Page 1: Quick Start Guide
Dahua HD IR Vandal Proof Network Dome Camera Quick Start Guide Dahua HD IR Vandal Proof Network Dome Camera Quick Start Guide Version 1.0.0 Dahua Technology CO., LTD... -
Page 2: Important Safeguards And Warnings
Dahua HD IR Vandal Proof Network Dome Camera Quick Start Guide Welcome Thank you for purchasing our Network camera! This user’s manual is designed to be a reference tool for your system. Please read the following safeguard and warnings carefully before you use this series product! Please keep this user’s manual well for future reference! - Page 3 Dahua HD IR Vandal Proof Network Dome Camera Quick Start Guide Please do not touch the heat dissipation component of the device directly in order to avoid scald. Please do not dismantle the device; there is no component which can be fixed by users themselves in the machine.
- Page 4 Dahua HD IR Vandal Proof Network Dome Camera Quick Start Guide Note: Please refer to the disk for more details, check and download corresponding user’s manual and tool. Before installation, please open the package and check all the components are included.
-
Page 5: Table Of Contents
Dahua HD IR Vandal Proof Network Dome Camera Quick Start Guide Table of Contents Device Structure ........................1 Structure Components ....................1 Framework and Dimension ..................2 Alarm Setup ........................3 Device Installation ........................6 Installation Steps ......................6 Micro SD Card Installation ..................8 Network Configuration ...................... -
Page 6: Device Structure
Dahua HD IR Vandal Proof Network Dome Camera Quick Start Guide 1 Device Structure 1.1 Structure Components Note: The following figure is for reference only, which is used to know the components and cable port function. There are differences about structure components and cables between different models, please refer to the actual object for more details. -
Page 7: Framework And Dimension
Dahua HD IR Vandal Proof Network Dome Camera Quick Start Guide Port Port Name Function Network data in/out and PoE. Port 1 Internet access port Note: Some devices do not support PoE. Port 2 Power input port Connect to DC 12V power, input power. -
Page 8: Alarm Setup
Dahua HD IR Vandal Proof Network Dome Camera Quick Start Guide Figure 1-3 1.3 Alarm Setup Note: Only supported by some series products. Figure1-3 Alarm input, output description: Step 1 Connect alarm input device to the alarm input of I/O cable. - Page 9 Dahua HD IR Vandal Proof Network Dome Camera Quick Start Guide Please refer to the following figure for alarm input information. See Figure 1-4. Alarm input: When the input signal is idle or grounded, the device can collect the different statuses of the alarm input port.
- Page 10 Dahua HD IR Vandal Proof Network Dome Camera Quick Start Guide Mode A: Level application. Alarm output high and low level, alarm output is OC; it needs to increase pull-up resistance externally to work normally. Max external pull-up level is 5V, max port current is 5mA.
-
Page 11: Device Installation
Dahua HD IR Vandal Proof Network Dome Camera Quick Start Guide 2 Device Installation 2.1 Installation Steps Note: Before the installation, please make sure the installation environments can at least support 3x weight of the camera and the bracket. - Page 12 Dahua HD IR Vandal Proof Network Dome Camera Quick Start Guide Aim the screw fix holes on the dome pedestal at the expansion bolt fix hole on the installation surface, then tighten four self-tapping screws into the expansion bolts and secure firmly, and fix the dome on the installation surface.
-
Page 13: Micro Sd Card Installation
Dahua HD IR Vandal Proof Network Dome Camera Quick Start Guide 2.2 Micro SD Card Installation Note: Please cut off the device power and turn off the device before installing Micro SD card. Long press the “Reset Button” for 5~10 seconds shown in Figure 2-4, then it can realize the device reset function. -
Page 14: Network Configuration
Dahua HD IR Vandal Proof Network Dome Camera Quick Start Guide 3 Network Configuration The IP address of all the cameras is the same when leaving factory (default IP192.168.1.108), in order to make the camera get access to the network smoothly, please plan the useable IP segment reasonably according to the actual network environment. -
Page 15: Login Web Interface
Dahua HD IR Vandal Proof Network Dome Camera Quick Start Guide Figure 3-1 Step 3 Modify the camera IP address on the “Net” interface, click “Save” to finish modification. See Figure 3-2 for more details. Figure 3-2 3.2 Login WEB Interface... - Page 16 Dahua HD IR Vandal Proof Network Dome Camera Quick Start Guide Figure 3-3 Step 3 Install controls according to the system prompt; see Figure 3-4 for the WEB main interface. Please modify the administrator password as soon as possible after you successfully logged in.
- Page 17 Dahua HD IR Vandal Proof Network Dome Camera Quick Start Guide Note: This quick start guide is for reference only. Slight difference may be found in user interface. All the designs and software here are subject to change without prior written notice.
