aiwa
Active Speaker System (Powered Subwoofer)
TS-W60
pg. 2
OWNERS RECORD
For your convenience, record the model number and serial number (you will find them on the rear of your set) in the
space provided below. Please refer to them when you contact your AIWA dealer in case of difficulty.
Model No. TS-W60 U
Serial No.
TABLE OF CONTENTS
FEATURES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Positioning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
FEATURES
• VOLUME control
• PHASE switch (NORMAL/REVERSE)
You can use the PHASE switch to change the quality or volume of sound reproduced by the powered subwoofer.
• AUTO POWER function
You can set the powered subwoofer to be powered on automatically when it receives signal from the stereo system.
• Frequency turnover control
According to the frequency range of the front speakers, you can adjust the frequency range of the sound reproduced
by the powered subwoofer.
• Two-way connection to the amplifier
The TS-W60 can be connected to equipment either with an RCA phono lack for a super woofer, or typical L and R
