Technical Manual
DS-7300HFI-S Embedded Net DVR
Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.

Advertisement

loading
Need help?

Need help?

Do you have a question about the ds-7300hfi-s and is the answer not in the manual?

Questions and answers

Related Manuals for HIKVISION ds-7300hfi-s

Summary of Contents for HIKVISION ds-7300hfi-s

  • Page 1 Technical Manual DS-7300HFI-S Embedded Net DVR Technical Manual ©2006 – 2010 by HIKVISION. All rights reserved.
  • Page 2 HIKVISION and then only on the condition that this notice is included in any such reproduction. No information as to the contents or subject...
  • Page 3 Technical Manual Overview DS-7300HFI-S embedded net DVR is an excellent digital surveillance product adopts embedded Linux OS and DaVinci Processor, along with the most advanced technology in the Information technology Industry such as video encoding/decoding, hard disk recording and TCP/IP transmission. The firmware is burned into the flash, making it more stable and reliable than software programs running from a standard disk drive.

  • Page 4: Order Models

    Technical Manual Order Models DS-7304HFI-S, DS-7308HFI-S, DS-7316HFI-S Note: 1. The default DVRs are without HDD or CD-R/W. 2. A factory recommended HDD should be used for this device. ©2006 – 2010 by HIKVISION. All rights reserved.

  • Page 5: Main Features

    Support digital zoom by using mouse when in PTZ control mode Different channels can be set different recording expired time Support normal and event video encoding parameters Support redundant recording Support hard disk group management Support NTP, SADP and SMTP protocols ©2006 – 2010 by HIKVISION. All rights reserved.
  • Page 6  Multiple recording types, including manual, continuous, alarm, motion, motion | alarm and motion & alarm recording, etc.  8 recording time periods with separate recording types.  Pre-record and Post-record time for alarm and motion detection, and ©2006 – 2010 by HIKVISION. All rights reserved.
  • Page 7 Remote access and configuration of parameters; remote import/export  of device configuration parameters. Remote access of device running status, system log and alarm status.  Remote control of DVR via button operation.  ©2006 – 2010 by HIKVISION. All rights reserved.
  • Page 8  Voice talk and broadcast.  Built-in WEB Server.  Development Provide Windows and Linux SDK  Provide software source code as demo  Provide development support and application system training  ©2006 – 2010 by HIKVISION. All rights reserved.
  • Page 9 ⑧ LAN Interface ⑨ USB Interface ⑩ VIDEO LOOP OUT ⑪ Termination Switch ⑫ RS-485 Interface, KB Control Interface, ALARM IN, ALARM OUT ⑬ GND ⑭ 100~240VAC Power Supply ⑮ POWER On/Off ©2006 – 2010 by HIKVISION. All rights reserved.
  • Page 10 ⑦ VGA Interface ⑧ RS-232 Interface ⑨ LAN Interface ⑩ USB Interface ⑪ Termination Switch ⑫ RS-485 Interface, KB Control Interface, ALARM IN, ALARM OUT ⑬ GND ⑭ 100~240VAC Power Supply ⑮ POWER On/Off ©2006 – 2010 by HIKVISION. All rights reserved.

  • Page 11: Specifications

    Power supply 100~240VAC, 6.3A, 50~60Hz Consumption ≤50W(without hard disk or DVD-R/W) Working -10℃~+55℃ temperature Others Working 10%~90% humidity Chassis 19” standard 1.5U chassis Size(mm) 70mm(H)×440mm(W)× 390mm(D) Weight ≤8Kg(without hard disk or DVD-R/W) ©2006 – 2010 by HIKVISION. All rights reserved.
  • Page 12 Technical Manual ©2006 – 2010 by HIKVISION. All rights reserved.
