4300 Remote Broadband Access Concentrator
Installation Instructions
Document Number 4300-A2-GZ40-00
July 2004
Contents
CONTENTS .................................................................................................................................................................................. 1
USING THIS INSTALLATION GUIDE ................................................................................................................................... 2
PRODUCT DOCUMENTATION ONLINE .............................................................................................................................. 2
INSPECTING SHIPMENT ......................................................................................................................................................... 3
WARRANTY, SALES, SERVICE, AND TRAINING INFORMATION ............................................................................... 3
PRODUCT OVERVIEW............................................................................................................................................................. 3
CABINET CONFIGURATIONS............................................................................................................................................... 5
EXPANSION, MOUNTING AND MAINTENANCE KITS .................................................................................................... 6
PRODUCT SPECIFICATIONS................................................................................................................................................. 7
QUARTER-TURN LOCKING DOOR LATCHES ................................................................................................................... 8
INSTALLATION PROCEDURE ............................................................................................................................................... 9
CLEARANCE REQUIREMENTS ............................................................................................................................................ 9
INSTALLATION PROCEDURE FOR POLE MOUNTING .................................................................................................. 10
INSTALLATION PROCEDURE FOR WALL MOUNTING................................................................................................. 12
CABINET GROUNDING INFORMATION ........................................................................................................................... 14
GROUND WIRE...................................................................................................................................................................... 14
GROUNDING DIAGRAM AND PROCEDURE.................................................................................................................... 15
PROTECTION/CROSS CONNECTS...................................................................................................................................... 16
PROTECTION/CROSS CONNECT WIRING TABLES ...................................................................................................... 17
FAN/FILTER REPLACEMENT.............................................................................................................................................. 19
.............................................................................................................................................................. 19
EXTERNAL WIRING............................................................................................................................................................... 20
LINE POWER ............................................................................................................................................................................ 20
SCHEMATIC WIRING DIAGRAMS ..................................................................................................................................... 20
4300-A2-GZ40-00
July 2004
1
Advertisement
Table of Contents
Related Manuals for Paradyne 4300
Summary of Contents for Paradyne 4300
-
Page 1: Table Of Contents
4300 Remote Broadband Access Concentrator Installation Instructions Document Number 4300-A2-GZ40-00 July 2004 Contents CONTENTS ... 1 USING THIS INSTALLATION GUIDE ... 2 PRODUCT DOCUMENTATION ONLINE ... 2 INSPECTING SHIPMENT ... 3 WARRANTY, SALES, SERVICE, AND TRAINING INFORMATION ... 3 PRODUCT OVERVIEW... 3 CABINET CONFIGURATIONS... -
Page 2: Using This Installation Guide
Fan Replacement Kit for the 4300 Remote BAC, Feature Number 4300-F1-500, Installation Instructions 4300-A2-GZ45-00 Filter Replacement Kit for the 4300 Remote BAC, Feature Number 4300-F1-501, Installation Instructions To order a paper copy of a Paradyne document, or to speak with a sales representative, please call 727-530-2000. July 2004 4300-A2-GZ40-00... -
Page 3: Inspecting Shipment
Paradyne worldwide office locations, use one of the following methods: • Internet: Visit the Paradyne World Wide Web site at www.paradyne.com. (Be sure to register your warranty at www.paradyne.com/warranty.) •... - Page 4 4300 Remote Broadband Access Concentrator Installation Instructions Rectifier or DC-DC Converter Figure A - Front view of cabinet with door open GranDSLAM 4200 DSLAMs Swing out racks for Protection/Cross Connect Panels July 2004 Cabinet lifting eyelets Protection/Cross Connect Panels 4300-A2-GZ40-00...
-
Page 5: Cabinet Configurations
–48 VDC power to the GranDSLAM assemblies. The input voltage to the DC-DC converter is 90 to 400 VDC. This model will be wired for one GranDSLAM assembly. 4300-A2-GZ40-00 4300 Remote Broadband Access Concentrator Installation Instructions Ground Bus Bar AC Input Panel for Model 2... -
Page 6: Expansion, Mounting And Maintenance Kits
4300 Remote Broadband Access Concentrator Installation Instructions EXPANSION, MOUNTING AND MAINTENANCE KITS See Table 1 for expansion kit part numbers. The Ordering Procedure section of this document contains instructions for ordering the kits. Table 1 - Expansion, Mounting and Maintenance Kits... -
Page 7: Product Specifications
Top View Front View Figure C – Cabinet overall dimensions 4300-A2-GZ40-00 4300 Remote Broadband Access Concentrator Installation Instructions 26 inches (66 cm) 22 inches (56 cm) — does not include heat exchanger 19 inches (48 cm) internal 60 pounds (27 kg) -
Page 8: Quarter-Turn Locking Door Latches
4300 Remote Broadband Access Concentrator Installation Instructions QUARTER-TURN LOCKING DOOR LATCHES The cabinet door is equipped with 2 quarter-turn padlockable latches. The latches are secured by turning the 7/16” hex security bolt one quarter turn clockwise until the stop is reached. Convenient security locking hasps are factory installed to allow for a #1 Master Lock padlock (or equivalent) to be installed. -
Page 9: Installation Procedure
4300 Remote Broadband Access Concentrator Installation Instructions Installation Procedure The 4300 Remote BAC can be mounted on a pole or wall. See figures below. Lifting eyelets are provided to facilitate hoisting if desired. During cabinet mounting, fix the cabinet securely to avoid personal injury or cabinet damage. -
Page 10: Installation Procedure For Pole Mounting
4300 Remote Broadband Access Concentrator Installation Instructions INSTALLATION PROCEDURE FOR POLE MOUNTING Use this procedure to mount the cabinet on a 6-inch to 8-inch diameter pole. See Figure F below for a cabinet mounting illustration. Figure F - Pole Mounting Diagram... - Page 11 For mounting heights less than 7’ above grade, excess bolt length may need to cut off in order to prevent a hazardous protrusion. Lifting eyelets are provided to facilitate hoisting if desired. 4300-A2-GZ40-00 4300 Remote Broadband Access Concentrator Installation Instructions July 2004...
-
Page 12: Installation Procedure For Wall Mounting
4300 Remote Broadband Access Concentrator Installation Instructions INSTALLATION PROCEDURE FOR WALL MOUNTING Use this procedure to mount the cabinet on a flat wall. See Figure G below for a cabinet mounting illustration. Figure G - Wall Mounting Diagram July 2004... - Page 13 6. Secure the cabinet to the wall by installing 5/16” flat washers, lock washers and nuts to the bolts inserted in step 5. 7. Repeat steps 5 and 6 for the lower mounting bracket. Lifting eyelets are provided to facilitate hoisting if desired. 4300-A2-GZ40-00 4300 Remote Broadband Access Concentrator Installation Instructions July 2004...
-
Page 14: Cabinet Grounding Information
4300 Remote Broadband Access Concentrator Installation Instructions Cabinet Grounding Information Bonding and grounding should be done in accordance with the operating telephone company’s standard procedures and comply with local electrical codes. GROUND WIRE The ground wire protects the electronics from voltage surges. A #6 ground wire must be properly grounded to provide lightning surge protection for the cabinet. -
Page 15: Grounding Diagram And Procedure
3. If the resistance requirement in Step 2 is met, proceed to step 4. Otherwise, follow local practices to lower the resistance to ground. 4. Connect a #6 ground wire to the ground rod. 4300-A2-GZ40-00 4300 Remote Broadband Access Concentrator Installation Instructions Internal Grounding bus Ground Rods July 2004... -
Page 16: Protection/Cross Connects
4300 Remote Broadband Access Concentrator Installation Instructions Protection/Cross Connects OSP side, 5 ft unterminated cable Protection modules, 5- pin gas tube, 230 Volt (50 pair) Figure I – Protection/Cross Connect Panel, top view (50 pair) Pair numbers Figure J –Cross Connect Panel, front view... -
Page 17: Protection/Cross Connect Wiring Tables
BLUE / BLACK BROWN / VIOLET Pair #12 ORANGE/ BLACK SLATE / VIOLET Pair #13 GREEN / BLACK 4300-A2-GZ40-00 4300 Remote Broadband Access Concentrator Installation Instructions Pair #14 Pair #26 BLUE / WHITE Pair #15 Pair #27 ORANGE / WHITE Pair #16... - Page 18 4300 Remote Broadband Access Concentrator Installation Instructions Table 3 - Cross Connect Panel Wiring WHITE / ORANGE WHITE / BLUE BINDER Pair #1 BLUE / WHITE BLUE / WHITE Pair #5 ORANGE / WHITE ORANGE / WHITE Pair #9 GREEN / WHITE...
-
Page 19: Fan/Filter Replacement
Figure K – Fan/Filter Replacement Diagram The 4300 Remote BAC is equipped with one –48 VDC fan assembly located in the top of the cabinet behind the rack-mounted equipment. The fan is retained by four 4 mm screws. It is accessible from inside of the cabinet. -
Page 20: External Wiring
(Type 78-8130-4094-2-A into the search box presented at that site.) LINE POWER To calculate how many line pairs are required to power the 4300 Remote BAC, you can use the 4300 Remote BAC Line Power Calculator, available at at www.paradyne.com. Select Support → Tools. - Page 21 4300 Remote Broadband Access Concentrator Installation Instructions Figure M - Model 2 Schematic Wiring Diagram 4300-A2-GZ40-00 July 2004...
- Page 22 4300 Remote Broadband Access Concentrator Installation Instructions Figure N - Model 3 Schematic Wiring Diagram *4300-A2-GZ40-00* *4300-A2-GZ40-00* July 2004 4300-A2-GZ40-00...
