RF-8001/
RF-8003
Personal Organizer
User's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RF-8001 and is the answer not in the manual?

Questions and answers

Related Manuals for Rolodex RF-8001

Summary of Contents for Rolodex RF-8001

  • Page 1 RF-8001/ RF-8003 Personal Organizer User’s Guide...

  • Page 2: Table Of Contents

    Contents License Agreement ....2 Notice ......3 Getting Started .

  • Page 3: License Agreement

    License Agreement READ THIS LICENSE AGREEMENT BEFORE USING THE ELECTRONIC REFERENCE. YOUR USE OF THE ELEC- TRONIC REFERENCE DEEMS THAT YOU ACCEPT THE TERMS OF THIS LICENSE. IF YOU DO NOT AGREE WITH THESE TERMS, YOU MAY RETURN THIS PACK- AGE WITH PURCHASE RECEIPT TO THE DEALER FROM WHICH YOU PURCHASED THE ELECTRONIC REFER- ENCE AND YOUR PURCHASE PRICE WILL BE REFUND-...

  • Page 4: Notice

    Notice Recommendations • The manufacturer strongly recommends that separate permanent written records be kept of all important data. Data may be lost or altered in virtually any electronic memory product under certain circumstances. Therefore, the manufacturer assumes no responsibility for data lost or otherwise rendered unusable whether as a result of improper use, repairs, defects, battery replacement, use after the specified battery life has expired, or any other...

  • Page 5: Getting Started

    Getting Started Using the Organizer for the First Time The first time you use your organizer, you should perform a system reset. Warning! A system reset erases any user-entered information and clears all settings. 1. Turn the organizer over and carefully pull the battery insulation sheet to remove it.

  • Page 6: Changing The Language

    Getting Started Changing the Language Your organizer can display prompts and other mes- sages in seven languages. To select a language, do the following: 1. Press 2001- 01- 01 12-00-00 indicates Home Time mode. 2. Press ALT+L. ENGLISH 3. Use SEARCH to cycle through English, Español (Spanish), Français (French), Deutsch (German), Italiano (Italian), Português (Portuguese) and Nederlands (Dutch).
  • Page 7 Getting Started Turning the Keytone On and Off The keytone is the beep that sounds whenever a key is pressed. When the keytone is on, appears at the top of the screen. To turn the keytone on or off, first press ALT and then press V( Using Symbols SYM gives you the option of entering any of 23...

  • Page 8: Shifted Keys

    Shifted Keys Press and release ALT before pressing the next key. is displayed. Press Q-O and A-H to get Euro characters. To lock ALT, press it twice. indicates that the keys are now shifted. Press any letter between Q-O and A-H to cycle through special characters and accented letters.

  • Page 9: Setting Home Time

    Setting Home Time The clock lets you set a Home time and view local times around the world. You must set the Home time before viewing the World times or using the Schedule, because World times are based on the Home time.

  • Page 10: Viewing World Time

    Setting Home Time 6. Enter the current time. 7. Press ENTER to save your settings. You can now set a date format. Press ALT+S and use SEARCH to cycle through the available for- mats. Press ENTER to select the one you want. Viewing World Time 1.

  • Page 11: Setting The Alarms

    Setting the Alarms You can set an hourly chime, a daily alarm and a schedule alarm, each of which has a different sound. Alarm Icon Hourly chime Daily alarm Schedule alarm Setting the Daily Alarm 1. Press and then SET. ALARM SET A 12-00 2.

  • Page 12: Entering A Phone Record

    Entering a Phone Record There are two telephone directories: Business and Personal. In the RF-8001 press to enter a personal record, to enter a business record. In the RF-8003 press once to enter a personal record and twice to enter a business record.

  • Page 13: Entering A Schedule Record

    Entering a Schedule Record In each schedule record, you can enter the name of the event and the date and time. You can enter a maximum of 36 characters in the name field. The data is arranged in chronological order from January to December.

  • Page 14: Entering A Memo Record

    Entering a Memo Record You can enter three lines of data in a memo record. You can type a maximum of 36 characters including letters, numbers and symbols on line one, and 36 numbers each on lines two and three. The records are stored in alphabetical order.

  • Page 15: Searching And Editing Records

    Searching and Editing Records Telephone and Memo records are listed alphabetically. Schedule records are listed chronologically. You can search for them either directly or sequentially. You can review your records, edit them or delete them. Searching for a Record Go to the directory you want. Use SEARCH to view the records in the order they appear.

  • Page 16: Editing A Record

    Searching and Editing Records Editing a Record 1. Find the record you want to edit. To learn how, read “Searching for a Record.” 2. Press ALT and then EDIT 3. Make your edits. Press ALT and then ) to delete a character at the cursor.

  • Page 17: Using A Password

    Using a Password Warning! Please keep written records of your data. If you forget your password, you will not be able to recover any of the data stored in your organizer. To bypass the password, you will have to perform a sys- tem reset, which will clear the password but will also erase all the data stored in memory.
  • Page 18 Using a Password Entering Confidential Data Make sure is not displayed on the screen before you begin to enter your confidential data. 1. Select the directory you want, and enter your data. 2. Press SET. will appear. 3. Press ENTER to store your data in secret memory.

  • Page 19: Using The Calculator

    Using the Calculator Making a Calculation 1. Press once to see the Calculator. 2. Type a number. You can type up to 10 digits. To type a decimal, press O(.). To clear a number, press C/Ce. 3. Press I(+), U(—), Y(x), or T(÷) to add, subtract, multiply, or divide, respectively.
  • Page 20 Using the Calculator M indicates the number is stored in memory. Note: The memory is cleared when your turn the unit off. 3. To retrieve the number from memory, press 4. To clear the memory, press Q( Note: When the integer part of a calculation result, or any integer in the memory, exceeds 10 digits, or any other invalid operation is attempted, a calculator error will occur and...

  • Page 21: Using The Converters

    Using the Converters There are three converters: Metric, Currency and Euro. Press to cycle through the converters and the calculator. Doing Metric Conversions Use the Metric converter to do any of nine built-in metric conversions. Inches Centimeters Yards Meters Miles Kilometers C°...
  • Page 22 Using the Converters Setting Currency Rates Do the following to enter your own currency names and conversion rates. You can use a maximum of four characters for a currency name. 1. Press until you see the Currency converter screen. EURO 2.
  • Page 23 Using the Converters Doing Currency Conversions Once you set conversion rates, you can do currency conversions. 1. Press until you see the Currency converter screen. 2. Use SEARCH to find the currencies you want. 3. Press ) or ) to select the conver- EDIT sion direction.

  • Page 24: Replacing The Battery

    Replacing the Battery This organizer uses one CR-2032 lithium battery. Before you follow these steps you should have a small Phillips screwdriver and the new battery at hand. Warning! When no battery is installed, this organizer will save your information for only about 30 seconds. So install the new battery quickly when you remove the old one.

  • Page 25: Specifications

    FOR HOME OR OFFICE USE Customer Support (609) 386-8997 © 2001 Franklin Electronic Publishers, Inc., Burlington, N.J. 08016-4907 USA. All rights reserved. ROLODEX® is a registered trademark of Berol Corporation, a subsidiary of Newell Rubbermaid, Inc. Patents pending.

  • Page 26: Limited Warranty (Outside U.s.)

    Limited Warranty (outside U.S.) This product, excluding batteries is guaranteed by Franklin for a period of one year from the date of purchase. It will be repaired or replaced with an equivalent product (at Franklin’s option) free of charge for any defect due to faulty workmanship or materials.

  • Page 27: Limited Warranty (U.s. Only)

    Limited Warranty (U.S. only) LIMITED WARRANTY, DISCLAIMER OF WARRANTIES AND LIMIT- ED REMEDY (A) LIMITED WARRANTY. FRANKLIN WARRANTS TO THE ORIGI- NAL END USER THAT FOR A PERIOD OF ONE (1) YEAR FROM THE ORIGINAL DATE OF PURCHASE AS EVIDENCED BY A COPY OF YOUR RECEIPT, YOUR FRANKLIN PRODUCT SHALL BE FREE FROM DEFECTS IN MATERIALS AND WORKMANSHIP.
  • Page 28 Limited Warranty (U.S. only) EVEN IF WE HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES, OR THEY ARE OTHERWISE FORESEEABLE. WE ARE ALSO NOT RESPONSIBLE FOR CLAIMS BY A THIRD PARTY. OUR MAXIMUM AGGREGATE LIABILITY TO YOU, AND THAT OF OUR DEALERS AND SUPPLIERS, SHALL NOT EXCEED THE AMOUNT PAID BY YOU FOR THE FRANKLIN PRODUCT AS EVIDENCED BY YOUR PURCHASE RECEIPT.

  • Page 29: Fcc Notice

    FCC Notice NOTE: This equipment has been tested and found to com- ply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 30 WORLD TIME LIST CITY NAME ABBREVIATION CITY NAME ABBREVIATION LONDON TOKYO LISBON ADELAIDE PARIS SYDNEY BERLIN NOUMEA ROME WELLINGTON AMSTERDAM TONGA BARCELONA MIDWAY ISLANDS HELSINKI HONOLULU CAIRO ANCHORAGE MOSCOW LOS ANGELES RIYADH DENVER TEHRAN CHICAGO DUBAI NEW YORK KABUL TORONTO KARACHI CARACAS DELHI...
  • Page 31 www.franklin.com...
