RF-8001
Personal
Organizer
Organizador
Personal
User's Guide
Manual del usuario

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RF-8001 and is the answer not in the manual?

Questions and answers

Related Manuals for Rolodex RF-8001

Summary of Contents for Rolodex RF-8001

  • Page 1 RF-8001 Personal Organizer Organizador Personal User’s Guide Manual del usuario...
  • Page 2 Notice Recommendations • The manufacturer strongly recommends that separate, permanent written records be kept of all important data. Data may be lost or altered in virtually any electronic memory product under certain circumstances. Therefore, the manufacturer assumes no responsibility for data lost or otherwise rendered unusable whether as a result of improper use, repairs, defects, battery replacement, use after the specified battery life has expired, or any other...

  • Page 3: Getting Started

    Getting Started Using the Organizer for the First Time The first time you use this organizer, you should perform a system reset. Warning! A system reset erases any user-entered information and clears all settings. 1. Turn the organizer over and carefully pull the battery insulation sheet to remove it.
  • Page 4 Getting Started 1. Press to enter Home Time mode. 2001 - 01 - 01 A 12 - 00 - 00 indicates Home Time mode. 2. Press LANG. ENGLISH? 3. Press (Search up) or (Search down) to cycle through English, Español (Spanish), Français (French), Deutsch (German), Portuguêse (Portuguese), Italiano (Italian), and Nederlands (Dutch).

  • Page 5: Key Guide

    Key Guide Function Keys Goes to the Business phone directory. Goes to the Personal phone directory. Toggles between Home and World time. Goes to the Schedule. Goes to the Memos. Toggles between the Calculator and Converter. Displays the e-mail address field in the phone directories.
  • Page 6 Key Guide Combination Keys Press and release ALT before pressing the next key. is displayed. Toggles times between 12- and 24-hour time (12/24) displays. C ( ) Selects the alarm clock and then cycles through the day and hour. Activates/deactivates reiminder alarms in the Schedule.
  • Page 7 Key Guide Calculator Function Keys In the calculator, the keys are autoshifted to perform the following functions. Clears the memory. Retrieves a number from the memory. Stores a negative number in the memory. Stores a positive number in the memory. T (÷) Divides a number.

  • Page 8: Using The Clocks

    Using the Clocks The clock lets you set a Home time and view local times around the world. You should set the Home time before viewing the World times or using the Schedule, because World times are based on Home time. Setting Home Time 1.
  • Page 9 Using the Clocks 6. When you see one in your time zone, press ENTER to choose it as your Home city. Note: If you wish to change the label of your Home city, type the name you want using up to 6 letters and press ENTER or to confirm the name.

  • Page 10: Setting World Time

    Using the Clocks Setting World Time 1. Press ) until the World time screen TIME appears. indicates the World time screen. There are 43 built-in cities of diffferent zones. 2. Use (Search up) or (Search down) to cycle through the list of cities and view their corre- sponding times.

  • Page 11: Setting The Alarms

    Setting the Alarms There are three kinds of alarms: the daily alarm, indicated by , the hourly chime, indicated by and the Schedule alarm, indicated by Setting the Daily Alarm/Hourly Chime 1. Press to enter alarm mode. ALARM A 12-00 2.

  • Page 12: Entering A Phone Record

    Using the Telephone Directories There are two telephone directories, a Business phone directory and a Personal phone directory. Entering a Phone Record 1. Press to enter a personal telephone record. Press to enter a business telephone record. PERSONAL You can enter a maximum of 36 characters, including letters, numbers and symbols.
  • Page 13 Using the Telephone Directories 3. Press to go to the next field. (Next) You can enter a Company, Address, Home phone number, Work number, Fax number, Cell number, Pager number, E-mail address, and Note. You can type up to 36 characters in the E-mail address field. It is not necessary to complete each field.

  • Page 14: Using The Scheduler

    Using the Scheduler In each schedule record, you can enter the name and type of event and the date and time when the event is going to occur. Entering a Schedule Record 1. Press (Sched) MESSAGE? 2. Type a description of the event. For example, type STAFF MEETING.

  • Page 15: Gauging The Memory

    Using the Scheduler Use the direction keys to move the cursor to the position you want. 4. Press ENTER to store the data. 5. Press ALT and then C ( ) to toggle the schedule alarm on and off. indicates that the schedule alarm is on. When the schedule alarm is set, the alarm will sound at the time of the appointment.

  • Page 16: Using The Memo Directory

    Using the Memo Directory You can enter three lines of data in a memo record. You can type a maximum of 36 characters including letters, numbers and symbols on line one, and 36 numbers each on lines 2 and 3. Entering a Memo Record 1.

  • Page 17: Searching And Editing Records

    Searching and Editing Records Telephone and Memo records are listed alphabetically. Schedule records are listed in chronological order. You can search for them either directly or sequentially. You can review your records, edit them or delete them. Searching for a Record 1.

  • Page 18: Editing A Record

    Searching and Editing Records Editing a Record 1. Find the record you want to edit. To learn how, read "Searching for a Record". 2. Press ALT and then (Edit/Ins). 3. Move the cursor to the character you want to edit. Press ALT and then (Edit/Ins) to insert a character in front of the cursor.

  • Page 19: Using A Password

    Using a Password You can lock your organizer so that only the Clock, Calculator and Converter can be used without supplying the password. Note: You do not need to set a password to use this organizer. Warning: Please keep written records of your data.

  • Page 20: Unlocking The Unit

    Using a Password 4. Press ENTER to save the password. When the password is set, is displayed on the screen to indicate that your password is in effect. Each time you enter the phone list (either personal or business), Memo, or Schedule, the password is required.

  • Page 21: Using The Calculator

    Using the Calculator Performing a Calculation 1. Press until the Calculator screen appears. 2. Type a number. You can type up to 10 digits. To type a decimal, press O (.) or . in the number keypad. To clear a number, press C/Ce. ÷...
  • Page 22 Using the Calculator Using the Calculator Memory 1. In the Calculator, make a calculation or type a number. 2. To add the number on the screen to the number stored in memory, press R ( +). To subtract the number on the screen from the number stored in memory, press E ( M indicates the number is stored in memory.

  • Page 23: Using The Converter

    Using the Converter Using the Built-in Conversion Rates Use your organizer to do the following built-in conversions: Feet Meters Yards Meters Ounces Grams US gallons Liters Miles Kilometers Inches Centimeters Pounds Kilograms 1. Press until the Converter screen appears. FEET 0.3048 2.
  • Page 24 Using the Converter Using the Euro Converter Your organizer includes the following built-in Euro conversions: 40.3399 1.95583 166.386 6.55957 0.787564 1936.27 40.3399 2.20371 13.7603 200.482 5.94573 1. Press to enter Euro conversion mode. EURO 2. Press (Search up) or (Search down) to select the Euro conversion item you want.
  • Page 25 Using the Converter Creating Custom Conversion Rates You can enter your own units and conversion rates. For example, you can enter and convert additional currency rates. 1. Press until you enter the currency mode. 2. Press (Search up) or (Search down) to select the conversion to be edited.

  • Page 26: Replacing The Battery

    Replacing the Battery This organizer uses one CR2032, 3-volt lithium battery. Before you follow these steps you should have a small Phillips screwdriver and the new battery at hand. Warning! When no battery is installed, this organizer will save your information for only about 30 seconds. So quickly install the new battery when you remove the old one.

  • Page 27: Specifications

    Specifications Model RF-8001 Size: 11.8 x 8. cm • Weight: 3 oz. Battery: One CR2032 lithium • Storage capacity: 10 KB ISBN 1-56712-691-X Cleaning This Product To clean this product, spray a mild glass cleaner onto a cloth and wipe its surface. Don’t spray liquids directly onto the unit.
  • Page 28 WORLD TIME LIST CITY NAME ABBREVIATION CITY NAME ABBREVIATION LONDON TOKYO LISBON ADELAIDE PARIS SYDNEY BERLIN NOUMEA ROME WELLINGTON AMSTERDAM TONGA BARCELONA MIDWAY ISLANDS HELSINKI HONOLULU CAIRO ANCHORAGE MOSCOW LOS ANGELES RIYADH DENVER TEHRAN CHICAGO DUBAI NEW YORK KABUL TORONTO KARACHI CARACAS DELHI...
  • Page 29  Electronic Publishers www.franklin.com...
