Millennium RC presents...       PARF & ARF



Assembly Instructions
The Slow Stick X PARF (Partial ARF) is an upgrade to the GWS Slow Stick Electric ARF Park Flyer Airplane
Kit ™. This PARF kit replaces the original Styrofoam wing and tail surfaces of the Slow Stick to a more robust
balsa-constructed design, complete with ailerons and a full symmetrical wing, allowing the Slow Stick to
become a fully aerobatic model aircraft. The Slow Stick X ARF does not require parts from an existing Slow
Stick.
Adult supervision recommended for children 15 and under. R/C Airplanes should be flown following safety
guidelines provided by the AMA (Academy of Model Aeronautics).
CAUTION: This is not a toy!
Recommendations:
1. Read through each step before starting assembly.
2. After removing all the pieces from packaging, inspect to make sure there are no broken or missing
parts.
3. CAUTION: When removing masking tape from covered parts, always do so by pulling tape onto itself,
rather than straight off, in order to prevent damage to covering.
4. Check off each completed step to help keep from losing your place.
V. 06‐08














Wing span:  Approx. 42"
Wing Area:  504 sq. in.
Wing Loading:  6.71 oz/ sq. ft.


Advertisement

loading
Need help?

Need help?

Do you have a question about the slow stick x and is the answer not in the manual?

Questions and answers

Related Manuals for Millenium slow stick x

Summary of Contents for Millenium slow stick x

  • Page 1 Assembly Instructions The Slow Stick X PARF (Partial ARF) is an upgrade to the GWS Slow Stick Electric ARF Park Flyer Airplane Kit ™. This PARF kit replaces the original Styrofoam wing and tail surfaces of the Slow Stick to a more robust balsa-constructed design, complete with ailerons and a full symmetrical wing, allowing the Slow Stick to become a fully aerobatic model aircraft.
  • Page 2 1. GWS Slow Stick Electric ARF Park Flyer (ailerons, elevators, rudders. . .) Airplane Kit ™ (used or new) or Millennium 2. Slow Stick X Decal R/C Fuselage Kit (Applies to PARF model 3. CA hinges for ailerons (depends on version...
  • Page 3 Assembly of the control hinges  4. Turn the stabilizer assembly over, and 1. Start by removing the horizontal stabilizer carefully fold the elevator back onto the and vertical stabilizer from the packing stabilizer. bags. Remove the four pieces of masking tape holding the elevator to the stabilizer. 2.
  • Page 4 leading edge of wing between the center 12. Slide the hinge, complete with centered T- ribs, making sure to trim any excess pin into the wing hinge slots from which you covering that may prevent it from gluing previously removed the hinge. properly.
  • Page 5 Assembly of the Tail Section  tiny holes through servo mounts and mount the servo using servo-manufacturer 24. Cut away covering from slots on the vertical provided screws. and horizontal stabilizer for mounting the tail section mount. Line the tail section mount with the bottom edge of the vertical stabilizer and trace the edge with a marker.

  • Page 6: Fuselage Assembly

      Fuselage Assembly  27. (Only applies to 2-piece fuselage) Use CA glue to attach fuselage joiner to one end of the shorter fuselage stick (tail end). 28. (Only applies to 2-piece fuselage) Slide one end of the longer fuselage stick into the joiner and attach with provided screw.
  • Page 7 33. Feed the long wire push rod through the push rod guide and through the guide holes in the rear wing saddle, so that the “Z-bend” is at the tail section. Repeat on both sides. 34. Install the servos, as per servo manufacturer instructions, using servo manufacturer-provided hardware.

  • Page 8: Contact Details

    Slide the decal into position and squeegee the excess water from under the decal. Allow the decal to dry overnight. Enjoy Your New Millennium R/C Slow Stick X!   41. Once balanced, without moving any of the black parts, VERY CAREFULLY remove the wing.
