4000E IP Broadband Loop Carrier
Installation Instructions
Document Number IPD4-A2-GZ40-10
July 2005
Contents

Software and Firmware License Agreement

The terms and conditions of this License Agreement (the "Agreement") will apply
to the software and/or firmware (individually or collectively the "Software")
incorporated into the Paradyne product (the "Product") purchased by you and any
IPD4-A2-GZ40-10
........................................................................................................ 3
............................................................................................ 4
............................................................................................ 12
................................................................................................ 12
........................................................................................................ 16
..................................................................................................... 17
ONCE YOU HAVE READ THIS LICENSE AGREEMENT AND AGREE TO ITS
TERMS, YOU MAY USE THE SOFTWARE AND/OR FIRMWARE INCORPORATED
INTO THE PARADYNE PRODUCT. BY USING THE PARADYNE PRODUCT YOU
SHOW YOUR ACCEPTANCE OF THE TERMS OF THIS LICENSE AGREEMENT.
IN THE EVENT THAT YOU DO NOT AGREE WITH ANY OF THE TERMS OF THIS
LICENSE AGREEMENT, PROMPTLY RETURN THE UNUSED PRODUCT IN ITS
ORIGINAL PACKAGING AND YOUR SALES RECEIPT OR INVOICE TO THE
LOCATION WHERE YOU OBTAINED THE PARADYNE PRODUCT OR THE
LOCATION FROM WHICH IT WAS SHIPPED TO YOU, AS APPLICABLE, AND YOU
WILL RECEIVE A REFUND OR CREDIT FOR THE PARADYNE PRODUCT
PURCHASED BY YOU.
July 2005
...................................................... 1
......................................................... 3
.................................................................. 6
..................................................................... 7
........................................................................... 9
....................................................................... 15
........................................................................ 15
.......................................................................... 17
............................................................................. 18
........................................... 20
1
