TS-UC15
U(W)
SERVICE MANUAL
ACTIVE SPEAKER SYSTEM
S/M Code No. 09-994-328-2N1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TS-UC15 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aiwa TS-UC15

Summary of Contents for Aiwa TS-UC15

  • Page 1 TS-UC15 U(W) SERVICE MANUAL ACTIVE SPEAKER SYSTEM S/M Code No. 09-994-328-2N1...

  • Page 2: Specifications

    SPECIFICATIONS Power supply 120 V AC, 60 Hz Input terminals/sensitivity AUX IN: 500 mV/10 kilo ohms, Power consumption 20 W stereo minijack (1) Speakers 77 mm full range antimagnetic USB: USB Rev.1.0 standard type satellite speakers/6 ohms (2) Output terminals SPEAKER: To satellite speakers 100 mm antimagnetic type (L.
  • Page 3 DISASSEMBLY INSTRUCTIONS Remove the four screws (BVT2+3-20). (1) Remove the screw (VFTT+3-6). (2) CABI, INNER and CABI, FRONT are difficult to remove because they are coated with silicon. Therefore, remove the CABI, INNER by pressing the top panel of CABI, FRONT until it is distorted. (3) 2 VFTT+3-6 CABI, FRONT Silicon coating area...

  • Page 4: Electrical Main Parts List

    ELECTRICAL MAIN PARTS LIST REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION USB C.B 87-001-629-110 IC,LA4630 C202 87-010-190-080 S CHIP F 0.01 87-A20-754-010 IC,BA4558N-DX C203 87-010-314-080 C-CAP,S 22P-50V 8Z-YP5-607-010 IC,UDA1321T C204 87-010-314-080 C-CAP,S 22P-50V 87-A21-195-080 IC,RE5RE33AA C205 87-010-178-080 CHIP CAP 1000P...

  • Page 5: Ic Block Diagram

    IC BLOCK DIAGRAM IC, UDA1321T • Regarding connectors, they are not stocked as they are not the initial order items. The connectors are available after they are supplied from connector manufacturers upon the order is received. CHIP RESISTOR PART CODE Chip Resistor Part Coding Figure Resistor Code...
  • Page 6 WIRING-1...

  • Page 7: Schematic Diagram

    SCHEMATIC DIAGRAM-1...
  • Page 8 SCHEMATIC DIAGRAM-2...
  • Page 9 WIRING-2...

  • Page 10: Mechanical Exploded View

    MECHANICAL EXPLODED VIEW 1/2 SH,FIBER P.C.B HT-SINK,POWER IC P.C.B P.C.B P.C.B CHAS,PT P.C.B...

  • Page 11: Mechanical Parts List

    MECHANICAL PARTS LIST 1/2 REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION 1 87-YP6-207-010 FOOT,WOOFER 16 8Z-YP6-006-010 CABI,REAR WOOFER USB UL 2 8Z-YP6-005-010 CABI,FRONT WOOFER USB UL 17 87-YP4-620-010 AC CORD ASSY,U SPT-2W 3 87-YP6-006-010 KNOB,RTRY BASS 18 8Z-YP6-606-010 F-CABLE,5P 2 JACK 4 87-YP6-004-010...
  • Page 12 MECHANICAL EXPLODED VIEW 2/2...
  • Page 13 MECHANICAL PARTS LIST 2/2 REF. NO PART NO. KANRI DESCRIPTION 1 87-YP6-009-010 GRILLE,SATELLITE 2 8Z-YP6-007-010 CABI,FRONT SATELLITE USB 3 87-YP6-607-010 SPKR,77 6OHM S 4 87-YP6-617-010 CORD,SPKR 5 87-YP6-008-010 CABI,REAR SATELLITE A 87-067-945-110 VFT2+3-12(F10) B 87-067-581-010 TAPPING SCREW, BVT2+3-15 COLOR NAME TABLE Basic color symbol Color Basic color symbol...
  • Page 14 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 Printed in Singapore 931196...
