Installation
Important
The unit must be fitted at least 50mm from the end of the tube.
The cable must not touch the any part of the lamp.
Lamp fitting
1
Select correct clip for lamp;
T5 or T8.
Louvre fixing assembly
1 2
Compact reflector fitting
1
2
Panel mounting using lugs
Use the lugs on rear of detector to
secure into thin sheet metal (1mm
max.).
4
2
3
Fixing lugs for gear tray fixing
3
Louvre fitting
1
2
4
4
3 4
Gear tray fixing dimensions
