INSTRUCTION MANUAL
Jig Saw
MT431
011277
DOUBLE INSULATION
IMPORTANT: Read Before Using.
1

Advertisement

Table of Contents
loading

Related Manuals for Maktec MT431

Summary of Contents for Maktec MT431

  • Page 1 INSTRUCTION MANUAL Jig Saw MT431 011277 DOUBLE INSULATION IMPORTANT: Read Before Using.

  • Page 2: Specifications

    ENGLISH (Original instructions) SPECIFICATIONS Model MT431 Length of stroke 18 mm Blade type B type Wood 65 mm Max. cutting capacities Mild steel 6 mm Strokes per minute (min 0 - 3,100 Overall length 214 mm Net weight 1.9 kg Safety class •...

  • Page 3: General Power Tool Safety Warnings

    Designation of Machine: tools. Unmodified plugs and matching outlets will Jig Saw reduce risk of electric shock. Model No./ Type: MT431 Avoid body contact with earthed or grounded are of series production and surfaces such as pipes, radiators, ranges and Conforms to the following European Directives: refrigerators.

  • Page 4: Jig Saw Safety Warnings

    up or carrying the tool. Carrying power tools with Service your finger on the switch or energising power tools 25. Have your power tool serviced by a qualified that have the switch on invites accidents. repair person using only identical replacement 14.

  • Page 5: Functional Description

    Switch action WARNING: DO NOT let comfort or familiarity with product 1. Switch trigger (gained from repeated use) replace strict adherence 2. Lock button to safety rules for the subject product. MISUSE or failure to follow the safety rules stated in this instruction manual may cause serious personal injury.

  • Page 6: Bevel Cutting

    blade, resulting in a serious personal injury. Turn the tool on without the blade making any contact To install the blade, loosen the bolt counterclockwise on and wait until the blade attains full speed. Then rest the the blade holder with the hex wrench. base flat on the workpiece and gently move the tool With the blade teeth facing forward, insert the blade into forward along the previously marked cutting line.

  • Page 7: Metal Cutting

    Complete the cut in the normal manner. Front flush cuts Finishing edges 1. Hex wrench 2. Bolt 3. Base 011287 Loosen the bolt on the back of the base with the hex 011290 wrench and slide the base all the way back. Then tighten To trim edges or make dimensional adjustments, run the the bolt to secure the base.

  • Page 8: Maintenance

    Insert the circular guide pin through either of the Straight cuts two holes on the fence guide. Screw the threaded knob onto the pin to secure the pin. 1. Rip fence Now slide the rip fence to the desired cutting radius, (Guide rule) and tighten the bolt to secure it in place.
  • Page 12 Makita Corporation Anjo, Aichi, Japan www.makita.com 884958-225...
