Wing Assembly - Millenium Slow Stick X Assembly Instructions Manual

DO NOT GLUE UNTIL INSTRUCTED TO DO SO!
NOTE: These instructions include steps for
building the wing either as a straight-wing Slow
Stick X OR the dihedral wing X-Trainer.

Wing assembly

The top of this wing is identified by the
installation of the main spar. The main spar
(SC1) is always installed from the TOP of the
wing.
Step-1: (Spar Crutch) Glue SC1 and SC1-A
together. Use SC1-B if you are building the
SSX as a trainer. Trim the plywood wing joiner
P2 for "dihedral" or "no dihedral".
Step-2: Glue SC2-A to wing rib W2. Pay
attention to orientation. The circle in SC2-A
should be close to W2 and near the bottom. Use
SC2-B if you are building the trainer.
Remember, the opposing wing half is a
mirrored version. SC2-A/B should be square to
W2.
IMPORTANT:
Step-3: Install but do not glue SC1 assembly.
The small holes in SC1 and SC2-A/B should
line-up.
Step-4: Install, do not glue W3 ribs.
Step-5: Glue TE-C pieces to TE-A. TE-A
should be square to TE-C.
