Lexicon Studio Core2 Service Manual
Core2 Block Diagram
Analog In
Input
CH 1
Level
Control
CS3310
CH 2
.
.
.
ADAT IN
SPDIF RCA IN
FPGA
BOOT
ROM
(Dev Only)
AD_CH12
AD_CH34
DSP
BOOT
ROM
6-2
L
DBX Type-4
R
DBX Type-4
SampleClk
FPGA
XCS10
PLL
RefClk
ADAT
MP100
or
Effects
SPDIF
DA_CH12 - SDATA
DA_CH34
DA_CH56
DA_CH78
DSP
M56301
PCI Bus
A/D
AK5383
AD_CH12
96K-S/s
SDATA
24bits
MasterClk
ADAT OUT
SPDIF RCA OUT
L
D/A
AK4324
R
Analog Out
CH 1
CH 2
.
.
.
