Page 1: Quick Start Guide
Dahua HD IR Vari-focal Dome Network Camera Quick Start Guide Dahua HD IR Vari-focal Dome Network Camera Quick Start Guide Version 1.0.0 Zhejiang Dahua Vision Technology CO., LTD... -
Page 2: Important Safeguards And Warnings
Dahua HD IR Vari-focal Dome Network Camera Quick Start Guide Welcome Thank you for purchasing our Network camera! This user’s manual is designed to be a reference tool for your system. Please read the following safeguard and warnings carefully before you use this series product! Please keep this user’s manual well for future reference! - Page 3 Dahua HD IR Vari-focal Dome Network Camera Quick Start Guide Please do not dismantle the device; there is no component which can be fixed by users themselves in the machine. It may cause water leakage or bad image for the device due to unprofessional dismantling.
- Page 4 Dahua HD IR Vari-focal Dome Network Camera Quick Start Guide There may be deviation between the actual value of some data and the value provided in the manual due to the reasons such as the real environment is not stable and so on. Please refer to the company’s final explanation if there is any doubt or dispute.
-
Page 5: Table Of Contents
Dahua HD IR Vari-focal Dome Network Camera Quick Start Guide Table of Contents Structure ............................. 1 Components ........................1 Framework and Dimension ..................2 Alarm Setup ........................3 Device Installation ........................5 Network Configuration ......................10 Modify IP Address ...................... 10... -
Page 6: Structure
Dahua HD IR Vari-focal Dome Network Camera Quick Start Guide 1 Structure Note: The following figures are for reference only, which are used to know each structure component and cable port functions. There are differences about wire structure for some product models, please refer to the actual object for more details. -
Page 7: Framework And Dimension
Dahua HD IR Vari-focal Dome Network Camera Quick Start Guide Port Port Name Note Power input port Port 3 Connect to DC 12V power, input power. Alarm signal input/output (optional, Port 4 I/O port supported by some product models) Network data in/out and PoE. -
Page 8: Alarm Setup
Dahua HD IR Vari-focal Dome Network Camera Quick Start Guide 1.3 Alarm Setup Note: It is only supported by some series products. Figure 1-3 Alarm input, output description: Step 1 Connect alarm input device to the alarm input of I/O cable. - Page 9 Dahua HD IR Vari-focal Dome Network Camera Quick Start Guide Please refer to the following figure for alarm output information. See Figure 1-5 and Figure 1-6. Figure 1-5 Figure 1-6 Mode A: Level application. Alarm output high and low level, alarm output is OC; it needs to increase pull-up resistance externally to work normally.
-
Page 10: Device Installation
Dahua HD IR Vari-focal Dome Network Camera Quick Start Guide 2 Device Installation Note: The following installation figures are for reference only; please refer to the figure according to the actual product. Before the installation, please make sure the installation surface can at least support 3x weight of the camera and the bracket. - Page 11 Dahua HD IR Vari-focal Dome Network Camera Quick Start Guide Figure 2-2 Motorized Vari-focal Camera Step 1 Use inner hex wrench in the accessories bag to open dome enclosure by unfastening three inner hex screws on the enclosure. Step 2 Install SD card, which is shown in Figure 2-3.
- Page 12 Dahua HD IR Vari-focal Dome Network Camera Quick Start Guide If the device needs to use WPS function, short press “Reset” button for 1~2 seconds when the device is power on, press the WPS button of the router, generally the device can be connected to the corresponding router within 1 minute (only supported by some models).
- Page 13 Dahua HD IR Vari-focal Dome Network Camera Quick Start Guide Figure 2-5 Hold the rotation bracket on both sides, turn the rotation bracket horizontally, adjust the lens direction horizontally to the targeted position; loosen the two hand screws on the both sides of the rotation...
- Page 14 Dahua HD IR Vari-focal Dome Network Camera Quick Start Guide Step 6 Take up the dome enclosure, put it back on the camera properly regarding to screw and hole, and fasten the three inner hex screws with wrench. So far the installation is completed.
-
Page 15: Network Configuration
Dahua HD IR Vari-focal Dome Network Camera Quick Start Guide 3 Network Configuration The IP address of all the cameras is the same when leaving factory (default IP192.168.1.108), in order to make the camera get access to the network smoothly, please plan the useable IP segment reasonably according to the actual network environment. -
Page 16: Login Web Interface
Dahua HD IR Vari-focal Dome Network Camera Quick Start Guide Step 3 Modify the camera IP address on the “Net” interface, click “Save” to finish modification. See Figure 3-2 for more details. Figure 3-2 3.2 Login WEB Interface Note: Different devices may have different WEB interfaces, the figures below are just for reference, please refer to the document <<WEB Operation Manual>>... - Page 17 Dahua HD IR Vari-focal Dome Network Camera Quick Start Guide Figure 3-3 Step 3 Install controls according to the system prompt; see Figure 3-4 for the WEB main interface. Please modify the administrator password as soon as possible after you successfully logged in.
- Page 18 Dahua HD IR Vari-focal Dome Network Camera Quick Start Guide Note This user’s manual is for reference only. Slight difference may be found in user interface. All the designs and software here are subject to change without prior written notice.
