Lexicon Studio Core2 Service Manual
PART NO. DESCRIPTION
245-10561 CAPSM,CER,100pF,50V,COG,5%
245-10976 CAPSM,CER,47pF,50V,COG,5%
245-11594 CAPSM,CER,2200pF,50V,COG,5%
245-11625 CAPSM,CER,33pF,50V,COG,5%
245-12316 CAPSM,CER,.0082uF,50V,X7R,10%
245-12485 CAPSM,CER,.1uF,25V,Z5U,20%
245-13810 CAPSM,CER,1200pF,50V,COG,5%,08 16.00
270-00779 FERRITE,BEAD
270-11545 FERRITESM,CHIP,600 OHM,0805
300-10509 DIODESM,1N914,SOT23
300-10563 DIODESM,DUAL,SERIES,GP,SOT23
300-11599 DIODESM,GP,1N4002,MELF
330-10523 ICSM,DIGITAL,74HCU04,SOIC
330-12452 ICSM,DIGITAL,74VHCT244,SOIC
340-09244 ICSM,LINEAR,78LS05,5V REG,SO-8
340-10550 ICSM,LIN,CS3310,VOL CTL,SOIC
340-11573 ICSM,LIN,NJM4580,DUALOPAMP,SOP10.00
340-11575 ICSM,LIN,7805,+5V REG,TO263
340-12061 ICSM,LIN,TLC2932,PLL,SSOIC
340-12062 ICSM,LIN,LM3940,5-3V REG,TO263
340-13843 ICSM,LIN,79L05A,-5V REG,SO-8
346-12072 ICSM,SS SWITCH,QS3245,QSOP
350-13834 ICSM,FPGA,XCS10,14X14,PLCC
350-13846 ICSM,ROM,27256,CORE2,V1.00
355-12830 ICSM,DAC,AKM4324,24b,96kHzVSOP 4.00
355-13829 ICSM,ADC,AKM5383,24b,96kHz,SOP
365-12046 ICSM,uPROC,DSP,56301,66MHz,TQF 1.00
390-12075 CRYSTALSM,6.000MHz,PAR,18pF
390-12361 CRYSTALSM,11.2896MHz,PAR,HC49
390-12362 CRYSTALSM,12.288MHz,PAR,HC49
430-10421 LEDSM,INNER LENS,GRN
490-02356 CONN,JUMPER,.1X025,2FCG
510-03961 CONN,POST,100X025,HDR,2MCG
510-13835 CONN,POST,.100,HDR,2X6MCG,LP
510-13837 CONN,DB25FG,PCRA,4-40THRD INS
510-13840 CONN,OPTO,PCRA,TORX173,6Mbps
510-13841 CONN,OPTO,PCRA,TOTX173,6Mbps
527-12974 CONN,DSUB,JSCKT,4-40,.187X.25
640-01701 SCRW,4-40X1/4,PNH,PH,ZN
701-13842 BRACKET,PCI,DB25+2OPTO CUTOUT 1.00
710-13710 PC BD,MAIN,CORE2
740-11287 LABEL,S/N,PCB,PRINTED
7-2
QTY REFERENCE
8.00 C78-81,88-91
4.00 C1,2,123,124
4.00 C99,100,107,108
4.00 C134,135,137,138
1.00 C128
90.00 BC1,2,5-8,13-16(+/-)
BC22;BC23A-H,J-L
BC24;BC27A-H
BC28,29
C4,6-10,47,50,52,53
C56,58,59,62,64,66
C68,70,72,82,96-98
C101-106,109-111
C117,118,120,122
C125-127,130,133
C136,139,141,143-145
C15,18,19,22,23,26
C27,30,31,34,35,38
C39,42,43,46
2.00 FB5,6
9.00 FB1-4,7-11
2.00 D14,23
9.00 D1-8,24
10.00 D12,13,15-22
1.00 U28
1.00 U22
1.00 U29
2.00 U3,4
U1,2,5-8,13-16
1.00 U20
1.00 U30
1.00 U26
1.00 U19
2.00 U21,25
1.00 U27
1.00 U24
U9-12
2.00 U17,18
U23
1.00 Y1
1.00 Y3
1.00 Y2
3.00 D9-11
4.00 W5-8
8.00 W1-8
1.00 J2
1.00 J1
1.00 CP1
1.00 CP2
2.00 J1
1.00 BRACKET
1.00
1.00
