30CA COMPACT
30C/CA COMPACT I
Instruction manual ..................... 2 - 13
GB
Betriebsanweisung...................... 14 - 25
D
Manuel d'Instructions ................ 26 - 37
F
Gebruikershandleiding................ 38 - 49
NL
Manual de Instrucciones ............. 50 - 61
E
Manuale di istruzioni .................. 62 - 73
I
Manual de Instruções .................. 74 - 85
P
GR
ã÷åéñéäéï ïäçãéùí .........................
86 - 97
T E C H N O L O G I E S

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 30CA COMPACT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Alto 30CA COMPACT

Summary of Contents for Alto 30CA COMPACT

  • Page 1 Hauptverwaltung P.O. Box 2122 Wap Reinigungssysteme GmbH & Co JAPAN AUSTRALIA D-89287 Bellenberg ALTO Danmark A/S Japan Tel. (++27) 11 97 57 06 0 Fax (++27) 11 39 43 08 1 ALTO Overseas Inc. Guido-Oberdorfer-Straße 2-8 Representative Office 1B/8 Resolution Drive Tel.

  • Page 3: Table Of Contents

    Health and safety at Work Act 1974 Guidance Note P.M. 29 United Kingdom: It has always been the ALTO policy to ensure that all ALTO products are safe and without risk to health or safety when properly used. ALTO always endeavour to provide customers with every available item of information on the product they are using by the issue of descriptive instruction manuals, literature and brochures which are constantly being updated and reviewed.

  • Page 4: Survey Of Models

    1.0 Survey of models 1.1 Model tag DK-9560 HADSUND This ALTO high pressure washer has the model TLF . (+45) 7218 2100 designation »30CA COMPACT / MODEL POWER 30C/CA COMPACT I« and the type designation TYPE FREQUENCY SERIAL NO VOLTAGE »P478/P452«.

  • Page 5: Instructions For Use

    IEC Wiring Regulations. Extension cable If you want a wider radius of action ALTO recommend you to use an extension hose instead of an exten- sion cable. If you want to apply an extension cable when operating a three-phase high pressure washer, we recommend you to use the cable dimensions mentioned below: (The use of the stated cable dimen- sions implies that the mains voltage is stable and corresponding to the voltage stated on the model tag.)

  • Page 6: Safety Devices On The Machine

    6. Always unplug when cleaning and maintaining the machine. 7. If the electric cable is damaged, it must be replaced by ALTO trained service personnel or a similarly trained person to avoid a dangerous situation (NB! Type Y connection: A special tool is required for the disassemblance of the machine).

  • Page 7: Operating Instructions

    If there is a risk of impurities (i.e. running sand) in the inlet water, an external sand filter should be mounted beyond the internal filter of the cleaner. Please contact your ALTO distributor for further information. NOTE: Connection to the public mains according to regulations.

  • Page 8: Spray Handle - Accessories

    Insert the nipple of the spray lance (2) in the quick coupling and release the trigger. Pul forward the spray lance or any other accessory to ensure correct mounting before starting the cleaner. Detergents - dosing unit Only use ALTO detergents. Use of aggressive detergents may damage equipment and affect the environment.

  • Page 9: Operation

    Operating instructions 3.3 Operation Always hold the spray lance with both hands! Always lock the spray handle when the cleaner is not in operation. Activate the high pressure washer by releasing the trigger of the spray handle (1). When the cleaner is not in use, secure the spray handle by turning the safety knob (2) into pos.

  • Page 10: Placement Of Accessories, Hose And Cable

    Operating instructions 3.6 Placement of accessories, hose and cable Spray lance in support for spray lance (1) Electric cable and high pressure hose on the handle (2) Container in support for container (3). Place the spray lance in the support for spray lance (1), nozzle facing upwards. Wind up the electric cable and place it on the transport handle (2).

  • Page 11: Fields Of Application And Working Methods

    4.3 Detergents The most efficient cleaning is reached with detergents in conjunction with the high pressure cleaning. For that purpose ALTO can offer you a series of products specially developed for high pressure cleaning, among other fields within: Cleaning of cars, caravans, boats etc.

  • Page 12: Working Methods

    Max. suction height of 1 m is reached with cold water up to 10°C. If there is a risk of impurities (i.e. running sands) in the inlet water, an external suction filter should be mounted beyond the internal filter of the cleaner. Contact your ALTO distributor for further information.

  • Page 13: Maintenance

    6.0 Maintenance Your ALTO high pressure washer is maintenance-free and therefore no special qualifications are required for the daily use. However, it applies to the most exposed components that a minimum of maintenance ensures a prolonged and problem-free operation. Therefore it will be a good idea to make a habit of the following: Before mounting the water inlet hose and the high pressure hose, the couplings should be cleaned free of dust and sand.

  • Page 14: Troubleshooting And Correction

    Pump, high pressure hose, or Contact your local ALTO service department. irregularly by itself spray handle leaky Should other malfunctions occur than those mentioned above, please contact the nearest ALTO service organisation. Customer Services (only UK): WAP/ALTO Cleaning Systems Ltd.

  • Page 15: Functional Description

    8.0 Functional description High pressure pump, water system The water passes from the inlet nipple (a) through a water filter (b) and into the high pressure pump (c). The high pressure pump is a piston pump with internal valve systems ensuring that the pump will supply an exactly measured out water volume per unit of time. The water circulates from the pump (c) to the automatic start/stop valve system (g).
  • Page 17 8.0 Descripción de funcionamiento Bomba de alta presión, sistema de circulación del agua El agua pasa desde la boquilla de entrada (a) a través de un filtro de agua (b) hasta la bomba de alta presión (c). La bomba de alta presión es una bomba de pistón con sistemas de válvulas internos que aseguran que la bomba suministre un volumen de agua exacto por unidad de tiempo.

This manual is also suitable for:

30c/ca compact i
