- Page 1 Dahua HD Megapixel Indoor Network Camera Quick Start Guide Dahua HD Megapixel Indoor Network Camera Quick Start Guide Version 1.0.0 Dahua Technology CO., LTD...
-
Page 2: Important Safeguards And Warnings
Dahua HD Megapixel Indoor Network Camera Quick Start Guide Welcome Thank you for purchasing our Network camera! This user’s manual is designed to be a reference tool for your system. Please read the following safeguard and warnings carefully before you use this series product! Please keep this user’s manual well for future reference! - Page 3 Dahua HD Megapixel Indoor Network Camera Quick Start Guide Please do not dismantle the device; there is no component which can be fixed by users themselves in the machine. It may cause water leakage or bad image for the device due to unprofessional dismantling.
- Page 4 Dahua HD Megapixel Indoor Network Camera Quick Start Guide Please refer to the disk for more details, check and download corresponding user’s manual and tool. Before installation, please open the package and check all the components are included. Contact your local retailer ASAP if something is broken in your package.
-
Page 5: Table Of Contents
Dahua HD Megapixel Indoor Network Camera Quick Start Guide Table of Contents Framework ........................1 Rear Panel ......................1 Dimension ......................3 Bidirectional talk ....................3 1.3.1 Device-end to PC ..................3 1.3.2 PC to the Device-end .................. 3 Alarm Setup ...................... 4 1.4.1 Alarm Input and Output Connection ............ -
Page 6: Framework
Dahua HD Megapixel Indoor Network Camera Quick Start Guide 1 Framework 1.1 Rear Panel Note: The figures are for reference only, which are used to know the functions of the rear panel. Different devices may have different structures of rear panel, please refer to the actual product for more details. - Page 7 Dahua HD Megapixel Indoor Network Camera Quick Start Guide function. WIFI Antenna port Connect to 4G/WIFI antenna, receiving wireless signal. Note: Only some models support this function. Alarm input port 1 Receive the on-off signal from the external alarm source.
-
Page 8: Dimension
Dahua HD Megapixel Indoor Network Camera Quick Start Guide Please make sure the device is securely earthed to prevent the thunderstorm strike when using the device. 1.2 Dimension The figures are for reference only, which are used to know the device dimension, please refer to the actual device for more details. -
Page 9: Alarm Setup
Dahua HD Megapixel Indoor Network Camera Quick Start Guide At the PC-end, speak via the speaker or MIC, and then you can get the audio from the earphone or sound box at the device-end. 1.4 Alarm Setup Note: Some devices don’t support alarm function, which can’t be applied to this chapter. -
Page 10: Ir Light Connection
Dahua HD Megapixel Indoor Network Camera Quick Start Guide Figure 1-4 Alarm input Please refer to the following figure for alarm output information. See Figure 1-5. Port NO and Port C composes an on-off button to provide the alarm output. - Page 11 Dahua HD Megapixel Indoor Network Camera Quick Start Guide Figure 1-6 IR light connection...
-
Page 12: Installation
Dahua HD Megapixel Indoor Network Camera Quick Start Guide 2 Installation 2.1 Lens Installation Figure 2-1 2.1.1 Auto Aperture Lens Installation Step 1 Remove the CCD protection cover on the device, aim the lens at the lens installation position, and turn the lens clockwise until it is installed firmly. -
Page 13: Sd Card/Sd Card Installation
Dahua HD Megapixel Indoor Network Camera Quick Start Guide 2.2 SD Card/SD Card Installation Figure 2-2 Step 1 Take down the SD card/4G card protection cover from the device. Step 2 Install the SD card/4G card into the device according to the installation direction shown in Figure 2-2. - Page 14 Dahua HD Megapixel Indoor Network Camera Quick Start Guide Figure 2-4 Install Cable: Step 1 Use the small slotted screwdriver to press the corresponding button of cable groove. Step 2 Insert the cable into the groove. Step 3 Release the screwdriver which presses the groove button and complete cable installation.
-
Page 15: Network Configuration
Dahua HD Megapixel Indoor Network Camera Quick Start Guide 3 Network Configuration The IP address of all the cameras is the same when leaving factory (default IP192.168.1.108), in order to make the camera get access to the network smoothly, please plan the useable IP segment reasonably according to the actual network environment. - Page 16 Dahua HD Megapixel Indoor Network Camera Quick Start Guide Figure 3-1 Step 3 Modify the camera IP address on the “Net” interface, click “Save” to finish modification. See Figure 3-2 for more details. Figure 3-2...
-
Page 17: Login Web Interface
Dahua HD Megapixel Indoor Network Camera Quick Start Guide 3.2 Login WEB Interface Note: Different devices may have different WEB interfaces, the figures below are just for reference, please refer to the document <<WEB Operation Manual>> in the disk and the actual interface for more details Step 1 Open IE and input the modified camera IP address in the address bar. - Page 18 Dahua HD Megapixel Indoor Network Camera Quick Start Guide Figure 3-4 Note: This quick start guide is for reference only. Slight difference may be found in user interface. All the designs and software here are subject to change without prior written notice.
