Operator's Manual
Shipping & Mailing
Inserter
Relay 1000
™
Document Inserting System
Quick Install Guide
International English Edition
SV63177 Rev. B
February 1, 2016
Advertisement
Related Manuals for Pitney Bowes Relay 1000
Summary of Contents for Pitney Bowes Relay 1000
- Page 1 Shipping & Mailing Inserter Relay 1000 ™ Document Inserting System Quick Install Guide International English Edition SV63177 Rev. B February 1, 2016...
- Page 2 Directives of the European Union. SV63177 Rev. B February 1, 2016 ©2005, 2016 Pitney Bowes Inc. All rights reserved. This guide may not be reproduced in whole or in part in any fashion or stored in a retrieval system of any type or transmitted by any means, electronically or mechanically, without the express, written permission of Pitney Bowes.
- Page 3 Relay 1000 Quick Install Guide Follow the instructions in this guide to get your Relay 1000 system setup and running in the shortest possible time. Included in this guide are instruction for the following: • Unpack • Load envelopes •...
- Page 4 Relay 1000 Quick Install Guide Step 1: Unpack 1. Lift out the following accessories and put them to one side: • Test paper and envelopes • Bottle of E-Z seal® • Power Cord 2. Remove the cardboard and foam packing.
- Page 5 Relay 1000 Quick Install Guide Step 2: Set in Place 1. Lift the inserter by its handles and place it on a flat surface. SAFETY NOTICE! • Lift the inserter only by its lifting handles. • Lift correctly (bend knees and keep back straight).
- Page 6 After a few seconds, the display shows READY. SAFETY NOTICE! • Locate the system close to a power socket. • Use the power cord supplied. • See the Relay 1000 Operating Guide for complete safety and connection information. SV63177 RevB...
- Page 7 Relay 1000 Quick Install Guide Step 4: Fill the Moistener 1. Slide the moistener open. 2. Fill the moistener with E-Z Seal®. Use the entire bottle. 3. Slide moistener closed. NOTE: The moistener takes about five minutes to become fully wet and ready for use.
-
Page 8: Step 5: Load Envelopes
Relay 1000 Quick Install Guide Step 5: Load Envelopes Use the test paper and envelopes to practice using the system and to make sure that system is working correctly. 1. Fan test envelopes marked with the letter B. 2. Tap the stack of envelopes to align edges. - Page 9 Relay 1000 Quick Install Guide Step 6: Load Sheets 1. Fan the stack of sheets test sheets that are marked with A1. 2. Tap the stack to align the edges. 3. Place the stack of sheets in feeder A1, FACE DOWN and BOTTOM EDGE FIRST.
- Page 10 Relay 1000 Quick Install Guide Step 7: Setup A green indicator on the control panel shows that a feeder or function is selected. Pressing the selection buttons repeatedly (a, b, and c in the image below) steps through feeders and options available on your system.
- Page 11 Relay 1000 Quick Install Guide Step 8: Run a Test Job To run a test job: 1. Press the Trial Piece button. 2. If the trail piece checks out ok, press Start. 3. Press Stop to stop processing. NOTE: The trial piece will not be sealed so you can check the contents of the envelope.
- Page 12 Relay 1000 Quick Install Guide Step 9: Congratulations Your Relay 1000 is now ready to use. There is a slot on the the top right side of the cover (shown in the image below) for storage of the Relay 1000 Operator Guide.
- Page 13 This page intentionally blank.
- Page 14 3001 Summer Street Stamford, CT 06926-0700 www.pitneybowes.com SV63177 RevB © 2016 Pitney Bowes Inc. All Rights Reserved...
