Summary of Contents for Telsyco IPDP – 00
-
Page 1: Doorphone Voip
IPDP – 00 IPNC4 - mod IPDP – 00C NC - mod4 IPNC1 - mod NM - mod4 IPNC2 - mod IPDP-K Installation and Operating Instructions TELSYCO s.r.o. e-mail: info@telsyco.com www.telsyco.com Prostřední 627/14 tel./fax: +420 241 765 832 141 00 Praha 4... - Page 2 Welcome We congratulate you on purchase of “DoorPhone VoIP” (VoIP = Voice over IP), which is the improved version of successful “New DoorPhone” (NUDV). This DoorPhone VoIP will widely manage to satisfy your needs of communication with persons at the building front door or your company entry, or family house doorway.
-
Page 3: Table Of Contents
Table of Contents DOORPHONE VOIP ....................1 BASIC DESCRIPTION..................4 ...................... 4 EATURES ..................5 ODULE SSEMBLY ..................6 ODULE EATURES 1.3.1 IPDP Basic Module .................. 6 1.3.2 Extending Module IPNCx-mod, NC-mod4 and NM-mod4......9 1.3.3 IPDP-K Keyboard Module ..............10 IP A ........ -
Page 4: Basic Description
Basic Description 1.1 Features Modular system allows to connect 4 to 64 buttons Voice communication is supplied only from telephone line Two 16digit numbers (IP adress) with each button Day/night switching Possibility of the call extension by * or # choice Possible to connect two independent locks for door opening Possible use of 5 switch modes (e.g. -
Page 5: Module Assembly
1.2 Module Assembly The IPDP structural elements are the basic modules with color camera IPDP-00C or without camera IPDP-00 and extending button modules IPNC1-mod with one button, IPNC2-mod with two buttons, IPNC4-mod, NC-mod4 and NM-mod4 with four buttons. Further it is possible to provide the assembly with numerical keyboard. -
Page 6: Module Features
1.3 Module Features 1.3.1 IPDP Basic Module The IPDP basic module assembling from modulus IP and motherboard. Positioning setting elements and connectors is on picture 1. Picture 1 Basic module - motherboard The “14 pin black conector” serves the connection of extending modules by means of flat cable. - Page 7 For IPDP is necessary used the AC voltage of min. 10Vst - max. 15Vst or DC voltage of min. 12Vss to max. 18Vss must be energized to “12V” terminal. This source loading depends on number of modules, since it simultaneously serves feeding of lighting through visiting cards –...
- Page 8 Setting voice communication – position trimmers are presetting from manufacture and in majority case agree with, therefore changes setting altering only in necessary case Basic position of trimmers, sense of rotation and meaning trimmers are illustration on picture 3. Picture 3 Setting of trimmers DIP switch setting basic operation and default setting.
-
Page 9: Extending Module Ipncx-Mod, Nc-Mod4 And Nm-Mod4
1.3.2 Extending Module IPNCx-mod, NC-mod4 and NM-mod4 This module is supplied in three designs. The IPNCx-mod module (picture 6) has four buttons and includes the electronics to be connected to the basic module. The NC-mod4 module has four buttons and includes the electronics to be connected to the IPNCx-mod or to previous NC-mod4 module. -
Page 10: Ipdp-K Keyboard Module
The flat cable connection is facilitated by connector locks, preventing from rotation, but to keep the connection routing is imperative. “To IP DoorPhone” is always the routing to the basic module. “To NCmod” is routing to the row end (on last NC-mod.). -
Page 11: Installation Of Doorphone Voip Assembly
1.4 Installation of DoorPhone VoIP Assembly 1.4.1 Installation on Plaster By installation on plaster the only compact box - Rain-Protective Cover KPDxx is used, which will supersede all mechanical parts (MKxx, Canopy xx and Fixing Frame xx). The installation is made by screwing to the wall by means of dowels. - Page 12 Picture 7 Mechanical assembly parts IPDP - installation and operating instructions...
-
Page 13: Focus Camera And Description Of Front Panel
1.6 Focus camera and description of front panel If is need focus picture from camera, so everything is illustration on picture front panel basic module on Picture 8 . Picture 8 front panel of basic module IPDP 1. front panel 2. -
Page 14: Doorphone Voip Operation
2 DoorPhone VoIP Operation 2.1 Signaling Overview The all-purpose guard signals an acoustic conditions they may occur during operation. Another signaling can be done by means of red LED (placed under microphone hole). You can listen the signaling samples in Nset setting program. -
Page 15: Doorphone With Keyboard
preprogrammed code and the time among presses is not bigger than the set point, then the DoorPhone will pick up and close the corresponding switch (if set in m=1 or m=5 modes) to the period given by seting in parameters. Then it will hang up. -
Page 16: Person Inside Object
2.3 Person Inside Object The person inside object is considered a person that is in phone contact with DoorPhone. 2.3.1 Outgoing Call The outgoing call is the call from DoorPhone (caused by visitor). After guard choice the telephone is ringing inside object and the pickuping up will allow speaking to the visitor at door. -
Page 17: Programming Of Parameters
3 Programming of Parameters 3.1 Basic VoIP settings 3.1.1 Choosing a mode and login It is important to choose a DoorPhone mode first. The DoorPhone can work in the PeerToPeer mode or SIP server mode. The mode setting can be made by a relevant switch (DIP switch see on picture 8). -
Page 18: Language Option
3.1.2 Language option Language setting can be made in a menu on the left panel. 3.1.3 Network settings Network settings are located in the Network seting menu item. It is possible to use DHCP service (1) or you can enter IP addresses manually. Manual configuration: After making changes click on a save and restart button. - Page 19 DHCP configuration: After making changes click on a save and restart button. 1 – Enable/disable ethernet settings via DHCP 2 – show automatic DHCP generate IP adress and othet settings 3 – Default value – presetings to the firm settings. After making changes click on a save and restart button (display screen - see page 22).
-
Page 20: Peer To Peer Or Sip Server Connection
3.1.4 Peer to peer or SIP server connection The DoorPhone can be set to the peer to peer (P2P) mode or to the SIP server mode by DIP switch (page 17). In P2P mode DoorPhone calling IP adress – in memory buttons (page 27). -
Page 21: Setting Video
3.1.6 Setting video After making changes use the save changes button. 1 – Resolution display video 2 – Number picture per second (frequency restoring picture) 3 – Setting next parameters of camera 4 – Default value – presetings to the firm settings. After making changes use the save changes button. -
Page 22: Service Settings
3.1.7 Service settings 1 – display current version of firmware in module VoIP and in module doorphone, button switching if is has save history events in basic or enhanced mode - it is important to analyses mistakes and problems. This file it is possible save to PC by click on download log file. -
Page 23: Setting Doorphone Parameters
3.2 Setting DoorPhone parameters 3.2.1 Basic Parameters After making changes use the save changes button. 1 – Mode of DoorPhone choice selects number per Day/Night DoorPhone mode or selects numbers of the first and second groups. 2 – Sign for call extension * or # (10sec before call end the DoorPhone will send a notice, then the call may be extended) 3 –... -
Page 24: All About Relays
3.2.2 All about relays After making changes use the save changes button. – Relay mode: =1 switch mode – it will close on command or password for period t (used for electrical locks, gate opening etc.) =2 camera mode – it will close by guard pick up and open by hanging up. =3 lighting mode –... - Page 25 2 – password for relay closing from buttons or keyboard [2 to 6 digits]. Total 6 passwords, they are controlled by Day/Night; the combination is entered either by DoorPhone buttons (first 10 buttons) or from attached keyboard (after pressing of key symbol). The relay closing influences the set switch mode and Day/Night switchover.
-
Page 26: Time Parameters
3.2.3 Time Parameters After making changes use the save changes button. 1 – max. time, for which the DoorPhone is hanging up, this time can be extended during call by sign choice from telephone (* or #) – see page 23. 2 –... -
Page 27: Direct Dialing - Memories
7 – In default is status of DoorPhone signalling acoustically. If signalling makes problem, so this signalling others tones prohibited. 8 – Default value – presetings to the firm settings. After making changes use the save changes button. 3.2.4 Direct Dialing – Memories After making changes use the save changes button. -
Page 28: Technical Parameters
4 Technical Parameters 4.1 Electrical Parameters Parameter Value Conditions Communication interface Ethernet 10BaseT, 100BaseTx VoIP protocol supported Band width 300Hz – 3400 Hz Power supply of lighting through, 12Vss ± 2V , 10-12Vst ± 2V switches and heating Max. consumption 300mA 12Vss Max. - Page 29 Guarantee conditions: The product was shop-checked. The producer guarantees that this product will keep the features described in these operating instructions in the course of guarantee provided that the user will be handled with it as described in the operating manual. The guarantee will be extended by period of possible guarantee repair.
- Page 30 Registered company address: TELSYCO, s.r.o. Prostřední 627/14 141 00 Praha 4 Czech Republic VAT: CZ28548302 Company is registered in the Commercial Register administered by the Municipal Court in Prague, Section C, Record 149478 TELSYCO s.r.o. Office: Kyjovská 1983/1 142 00 Praha 4...
