- Page 1 User Manual Tabletop scale PCE-BSH series User manuals in various languages (Deutsch, français, italiano, español, português, nederlands, türk, polski, русский, 中文) can be downloaded here: www.pce-instruments.com Last change: 28 October 2016 v1.0 © PCE Instruments...
-
Page 2: Table Of Contents
System description ................3 Getting started ..................4 Operation ....................4 Measurement ........................4 Further functions ......................5 Settings ..........................6 Calibration ..................... 9 When to calibrate? ......................9 One point calibration ......................9 Warranty ....................10 Disposal ....................10 © PCE Instruments... -
Page 3: Safety Notes
We expressly point to our general guarantee terms which can be found in our general terms of business. If you have any questions please contact PCE Instruments. The contact details can be found at the end of this manual. © PCE Instruments... -
Page 4: Specifications
Mains adaptor 12 V / 500 mA Dimensions 200 x 265 x 100 mm Weight Approx. 1800 g (without batteries) Delivery contents 1 x tabletop scale PCE-BSH 6000 or PCE-BSH 10000 1 x weighing pan 1 x mains adaptor 1 x instruction manual © PCE Instruments... -
Page 5: System Description
Print the current reading UNIT key PCS key Switch the measuring unit: g ,ct, oz, tola Piece counting function Bottom side Power switch Battery compartment Cover of the battery compartment Batteries Use 6 x 1.5 V AA batteries © PCE Instruments... -
Page 6: Getting Started
When there is no load on top of the weighing pan, the display should show “0”. If this is not the case, press the [ZERO] key to zero the display. If the reading is stable, a stable indication appears on the display. Now you can read the weight of the object. © PCE Instruments... -
Page 7: Further Functions
By pressing the [PRINT] key, the current reading is sent out via the USB interface. Depending on the setting, the scales either send out the readings when the [PRINT] key is pressed, continuously or once the reading is stable. © PCE Instruments... -
Page 8: Settings
“OFF” (no transmission), “Key” (pressing the [PRINT] key transmits the current reading), “Stb” (transmission once the reading is stable). Press the [ZERO] key once again to return to normal weighing mode. USB output format 9600 / P NONE / KEY © PCE Instruments... - Page 9 1 kg = 85.11.4 TAR 0.2 TAR 1 kg = 85. 8.6 TMR 0.2 TMR Use the [ZERO] key to switch between the different units. Use the [UNIT] key to activate or deactivate the unit for weighing mode. © PCE Instruments...
- Page 10 When starting the device, all loads within this range will be set to zero. - Zero range: When pressing the [ZERO] key, all loads within this range will be set to zero. - Taring range: Load range in which the tare function can be used. © PCE Instruments...
-
Page 11: Calibration
[PCS] key to increase the value of the selected digit and use the [UNIT] key to go to the next digit. After that, put the weight on top of the weighing platform. Wait for the reading to stabilize and press the [ZERO] key to confirm. After a successful calibration, the device automatically switches to weighing mode. © PCE Instruments... -
Page 12: Warranty
For countries outside the EU, batteries and devices should be disposed of in accordance with your local waste regulations. If you have any questions, please contact PCE Instruments. © PCE Instruments... - Page 13 PCE Instruments contact information Germany France Spain PCE Deutschland GmbH PCE Instruments France EURL PCE Ibérica S.L. Im Langel 4 76, Rue de la Plaine des Bouchers Calle Mayor, 53 D-59872 Meschede 67100 Strasbourg 02500 Tobarra (Albacete) Deutschland France España Tel.: +49 (0) 2903 976 99 0...
- Page 14 © PCE Instruments...
- Page 15 © PCE Instruments...
- Page 16 User manuals in various languages (German, French, Italian, Spanish, Portuguese, Dutch, Turkish, Polish, Russian, Chinese) can be downloaded here: www.pce-instruments.com Specifications are subject to change without notice. © PCE Instruments...
