Dahua HD IR Waterproof Fixed Network Camera Quick Start Guide
Step 6
Use inner hex screwdriver to loosen adjusting screw shown in Figure 2-2.
Step 7
Adjust the device in all possible directions, and set its monitoring direction.
Step 8
Use inner hex screwdriver to tighten the adjusting screws.

2.2 Install Micro SD Card

The Micro SD Card installation steps are shown as below:
Step 1
Loosen the screws on the lower cover and remove the cover, then you can see the installation
location of SD card.
Step 2
Insert the Micro SD Card into the SD card slot according to the Figure 2-3.
Step 3
Tighten the screws and fix the cover firmly.
Note:

Please install the Micro SD card according to the steps; it may cause SD card recognition
abnormity with improper installation.

The cover is involved in waterproof function; make sure tighten the cover firmly after
installation is completed.
Figure 2-2
5
