Summary of Contents for Cornelius STARBUCKS UC100 PROGATE
- Page 1 STARBUCKS UC100 PROGATE Operator’s Manual Release Date: January 24, 2008 Publication Number: 621054211OPR Revision Date: April 07, 2014 Revision: B Visit the Cornelius web site at www.cornelius.com for all your Literature needs.
-
Page 2: Contact Information
Commercial Warranty. Cornelius will not be responsible for any repair, replacement or other service required by or loss or damage resulting from any of the following occurrences, including but not limited to, (1) other than... -
Page 3: Table Of Contents
TABLE OF CONTENTS Safety Instructions ........... 1 Read and Follow all Safety Instructions . -
Page 5: Safety Instructions
AFETY RECAUTIONS This ice dispenser has been specifically designed to provide protection against personal injury and eliminate contamination of ice. To ensure continued protection and sanitation, observe the following: © 2008-2014, Cornelius Inc. - 1 - Publication Number: 621054211OPR... -
Page 6: Description
Listed below are the codes and their meaning: PR (Prime) This code will display when the unit has just been powered. When displayed, ice levels are low or close to empty inside the hopper. Publication Number: 621054211OPR - 2 - © 2008-2014, Cornelius Inc. -
Page 7: Loc (Lock)
The controller has four default tables contained within it. These tables are: “USA”, “International”, “Custom” and “Data”. To view or program the current table perform the following steps: Press and hold the “P” button and the “M” button simultaneously. © 2008-2014, Cornelius Inc. - 3 - Publication Number: 621054211OPR... -
Page 8: To View The Data Table, Perform The Following Steps
Sanitizing solution – Dissolve one packet of Kay-5 Sanitizer/Cleaner into 2-1/2 gallons of water to ensure 100 ppm of available chlorine. The following dispenser maintenance should be performed at the intervals indicated:. Publication Number: 621054211OPR - 4 - © 2008-2014, Cornelius Inc. -
Page 9: Daily (Or As Required)
Wash cup rest with soap solution and rinse in potable water. Install the cup rest into the drip tray. Clean all exterior surfaces with soap solution and rinse with potable water. © 2008-2014, Cornelius Inc. - 5 - Publication Number: 621054211OPR... -
Page 10: Ice Chute Maintenance
Figure 3 remove the ice chute cover and replace it. Reinstall the finger guard onto the ice chute cover. If ERR is displayed, press “M” button to return to dispense mode. Publication Number: 621054211OPR - 6 - © 2008-2014, Cornelius Inc. -
Page 11: Monthly Maintenance
NOTE: The bottom of the auger has a depression in the shape of a D. When replacing the auger, it will be necessary to rotate the auger after insertion in the tube to engage the motor shaft. Make © 2008-2014, Cornelius Inc. - 7 -... -
Page 12: Specifications
100 psi max to unit regulated to 65 psi (4.48 bar) to Progate ice gate system Dimensions: 24-3/16 in. Wide; 30-3/8 in. Deep 27 in. Below Countertop; 28 in. Above Countertop Publication Number: 621054211OPR - 8 - © 2008-2014, Cornelius Inc. -
Page 13: Troubleshooting
ICE DISPENSING A. Defective ice gate cylinder. A. Contact service agent. DURING AUTOMATIC AGITATION B. Defective ice gate solenoid valve. B. Contact service agent. C. Defective keypad. C. Contact service agent. © 2008-2014, Cornelius Inc. - 9 - Publication Number: 621054211OPR... - Page 14 UC100 ProGate Operator’s Manual Publication Number: 621054211OPR - 10 - © 2008-2014, Cornelius Inc.
- Page 16 Cornelius Inc. www.cornelius.com...
