SERVICE MANUAL
ACTIVE SPEAKER SYSTEM
t
• Replace this Service manual with "Revision Publishing" when it is issued.
r
TS-SLW700
TS-SLW701
S/M Code No. 09-018-449-2T1
U,K
EZ
u
a
o

Advertisement

loading
Need help?

Need help?

Do you have a question about the TS-SLW700 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aiwa TS-SLW700

Summary of Contents for Aiwa TS-SLW700

  • Page 1 TS-SLW700 TS-SLW701 SERVICE MANUAL ACTIVE SPEAKER SYSTEM • Replace this Service manual with “Revision Publishing” when it is issued. S/M Code No. 09-018-449-2T1...

  • Page 2: Parts List

    PARTS CODE K NO. DESCRIPTION SUFFIX MODEL NAME X AI(1) 0001 88-710-939-810 0E CAP,M 0.22-50 J TFL TS-SLW700 X AI(1) 0001 88-710-939-810 0E CAP,M 0.22-50 J TFL EZSN TS-SLW701 0 X AI(1) 0001 88-710-939-810 0E CAP,M 0.22-50 J TFL TS-SLW700 X AI(1) 0002 88-700-800-810 0E CAP,M 0.012-50 J AMZV...
  • Page 3 PARTS CODE K NO. DESCRIPTION SUFFIX MODEL NAME 0 O AI(1) 0116 87-010-186-080 0E C-CAP,S 4700P-50 K B C2012 TS-SLW700 O AI(1) 0119 87-012-368-080 0E C-CAP,S 0.1-50 Z F TS-SLW700 O AI(1) 0119 87-012-368-080 0E C-CAP,S 0.1-50 Z F EZSN...
  • Page 4 O AI(1) 0211 87-012-140-080 0E C-CAP,S 470P-50 J CH EZSN TS-SLW701 0 O AI(1) 0211 87-012-140-080 0E C-CAP,S 470P-50 J CH TS-SLW700 O AI(1) 0212 87-012-140-080 0E C-CAP,S 470P-50 J CH TS-SLW700 O AI(1) 0212 87-012-140-080 0E C-CAP,S 470P-50 J CH...
  • Page 5 PARTS CODE K NO. DESCRIPTION SUFFIX MODEL NAME O AI(1) 0320 87-012-140-080 0E C-CAP,S 470P-50 J CH TS-SLW700 O AI(1) 0320 87-012-140-080 0E C-CAP,S 470P-50 J CH EZSN TS-SLW701 0 O AI(1) 0320 87-012-140-080 0E C-CAP,S 470P-50 J CH TS-SLW700...
  • Page 6 K NO. DESCRIPTION SUFFIX MODEL NAME 0 O AI(1) 0508 87-010-384-080 0E CAP,E 100-25 M 11L SME TS-SLW700 O AI(1) 0509 87-010-384-080 0E CAP,E 100-25 M 11L SME TS-SLW700 O AI(1) 0509 87-010-384-080 0E CAP,E 100-25 M 11L SME EZSN...
  • Page 7 UNIT NAME REF NO. PARTS CODE K NO. DESCRIPTION SUFFIX MODEL NAME S AI(1) 0109 87-020-465-080 0E DIODE,1SS133 TS-SLW700 S AI(1) 0109 87-020-465-080 0E DIODE,1SS133 EZSN TS-SLW701 0 S AI(1) 0109 87-020-465-080 0E DIODE,1SS133 TS-SLW700 S AI(1) 0110 87-020-465-080 0E DIODE,1SS133...
  • Page 8 UNIT NAME REF NO. PARTS CODE K NO. DESCRIPTION SUFFIX MODEL NAME 0 S AI(1) 0401 87-020-465-080 0E DIODE,1SS133 TS-SLW700 S AI(1) 0402 87-020-465-080 0E DIODE,1SS133 TS-SLW700 S AI(1) 0402 87-020-465-080 0E DIODE,1SS133 EZSN TS-SLW701 0 S AI(1) 0402 87-020-465-080 0E DIODE,1SS133...
  • Page 9 DESCRIPTION SUFFIX MODEL NAME S AI(1) 0511 87-A40-345-080 0E ZENER,MTZJ10C EZSN TS-SLW701 0 S AI(1) 0511 87-A40-345-080 0E ZENER,MTZJ10C TS-SLW700 S AI(1) 0513 87-020-465-080 0E DIODE,1SS133 TS-SLW700 S AI(1) 0513 87-020-465-080 0E DIODE,1SS133 EZSN TS-SLW701 0 S AI(1) 0513 87-020-465-080 0E DIODE,1SS133...
  • Page 10 UNIT NAME REF NO. PARTS CODE K NO. DESCRIPTION SUFFIX MODEL NAME X AI(1) JR 0003 88-118-000-080 0E C-JUMPER,S TS-SLW700 X AI(1) JR 0003 88-118-000-080 0E C-JUMPER,S EZSN TS-SLW701 0 X AI(1) JR 0003 88-118-000-080 0E C-JUMPER,S TS-SLW700 X AI(1)
  • Page 11 UNIT NAME REF NO. PARTS CODE K NO. DESCRIPTION SUFFIX MODEL NAME S AI(1) 0123 87-A30-074-080 0E C-TR,RT1P 141C TS-SLW700 S AI(1) 0123 87-A30-074-080 0E C-TR,RT1P 141C EZSN TS-SLW701 0 S AI(1) 0123 87-A30-074-080 0E C-TR,RT1P 141C TS-SLW700 S AI(1)
  • Page 12 REF NO. PARTS CODE K NO. DESCRIPTION SUFFIX MODEL NAME 0 S AI(1) 0225 87-A30-268-040 0E C-TR,2SA1514K(S) TS-SLW700 0 S AI(1) 0226 87-A30-075-080 0E C-TR,2SA1235F TS-SLW700 0 S AI(1) 0301 87-A30-257-080 0E C-TR,2SD1306E TS-SLW700 0 S AI(1) 0302 87-A30-075-080 0E C-TR,2SA1235F...
  • Page 13 UNIT NAME REF NO. PARTS CODE K NO. DESCRIPTION SUFFIX MODEL NAME 0 S AI(1) 0415 87-A30-106-070 0E C-TR,CMBT5551 TS-SLW700 S AI(1) 0417 87-A30-072-080 0E C-TR,RT1P 144C TS-SLW700 S AI(1) 0417 87-A30-072-080 0E C-TR,RT1P 144C EZSN TS-SLW701 0 S AI(1)
  • Page 14 REF NO. PARTS CODE K NO. DESCRIPTION SUFFIX MODEL NAME 0 X AI(1) 0002 88-118-223-080 0E C-RES,S 22K-1/10W J TS-SLW700 X AI(1) 0003 88-118-563-080 0E C-RES,S 56K-1/10W J TS-SLW700 X AI(1) 0003 88-118-563-080 0E C-RES,S 56K-1/10W J EZSN TS-SLW701 0 X AI(1)
  • Page 15 UNIT NAME REF NO. PARTS CODE K NO. DESCRIPTION SUFFIX MODEL NAME 0 X AI(1) 0122 88-121-222-080 0E RES,2.2K-1/8W J TS-SLW700 X AI(1) 0123 88-121-222-080 0E RES,2.2K-1/8W J TS-SLW700 X AI(1) 0123 88-121-222-080 0E RES,2.2K-1/8W J EZSN TS-SLW701 0 X AI(1) 0123 88-121-222-080 0E RES,2.2K-1/8W J...
  • Page 16 REF NO. PARTS CODE K NO. DESCRIPTION SUFFIX MODEL NAME X AI(1) 0146 88-118-332-080 0E C-RES,S 3.3K-1/10W J TS-SLW700 X AI(1) 0146 88-118-332-080 0E C-RES,S 3.3K-1/10W J EZSN TS-SLW701 X AI(1) 0147 88-118-393-080 0E C-RES,S 39K-1/10W J TS-SLW700 X AI(1)
  • Page 17 PARTS CODE K NO. DESCRIPTION SUFFIX MODEL NAME 0 X AI(1) 0172 88-118-472-080 0E C-RES,S 4.7K-1/10W J TS-SLW700 0 X AI(1) 0177 88-118-473-080 0E C-RES,S 47K-1/10W J TS-SLW700 0 X AI(1) 0178 88-118-473-080 0E C-RES,S 47K-1/10W J TS-SLW700 0 X AI(1)
  • Page 18 REF NO. PARTS CODE K NO. DESCRIPTION SUFFIX MODEL NAME 0 X AI(1) 0217 88-118-101-080 0E C-RES,S 100-1/10W J TS-SLW700 X AI(1) 0218 88-118-101-080 0E C-RES,S 100-1/10W J TS-SLW700 X AI(1) 0218 88-118-101-080 0E C-RES,S 100-1/10W J EZSN TS-SLW701 0 X AI(1)
  • Page 19 MODEL NAME O AI(1) 0241 87-A00-915-050 -- RES,M/F 0.33-2W J EZSN TS-SLW701 0 O AI(1) 0241 87-A00-915-050 -- RES,M/F 0.33-2W J TS-SLW700 O AI(1) 0242 87-A00-915-050 -- RES,M/F 0.33-2W J TS-SLW700 O AI(1) 0242 87-A00-915-050 -- RES,M/F 0.33-2W J EZSN...
  • Page 20 PARTS CODE K NO. DESCRIPTION SUFFIX MODEL NAME 0 X AI(1) 0265 88-118-683-080 0E C-RES,S 68K-1/10W J TS-SLW700 0 X AI(1) 0266 88-118-105-080 0E C-RES,S 1M-1/10W J TS-SLW700 0 X AI(1) 0267 88-118-103-080 0E C-RES,S 10K-1/10W J TS-SLW700 0 X AI(1)
  • Page 21 REF NO. PARTS CODE K NO. DESCRIPTION SUFFIX MODEL NAME 0 O AI(1) 0325 87-A00-257-080 0E RES,M/F 0.15-1W J TS-SLW700 O AI(1) 0326 87-A00-915-050 -- RES,M/F 0.33-2W J TS-SLW700 O AI(1) 0326 87-A00-915-050 -- RES,M/F 0.33-2W J EZSN TS-SLW701 0 O AI(1) 0326 87-A00-915-050 -- RES,M/F 0.33-2W J...
  • Page 22 REF NO. PARTS CODE K NO. DESCRIPTION SUFFIX MODEL NAME 0 X AI(1) 0412 88-118-153-080 0E C-RES,S 15K-1/10W J TS-SLW700 0 X AI(1) 0413 88-118-333-080 0E C-RES,S 33K-1/10W J TS-SLW700 X AI(1) 0413 88-118-682-080 0E C-RES,S 6.8K-1/10W J TS-SLW700 X AI(1) 0413 88-118-682-080 0E C-RES,S 6.8K-1/10W J...
  • Page 23 MODEL NAME X AI(1) 0436 88-118-473-080 0E C-RES,S 47K-1/10W J EZSN TS-SLW701 0 X AI(1) 0436 88-118-473-080 0E C-RES,S 47K-1/10W J TS-SLW700 X AI(1) 0437 88-118-103-080 0E C-RES,S 10K-1/10W J TS-SLW700 X AI(1) 0437 88-118-103-080 0E C-RES,S 10K-1/10W J EZSN...
  • Page 24 UNIT NAME REF NO. PARTS CODE K NO. DESCRIPTION SUFFIX MODEL NAME X AI(1) 0501 88-118-000-080 0E C-JUMPER,S TS-SLW700 X AI(1) 0501 88-118-000-080 0E C-JUMPER,S EZSN TS-SLW701 0 X AI(1) 0501 88-118-000-080 0E C-JUMPER,S TS-SLW700 X AI(1) 0502 88-118-333-080 0E C-RES,S 33K-1/10W J...
  • Page 25 REF NO. PARTS CODE K NO. DESCRIPTION SUFFIX MODEL NAME 0 X AI(1) 0524 88-118-101-080 0E C-RES,S 100-1/10W J TS-SLW700 X AI(1) 0525 88-121-103-080 0E RES,10K-1/8W J TS-SLW700 X AI(1) 0525 88-121-103-080 0E RES,10K-1/8W J EZSN TS-SLW701 0 X AI(1)
  • Page 26 SUFFIX MODEL NAME X AI(1) 0548 88-121-103-080 0E RES,10K-1/8W J EZSN TS-SLW701 0 X AI(1) 0548 88-121-103-080 0E RES,10K-1/8W J TS-SLW700 X AI(1) 0549 88-118-471-080 0E C-RES,S 470-1/10W J TS-SLW700 X AI(1) 0549 88-118-471-080 0E C-RES,S 470-1/10W J EZSN TS-SLW701...
  • Page 27 EZSN TS-SLW701 X APPEARANCE 8B-YPA-015-010 -- LBL,CX-LDV700 TS-SLW700 0 X ASSY CODE PB-YPA-913-070 -- TS-SLW700USN TS-SLW700 X ASSY CODE PB-YPA-933-070 -- TS-SLW700 KSN TS-SLW700 X ASSY CODE PB-YPA-943-070 -- TS-SLW701 EZSN EZSN TS-SLW701 X CB 87-033-220-010 0E PIN,DIA1 COATING TS-SLW700...
  • Page 28 CN 0104 87-009-317-010 0E CONN,11P V 51048 EZSN TS-SLW701 0 O CB CN 0104 87-009-317-010 0E CONN,11P V 51048 TS-SLW700 0 O CB CN 0109 87-009-345-010 0E CONN,2P H WHT PH TS-SLW700 ! O CB CN 0109 87-009-346-010 0E CONN,3P H WHT PH...
  • Page 29 UNIT NAME REF NO. PARTS CODE K NO. DESCRIPTION SUFFIX MODEL NAME O CB 0401 87-003-383-010 1A COIL,1UH K TS-SLW700 O CB 0401 87-003-383-010 1A COIL,1UH K EZSN TS-SLW701 0 O CB 0401 87-003-383-010 1A COIL,1UH K TS-SLW700 S CB...
  • Page 30 UNIT NAME REF NO. PARTS CODE K NO. DESCRIPTION SUFFIX MODEL NAME X CB 0006 8B-YPA-635-010 -- WIRE,JUMP D TS-SLW700 X CB 0006 8B-YPA-635-010 -- WIRE,JUMP D EZSN TS-SLW701 0 O CB 0007 8B-YPA-631-010 -- F-CABLE,2P JACK TS-SLW700 X CB...
  • Page 31 K NO. DESCRIPTION SUFFIX MODEL NAME X MECHANICAL 8B-YP9-207-010 -- CUSH,DUCT EZSN TS-SLW701 0 X MECHANICAL 8B-YP9-207-010 -- CUSH,DUCT TS-SLW700 O MECHANICAL 8B-YP9-208-010 -- FOOT,BOX TS-SLW700 O MECHANICAL 8B-YP9-208-010 -- FOOT,BOX EZSN TS-SLW701 0 O MECHANICAL 8B-YP9-208-010 -- FOOT,BOX TS-SLW700...
  • Page 32 K NO. DESCRIPTION SUFFIX MODEL NAME X PWB 8B-YPA-601-010 -- PWB,COMB MAIN EZSN TS-SLW701 0 X PWB 8B-YPA-601-010 -- PWB,COMB MAIN TS-SLW700 X PWB 8B-YPA-602-010 -- PWB,MAIN TS-SLW700 X PWB 8B-YPA-602-010 -- PWB,MAIN EZSN TS-SLW701 0 X PWB 8B-YPA-602-010 -- PWB,MAIN...
  • Page 33 SCHEMATIC DIAGRAM – 1 (MAIN / JACK / POWER / LED) <U>...
  • Page 34 SCHEMATIC DIAGRAM – 2 (MAIN / JACK / POWER / LED) <EZ,K>...
  • Page 35 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 9620450 Printed in Singapore...
