- Page 1 DJI FOCUS ACCESSORY SUPPORT FRAME Quick Start Guide V1.0 2016.03...
- Page 2 Read this entire document carefully to ensure proper configuration before use. Failure to read and follow instructions and warnings in this document may result in serious injury to yourself or others, or damage to your DJI product or damage to other objects in the vicinity. This document and all other collateral documents are subject to change at the sole discretion of DJI.
- Page 3 Extension Rod Kit ×1 Accessory Mount ×2 Screw ×2 Extension Rod ×2 Accessories Package Camera Screw A (1/4'') ×2 Camera Screw B (3/8'') ×2 Camera Screw C (1/4'') ×2 Camera Screw D (3/8'') ×2 © 2016 DJI. All Rights Reserved.
- Page 4 3. Attach the extension rod kit to the camera mounting plate and tighten the screw. 4. Slide the accessory mount onto the extension rod, adjust it to the desired position and then tighten the knob. Knob © 2016 DJI. All Rights Reserved.
- Page 5 5. Install a third extension rod if necessary. 6. Mount the DJI Focus motor. Adjust its position so that it makes good contact with the camera lens gear ring. Ensure the whole structure is securely held in place. © 2016 DJI. All Rights Reserved.
- Page 6 DJI Support http://www.dji.com/support This content is subject to change. Download the latest version from http://www.dji.com/product/focus Download the latest version from DocSupport@dji.com. © 2016 DJI. All Rights Reserved. Printed in China.
