Each product from HSD has unique functions that users will need to fully grasp step by step as you will complete the assembly. It is necessary to assemble and test the product strictly in accordance with HSD's standards.
C O N T E N T S ----------------------------------------------------------------------------------- Box Content Specifications ---------------------------------------------------------------------------------- Assembly --------------------------------------------------------------------------------------- ------------------------------------------------------ Control Horn and Servo Arm Settings ------------------------------------------------------------------------- Control Direction Test ------------------------------------------------------------------------------ Clevis Installation Control Surface Centering ------------------------------------------------------------------- Throttle Range Setting ----------------------------------------------------------------------- ----------------------------------------------------------------------------- CG Configuration Battery Installation ---------------------------------------------------------------------------- Accessories...
Attention EDF jets require Li-PO batteries with a high discharge rating (C rating) for increased safety and optimal performance. We recommend using Li-Po batteries with a minimum of 40C or above. Box Contents Specifications 1100mm 75mm EDF Brushless Outrunner Motor 3060/2600KV (4S) Installed 3060/2000KV (6S) Installed...
Assembly PA 3*15MM 1pcs PA 3*18MM 1pcs PA 2.6*6MM 1pcs Connect the servo link and fix the screws PA 3*5MM 2pcs Connect the servo link and fix the screws Fixed with screws M3*3MM 1pcs PA 2.6*6MM 2pcs PA 2.6*6MM 4pcs Assembly is now complete.
Control Horn and Servo Arm Settings The table below shows the factory settings for the control horns and servo arms. Fly the aircraft at factory settings before After flying y ou may choose to adjust the linkage positions for the desired control response.
Control Direction Test Assemble the aircraft and bind your transmitter to the receiver before performing this test . After binding a transmitter to the aircraft receiver, set the trims and sub-trims to 0, then adjust the clevises to center the control surfaces. Move the controls on the transmitter to make sure the aircraft control surfaces move in the proper direction.
Clevis Installation * Adjust the push rod and clevis as necessary *Carefully adjust the clevis so that it creates a centered surface when attached to the control horn. Control Surface Centering *After assembly and transmitter setup, verify that the contro l surfaces are centered.
CG Location Make sure the center of gravity (CG) is as indicated in the following diagram: + 1 0 m m + 1 0 m m - 10m m - 10m m 85MM + 10m m - 10m m Battery Installation Recommended battery location for Recommended battery location for 4S 3300mAh (350g) Li-Po...
Troubleshooting Probable Causes Solutions Problem 1. Charge the battery 1. Battery is not fully charged 2. Install fresh AA batteries 2. Transmitter battery is low 3. Check for connection between 3. Motor is not connected Motor does the ESC and motor 4.
Model Flying Precautions Select your flight area carefully. Always choose an open space that is unobstructed by trees and/or buildings and away from crowded area.Avoid flying in area with roads,electricity/telephone poles or wires and water nearby or within close proximity to air traffic. Do not fly this model in poor weather, high winds, low visibility, extreme temperatures, rain and storms ...
