peak measurement by the RMS measurement. See the following graph for reference.

  • Page 52: Computer Controlled Operation

    GPIB P HANGING THE RIMARY DDRESS Each instrument serviced by the GPIB has its own primary address code, which enables the computer to obtain readings from the instrument. The factory default of the GPIB address on the 6530 is 14.

  • Page 53: About The Rs-232 Interface

    Some PC interfaces can access from one to fifteen 4-bit primary addresses. Other interfaces can access as many as thirty-one 5-bit primary addresses. The 6530 uses the 4-bit format. For setup, complete the following instructions utilizing the USER MENU control buttons.

  • Page 54: Communication Parameters

    Make sure that the 6530 and its host computer are communicating before acquiring data. 1. Make sure the primary GPIB address is set correctly for the 6530. 2. Set the input variable to 15 characters (13 variable characters and the two required data termination characters CR and LF.

  • Page 55: Data Format

    Magtrol Model 6530 Three-Phase Power Analyzer Chapter 5 – Computer Controlled Operation DATA FORMAT • All measurement values are returned as an ASCII-string floating point in E notation. • The same data format will be used for both IEEE-488 and RS-232 interface. See Section 5.6 –...

  • Page 56: Oe Example

    Use the following information to answer the formatting questions asked when installing your GPIB software. All GPIB data acquisition systems require the use of data termination characters. The 6530 uses the GPIB standard termination characters Carriage Return (CR) and Line Feed (LF). Provide them in that order.

  • Page 57: 6530 Communication Commands

    Magtrol Model 6530 Three-Phase Power Analyzer Chapter 5 – Computer Controlled Operation 6530 COMMUNICATION COMMANDS IEEE-488 Address: 0-15 Terminator: carriage return followed by a line feed RS-232 Baud Rate: 300, 600, 1200, 2400, 4800, 9600, 19.2 k, 115.2 k Terminator:...
  • Page 58 Chapter 5 – Computer Controlled Operation Magtrol Model 6530 Three-Phase Power Analyzer " " 1 l l a t < > r " " 2 " " 1 l l a t < > r " " 2 " "...
  • Page 59 Magtrol Model 6530 Three-Phase Power Analyzer Chapter 5 – Computer Controlled Operation " " 1 l l a t < > r " " 2 " " 1 l l a n i l t < > r . ) r "...

  • Page 60: Data Output Commands

    Chapter 5 – Computer Controlled Operation Magtrol Model 6530 Three-Phase Power Analyzer 5.6.2 UTPUT OMMANDS " " 1 " " 2 t < > r " " 1 t < > r " " 2 " " 1 t <...

  • Page 61: Calibration

    6. Calibration CLOSED-BOX CALIBRATION The 6530 features closed-box calibration. The advantage of closed-box calibration is that the user does not have to disassemble the case or make mechanical adjustments. CALIBRATION SCHEDULE Calibrate the 6530: • After any repairs are performed.

  • Page 62: Basic Calibration Process

    4. Turn the power ON while holding the SHIFT button. See Section 3.1 – Powering Up the 6530. Before the display panel shows the segments of the VFD (series of rectangles), the following display will appear indicating that the instrument has been placed in the calibration mode.
  • Page 63 Magtrol Model 6530 Three-Phase Power Analyzer Chapter 6 – Calibration 5. Set volt and amp range by entering the following command codes. VOLTS => RV0,m2 where m2 = 0 to 3 AMPS => RA0,m2 where m2 = 0 to 3 6.

  • Page 64: Optional Features

    7. Optional Features ANALOG OUTPUTS An option to the 6530 is an analog output plug-in module that provides 12 channels of analog output corresponding to volts, amps and watts. Each output is capable of, and calibrated to, ± 10 volts.

  • Page 65: Hardware Connection

    9. Replace the top cover by reconnecting the ground strap and replacing the four screws. 10. Finally, plug the line cord in to the back of the unit. When the power is turned on, the 6530 will recognize the card is in place and start sending data to it.

  • Page 66: Calibration

    7.1.5 ALIBRATION 7.1.5.1 Closed-Box Calibration The 6530 features closed-box calibration for the analog output. The advantage of closed-box calibration is that the user does not have to disassemble the case or make mechanical adjustments. 7.1.5.2 Calibration Schedule Calibrate the 6530 analog output board: •...
  • Page 67 Magtrol Model 6530 Three-Phase Power Analyzer Chapter 7 – Optional Features " " b i l o i t b i l o i t b i l o i t l l a t < > r i t i l l u .

  • Page 68: Troubleshooting

    8. Troubleshooting s ' t • • . t l • • . e l . t l • If you require additional assistance, please contact Magtrol Customer Service at 1-716-668-5555.

  • Page 69: Appendix A: Schematics

    Appendix A: Schematics MAIN BOARD - DSP, RAM, FLASH...

  • Page 70: Main Board - Input/Output, Gpib, Rs-232

    Appendix A: Schematics Magtrol Model 6530 Power Analyzer MAIN BOARD - INPUT/OUTPUT, GPIB, RS-232...

  • Page 71: Main Board - Fpga

    Magtrol Model 6530 Power Analyzer Appendix A: Schematics MAIN BOARD - FPGA 107 CCLK CCLK I/O54 IRQC 74 PROGRAM PROG I/O55 USB_IRQ 72 DONE I/O56/SGCK3 SCO_V2 36 MODE I/O57 TIO2 +5VD I/O58/PGCK3 SCO_V1 38 N/C2 I/O59 AUX1 34 N/C1 CCLK...

  • Page 72: Input Module - Current

    Appendix A: Schematics Magtrol Model 6530 Power Analyzer INPUT MODULE - CURRENT DGND1 28 DGND DVDD AGND7 AGND6 21 AVDD2 AGND5 19 AVDD1 AGND4 15 AVDD AGND3 13 AGND2 10 AGND1 9 AGND...

  • Page 73: Input Module - Voltage

    Magtrol Model 6530 Power Analyzer Appendix A: Schematics INPUT MODULE - VOLTAGE DGND1 DGND DVDD AGND7 AGND6 AVDD2 AGND5 AVDD1 AGND4 AVDD AGND3 AGND2 AGND1 AGND...

  • Page 74: Key Pad

    Appendix A: Schematics Magtrol Model 6530 Power Analyzer KEY PAD...

  • Page 75: Analog Output

    Magtrol Model 6530 Power Analyzer Appendix A: Schematics ANALOG OUTPUT A.7.1 Analog Output – drawing 1 of 4...
  • Page 76 Appendix A: Schematics Magtrol Model 6530 Power Analyzer A.7.2 Analog Output – drawing 2 of 4 +15VA BAT54S LT2079 J1-1 U5-A AMPS PHASE 1 J1-14 C22 0.01 -15VA +15VA PAEN BAT54S LT2079 VOUT1 AD7834 VOUT2 SYNC J1-2 FSYNC U5-B DATAIN...
  • Page 77 Magtrol Model 6530 Power Analyzer Appendix A: Schematics A.7.3 Analog Output – drawing 3 of 4 +15VA BAT54S LT2079 J1-4 U1-A – AMPS PHASE 2 J1-17 C26 0.01 -15VA +15VA BAT54S LT2079 J1-5 PAEN U1-B – VOLTS PHASE 2 VOUT1 J1-18 C27 0.01...
  • Page 78 Appendix A: Schematics Magtrol Model 6530 Power Analyzer A.7.4 Analog Output – drawing 4 of 4 +15VA BAT54S LT2079 J1-7 U2-A – AMPS PHASE 3 J1-20 C30 0.01 -15VA +15VA BAT54S LT2079 J1-8 PAEN U2-B – VOLTS PHASE 3 VOUT1 J1-21 C31 0.01...

  • Page 79: Glossary

    Following is a list of abbreviations and terms used in this manual. For a list of symbols and abbreviations used on the 6530 display, refer to Section 2.3.2 – Display Guide. Active Power....The sum of the instantaneous volts input multiplied by the instantaneous amps input = true power = watts.

  • Page 80: Index

    Communication Commands 47 IEEE-488. See GPIB/IEEE-488 Communication Parameters 44 Input Module 10 Configuration Commands 47 Inputs 10. See also Outputs Connection Amps Input 10 6530-to-PC 44 Ext. Sync. 11 Analog Output Board 55 External Sensor 10 RS-232 43 Voltage Input 10...
  • Page 81 Magtrol Model 6530 Three-Phase Power Analyzer Index Inrush 69 RS-232 Interface 43 Inrush Current 40 RS-232C 11 Interrupt Driven AC 35 Scaling Activated 27 DC 37 Secondary Functions 6 Self-Test 13 Line Voltage 13 Sensor Substitution 24 Setup 17–31 Signal...

  • Page 82: Magtrol Limited Warranty

    If purchaser fails to give notice, the delivery shall be deemed to conform with the terms of the order. The purchaser assumes all risk of loss or damage to products upon delivery by Magtrol to the carrier. If a product is damaged in transit, PURCHASER MUST FILE ALL CLAIMS FOR DAMAGE WITH THE CARRIER to obtain compensation.
  • Page 83 MAGTROL INC MAGTROL SA Subsidiaries in: • Germany 70 Gardenville Parkway Route de Moncor 4B Magtrol SA ISO 9001:2000 certified • France Buffalo, New York 14224 USA 1701 Fribourg, Switzerland • Great Britain Phone: +1 716 668 5555 Phone: +41 (0)26 407 3000 •...
