- Page 1 WRIST BLOOD PRESSURE MONITOR MD 10544 Item #7221 Two-Year Limited Warranty Toll Free Customer Care: 1-866-633-4660 0366 INSTRUCTION MANUAL Distributed by MEDION Please fold out!
-
Page 2: Package Contents
DESCRIPTION OF PARTS PACKAGE CONTENTS 1. Wrist blood pressure monitor 2. Storage case 3. 2 AAA batteries 4. Instruction Manual TECHNICAL DATA Measurement method: Oscillometric Measuring range: Blood pressure: 40 ~ 250mmHg Pulse: 40 ~ 199 beats/min. Power supply: 2 AAA batteries Display: Memory spaces: 2 x 50 measurement results... -
Page 3: Table Of Contents
Table of contents INTRODUCTION ......4 SAFETY INSTRUCTIONS ......5 COMPLIANCE WITH FCC RULES . -
Page 4: Introduction
INTRODUCTION Thank you for the trust you have placed in us! Congratulations on the purchase of your new wrist blood pressure monitor! We are convinced that you will be delighted with this modern piece of equipment. In order to guarantee the optimum operation and performance of this device at all times and in order to protect your personal safety, we would make the following suggestions: •... -
Page 5: Safety Instructions
SAFETY INSTRUCTIONS • Blood pressure measurements should only be interpreted by a physician or a trained health care professional who is familiar with your medical history. Through regular use of this device and recording of your measurements, you can keep your physician informed of the changes in your blood pressure. -
Page 6: Compliance With Fcc Rules
COMPLIANCE WITH FCC RULES This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 7: Medion Limited Warranty
MEDION LIMITED WARRANTY Medion warrants that the product accompanied by this limited warranty is free from manufacturing defects in material or workmanship for a period of 24 months from the date of original purchase. This warranty only applies to the original purchaser of the product. The limited warranty period also applies to any implied warranties that may exist under applicable law. -
Page 8: About This Device
ABOUT THIS DEVICE The device is used to measure blood pressure at the wrist. It is suitable for healthy people above 12 years of age and can be used to make comparative measurements – especially during sporting activities. If the values obtained give you cause to be concerned about your health, seek medical advice. -
Page 9: First Operation
FIRST OPERATION Remove the cover of the battery compartment in the direction of the arrow. Insert two AAA batteries. Pay attention to the polarity (the negative terminal faces the spring). Close the battery compartment. Replace the batteries: – if the battery icon appears on the display, –... -
Page 10: The Display
THE DISPLAY User icon 1 or 2; select the user with the button. The battery icon appears if the batteries need to be changed. This symbol appears if the average blood pressure value is shown. The pulse sign appears when the pulse is displayed. ) Error notifications for operating and device errors. -
Page 11: Blood Pressure Indicator
BLOOD PRESSURE INDICATOR The World Health Organization (WHO) and National High Blood Pressure Education Program Coordinating Committee have developed a blood pressure standard, classifying blood pressure ranges into 4 stages. This unit is equipped with an innovative blood pressure classification indicator, which visually indicates the assumed risk level (prehypertension/ stage 1 hypertension/ stage 2 hypertension) of the result for each measurement. -
Page 12: Attaching The Cuff
ATTACHING THE CUFF Attach the cuff in such a way that it is approx. 0.2 - 0.4 inches away from the palm of your left hand (see fig. B). Ensure that no articles of clothing are trapped in the cuff. Hold the lower part of the cuff as shown in fig. -
Page 13: Correct Measurement
CORRECT MEASUREMENT • Place your elbow on the table or other supporting surface, and hold your arm so that the cuff is at heart height. • To measure your blood pressure, sit comfortably on a chair, take 5 or 6 deep breaths and relax. •... -
Page 14: Carrying Out Measurements
CARRYING OUT MEASUREMENTS Attach the cuff to your wrist as described above. Press the ON/OFF button. All indicators are displayed for a few seconds on the screen; then the screen shows the time and the most recently selected memory space. Measurement starts automatically;... -
Page 15: Storing Values
STORING VALUES This device contains memory storage for up to 2 individual users . Up to 50 measurements can be stored for each user. You can also display the average values of the stored measurements. Before measuring, select the user with the DUAL USER button. -
Page 16: Cleaning And Maintenance
CLEANING AND MAINTENANCE Notes on maintenance It is recommended that you check the usability of the unit every three years or after repairs. According to the "Operating Regulations for Medical Products," a technical measurement check must take place every 2 years if the device is used for commercial purposes. Cleaning/storage Do not clean the device with solvents that contain alcohol. -
Page 17: Environmental Protection/Disposal
ENVIRONMENTAL PROTECTION/ DISPOSAL The unit is battery-operated. Do not dispose of dead batteries in the household trash. After the end of its life, ensure to dispose the product beneficial to the environment. Do not dispose the product in the household trash. -
Page 18: Error Messages
ERROR MESSAGES Defect Possible cause and solution EE / E1 / E2 The cuff is not attached correctly. Please refer to the notes in these instructions. Movement during measurement. Do not move or speak during measurement The device is not able to measure the values appropriately. Take the measurement again after a 5 minute break. -
Page 19: Guidelines And Manufacturer's Declaration For Electromagnetic Emissions (Emc)
EMISSIONS (EMC) Guidelines and manufacturer's declaration – electromagnetic emissions Model MD 10544 is designed for operation in an environment as described below: The customer or user of Model MD 10544 should ensure that it is operated in such an environment. - Page 20 HF transmitters we recommend an on-site inspection . If the field determined at the location of Model MD 10544 exceeds the pass level stated above the Model MD 10544 must be checked for normal operation at each point of use.
- Page 21 HF telecommunication devices and the [DEVICE or SYSTEM] Model MD 10544 is intended for operation in an electromagnetic environment in which the HF interference is controlled . The customer or user of Model MD 10544 can help to avoid electromagnetic interference by adhering to the minimum distance between portable and mobile HF telecommunication devices (transmitters) and the Model MD 10544 –...
