FRONIUS IG 300 / 400 / 500
42,0410,1288 012006
GB
Operating instructions
Inverter for mains-connected
photovoltaic systems

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IG 300 and is the answer not in the manual?

Questions and answers

Related Manuals for Fronius IG 300

Summary of Contents for Fronius IG 300

  • Page 1 FRONIUS IG 300 / 400 / 500 Operating instructions Inverter for mains-connected photovoltaic systems 42,0410,1288 012006...
  • Page 3 Read the manual carefully and you will soon be familiar with all the many great features of your new Fronius product. This really is the best way to get the most out of all the advantages that your machine has to offer.

  • Page 5: Safety Rules

    Safety rules DANGER! “DANGER!” indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury. This signal word must be limited to the most extreme situations. This signal word is not used for hazards relating to property damage unless there is also a risk of personal injury appropriate to this level.
  • Page 6 General Remarks All the safety instructions and warning signs on the machine itself: (continued) must be kept in a legible condition must not be damaged must not be removed must not be covered, pasted or painted over For information about where the safety instructions and warning signs are located on the machine, please refer to the section of your machine’s in- struction manual headed “General Remarks”.
  • Page 7 Qualified Staff Maintenance and repair may only be carried out by an authorised specialist (continued) company. There is no guarantee in the case of parts sourced from other suppliers that these parts have been designed and manufactured to cope with the stresses and safety requirements that will be placed on them.
  • Page 8 Safety markings Equipment with the CE mark fulfils the basic requirements of the Guideline Governing Low-Voltage and Electromagnetic Compatibility. (More detailed information about this may be found in the Annex or in the section of your documentation headed “Technical Data”.) Disposal Do not dispose of this device with normal domestic waste! To comply with the European Directive 2002/96/EC on Waste Electrical and...

  • Page 9: Table Of Contents

    General ..............................6 Current is generated on the roof ......................6 Current is converted underneath the roof ....................7 The FRONIUS IG in the photovoltaic system ....................8 General ..............................8 Converting DC to AC current ........................8 Fully automatic operational management ....................8 Voltage transformation and galvanic isolation ..................
  • Page 10 Class 5 ..............................62 Customer service ........................... 64 Technical data ............................. 65 FRONIUS IG 300 / 400 / 500 ......................... 65 Standards and directives with which the equipment complies ............... 66 Warranty and liability ........................... 67 Warranty requirements and liability ......................67 Scope of warranty ..........................

  • Page 11: Protection Of Personnel

    Galvanic (electri- The FRONIUS IG is constructed and operated in the safest possible way, both in terms cal) isolation of installation and operation. The DC and AC sides are completely galvanically (electri- cally) isolated from one another to ensure optimum levels of safety.

  • Page 12: Mains Connection

    -10°C can be found in the data sheet for the solar panels. If the open-circuit voltage for the solar panels rises above 530 V, this will result in com- plete destruction of the FRONIUS IG and all warranty rights shall be declared null and void.

  • Page 13: Safety Strategy

    In Italy, due to the country-specific ENEL DK5940 Directive in force, the following inverter in the FRONIUS IG 400 and IG 500 series must be con- nected to the public grid using the operator’s own isolating transformer. The transformer is supplied with a user manual (operating instructions), which must be consulted when installing the device.“...

  • Page 14: How A Photovoltaic System Works

    How a photovoltaic system works The amount of solar energy radiated worldwide amounts to approx. General 1,540,000,000,000,000,000 kWh per year (1,540 peta kWh / year). This is 15,000 times more than the total electricity consumed. We would like to congratulate you on your decision to make active use of the world’s largest energy pool.

  • Page 15: Current Is Converted Underneath The Roof

    The DC current generated in the solar modules cannot be fed into the public mains verted underne- network or used within the household unless it has first been converted in the inverter. This is the primary function of the FRONIUS IG. ath the roof...

  • Page 16: The Fronius Ig In The Photovoltaic System

    Needless to say, it retains all its settings and stored data. The FRONIUS IG is designed for use with solar modules with a wide range of voltage Voltage transfor- input. This enables the widest possible variety of types of solar module to be used.

  • Page 17: Monitoring The Mains Network

    Insolation In addition to the functions implemented in the FRONIUS IG, the wide range of data communication elements enables a multitude of different data logging and display options. The add-on system components required for this purpose are easy to install (see operating instructions for FRONIUS IG DatCom).

  • Page 18: Plus Points

    FRO- NIUS IG can manage all these tasks simultaneously. The FRONIUS IG also meets a large number of the criteria for the protection of people, other domestic equipment as well as itself.

  • Page 19: The Fronius Ig

    From this time onwards, system data will be displayed on the FRONIUS IG graphic display. Whilst the FRONIUS IG is running it keeps the voltage of the solar modules constantly within the range for obtaining maximum power.

  • Page 20: Startup Phase

    Once the FRONIUS IG has been switched on automatically it carries out a self-test Startup phase routine. After this, the public mains network is tested. This test can take from just a few seconds up to several minutes depending on national regulations.

  • Page 21: Fronius Ig 500 Overview

    Startup phase (continued) (5) Feeding power into the mains Once the tests have been completed the FRONIUS IG starts feeding power into the mains The LED is illuminated green and the FRONIUS IG is in operation (6) Checking the roof fans When power is starting to be fed into the mains, the fan controller is checked.

  • Page 22: Led For Operating Status

    (4) LED flashing orange: A warning appears on the display Or the FRONIUS IG has been switched to standby mode in the setup menu = power feed-in is switched off manually Power feed-in is resumed automatically after the next sunrise When the orange LED is flashing, power feed-in can be started manually at any time (see chapter entitled “The Setup Menu”)

  • Page 23: The Display

    The display General The FRONIUS IG is pre-configured and ready to use. There is no need to make any initial settings before using it to feed power into the mains, which is a fully-automated process. The display unit’s power is supplied by the solar modules, which means that the display unit can be used in the daytime.
  • Page 24 Symbols (6) ... appears when values are displayed which are directly associated with the public (continued) mains network (7) ... appears when values are displayed which are directly associated with the solar module (8) ... appears when values are displayed which are directly associated with the FRO- NIUS IG (9) ...

  • Page 25: Navigating Around The Display

    Navigating around the display Display illumina- Press any key to light up the display. If no key is pressed for 30 seconds or more, the display illumination will go off again. The setup menu also offers a choice between tion display lighting permanently on or permanently off.

  • Page 26: The Display Modes

    Scrolling between display functions Choose your preferred display mode (see above) Use keys (A) and (B) to scroll between the available display functions The display modes The following display modes are available: Overview of display modes „Now“ display mode ... Displays real-time values „Day“...
  • Page 27 * Maximum insolation (W/m²) Service hours completed by the FRONIUS IG (HH:MM) Value displayed is applicable to the mains phase of the master power module. Use the „Enter“ key to call up the submenu for the other mains phases (L1, L2, L3).
  • Page 28 The voltage displayed whilst power is being fed into the mains corresponds to what is known as MPP voltage (MPP = maximum power point). The FRONIUS IG always maintains the module voltage within the range that allows the maximum possible power to be obtained from the solar modules.
  • Page 29 (continued) modules ... (amperes) The FRONIUS IG always maintains the module voltage within the range that allows the maximum possible power to be obtained from the solar modules. This results in the optimum module current.
  • Page 30 (watts/ m²; optional sensor card) Time (optional datalogger) ... if the time is changed on a FRONIUS IG or an add-on system component, it will also be changed in any other devices that are connected via LocalNet.
  • Page 31 Overview of display values (continued) Fan controller malfunction Fan controller ready for operation Inlet air temperature (°C) The roof fan speed and the code for the fan concerned are displayed alternately. RPM = revolutions per minute FL = “front left” FR = “front right”...

  • Page 32: Day" / „Year" / „Total" Display Mode

    „Year“ display mode ... Displays values for power fed into the mains during the current calendar year - only in conjunction with a data logger „Total“ display mode ... Displays values for power fed into the mains since the FRONIUS IG was originally commissioned.
  • Page 33 „Day“ / „Year“ / Return ... amount of money earned „Total“ display during the period of time in question mode (currency can be selected in the Setup (continued) menu) Important! As with energy fed in, here too there may be discrepancies with other measured values.
  • Page 34 The service hours are shown in hours and minutes up to 999 hours and 59 minutes („999:59“). After that, only the hours are shown. Although the FRONIUS IG does not operate during the night, the data required by the optional sensor card is logged and stored 24 hours a day.

  • Page 35: The Setup Menu

    Status display for power modules Version MainCtrl Fan Control PS00 ..PS14 „Setup“ display mode The setup menu allows the FRONIUS IG’s initial settings to be changed easily to bring it in line,as closely as possible, with your preferences and requirements.

  • Page 36: Open The Setup Menu

    Open the setup Move to the menu level (see chapter menu entitled „Navigating around the display“) Use keys (A) or (B) to choose „Setup“ mode (5) Enter „Setup“ mode (5): Press „Enter“ key (D) The first menu item, „Standby“, is shown.

  • Page 37: Setting The Menu Items

    / switch off standby mode. The „Standby“ menu item provides the facility to put the FRONIUS IG into standby mode manually. The power electronics are switched off in standby mode. No power is fed into the mains.
  • Page 38 „Contrast“ ... Adjusts contrast on the LCD display. To initiate contrast adjustment: Press „Enter“ key (D) Since the contrast is temperature-depen- dent, when the ambient conditions change it may be necessary to adjust the contrast. Choose a setting from „0“ to „7“ - press key (A) or (B): Settings Minimum contrast (0) to maxi- mum contrast (7):...
  • Page 39 „Light mode“ ... Initial setting for display illumination. To initiate „light mode“ adjustment: Press „Enter“ key (D) To change between the settings Auto 1., On 2. and Off 3. - press key (A) or (B): The display illumination is switched off if no keypress is detected for 30 seconds Accept: Press „Enter“...
  • Page 40 Enter currency (factory setting: EUR) First digit flashing Use key (A) or (B) to select a letter for the first character Press „Enter“ key (D) to confirm Next digit flashing The procedure for entering the other digits is the same as for the first digit (described above) Accept currency: Press „Enter“...
  • Page 41 FRONIUS IG should be assigned a different address. It is important to assign a different address to each FRONIUS IG to enable the datalog- ger to distinguish between the individual inverters. If there are two FRONIUS IGs with the same address in the system, then data communication with the datalogger will not be possible.
  • Page 42 If a successful data connection has been If DatCom is not installed or if the data established, then the status „OK “ is connection is not working correctly, displayed. then „Error“ will be displayed. Use arrow key (B) to initiate the signal card test Start signal card test by pressing Signal card not installed...
  • Page 43 Important! The „Time“ menu option is only supported when the optional data- logger is connected. “Time” ... Setting time and date To initiate time adjustment: Press “Enter” key (D) Setting date (e.g.: 03.10.2003) First digit flashing Use key (A) or (B) to select a number for the first digit Press „Enter“...
  • Page 44 „State Fan“ ... Queries status for the fan controller Initiating „State Fan“ setting: Press „Enter“ key (D) Fan controller ready for operation Press „Enter“ key (D) Start fan controller test Press „Enter“ key (D) 4a. The fan controller is tested. This involves the roof fans running for approx.
  • Page 45 „STATE_PS“ ... Status display for the power modules Press „Enter“ key (D) In this case, for instance, the first power module (PS00) is set to „Stand- by“ „Standby“ means no power is being fed into the mains Press „Enter“ key (D) Displays the most recently stored service code (e.g.
  • Page 46 „Version“ ... Shows the version number and serial number of the IG control unit and the power module. To view/change the version: Press „Enter“ key (D) To switch between the MAIN 1., PS 2. and FAN CTRL displays, press key (A) or (B): Show version number of IG control unit: Press „Enter“...

  • Page 47: Supplementary Information

    FRONIUS developed LocalNet to make these add-on system components flexible and capable of being used in a wide variety of different applications. LocalNet is a data network which enables more than one FRONIUS IG to be linked up with the add-on system components.

  • Page 49: Installation Instructions

    Installation instructions...

  • Page 50: Opening The Housing

    FRONIUS IG by crane it is essential that all four of the dedicated attachment points are used. Selecting a The FRONIUS IG is available in IP 20 or IP 43 versions. The IP 20 version is intended location exclusively for installation in closed rooms but is also suitable for operation in containers.

  • Page 51: Fitting The Base

    Important! The optional base must be used if the surface on which the FRONIUS IG is to be installed does not allow cables to be routed in from below. The FRONIUS IG IP 43 version must be installed on the base.

  • Page 52: Ip 20 Version: Fitting The Exhaust Pipe

    Keep all ventilation openings completely free of obstructions. At haust pipe the FRONIUS IG installation location, the amount of fresh air supplied should be at least 750 m³ an hour. In all other air outlet situations, an exhaust air guide with a straight, bevelled pipe is sufficient.

  • Page 53: Forced-Air Ventilation

    A power derating system briefly restricts the output from the FRONIUS IG in order to prevent the temperature from exceeding the permissible value. Your FRONIUS IG will continue to operate without any down times for as long as possible. Even if the FRONIUS IG very frequently operates under maximum load, the...

  • Page 54: Cleaning The Air Filter

    Cleaning the air filter General informa- The frequency with which the air filter must be cleaned depends on the air quality at the tion installation site. Important! If cooling air has to be drawn in from outside the installation area, we recom- mend the „air supply“...

  • Page 55: Connecting The Solar Modules And The Mains

    Connecting the solar modules and the mains To enable suitable solar modules to be chosen and to use the FRONIUS IG as efficiently Solar modules as possible, it is important to bear the following points in mind: If insolation is constant and the temperature is falling, the open-circuit voltage will increase.

  • Page 56: Strain Relief

    DC DC cable cross section: 70 mm² leads If two pairs of DC cables are connected to the FRONIUS IG, they should be con- nected directly (without using the copper brackets). NOTE! Do not exceed the follo-...

  • Page 57: External Power Supply To Rack

    (if connect a switch (230 V, 1 A) to the required by your terminals shown. These terminals allow power supply you to disconnect the FRONIUS IG from company) the mains supply. Important! For further details, please see the accompanying overall circuit diagram.

  • Page 58: Configuring The Inverter

    FRONIUS IG is functioning correctly. If, when you use your FRONIUS IG for the first time, events do not occur as described above and if the FRONIUS IG does not start feeding power into the mains, consult the chapter on “Troubleshooting”.

  • Page 59: Localnet

    FRONIUS IG: The COM card, which is installed in the FRONIUS IG at the time of manufacture; this allows the FRONIUS IG to establish a data interface with the LocalNet and the add-on system components to which it is connected.

  • Page 60: Configuration

    In order to distinguish between several identical add-on system components, each one of them must be assigned a unique number. Likewise, in order for each FRONIUS IG to be defined unambiguously in the LocalNet, they must also be assigned a separate number each.

  • Page 61: Example

    RS-485 interfaces as its input and output. RJ45 plug connectors are used to connect to these cards. The first FRONIUS IG with COM card can be up to 1,000 m away from the last FRONI- US IG with COM card.

  • Page 62: Replacing Fuses

    Replacing fuses Replacing fuses WARNING! Danger due to mains voltage and DC voltage from solar modules. The connection area should only ever be opened by an authorised electrical engineer, and only when the power is disconnected. Criteria for selecting fuses: = 20 A = 600 V DC and AC Fuse dimensions: 10.3 x 35 - 38 mm...

  • Page 63: Service Codes Displayed

    170 V, it is reasonable to assume that there is a fault elsewhere in the photovoltaic system. If the open-circuit voltage of the solar modules (at the FRONIUS IG connections) is more than 170 V, this may indicate a basic fault in the FRONIUS IG. In this event, always notify a FRONIUS-trained service engineer.

  • Page 64: Status Diagnosis For Power Modules

    Status diagnosis Display during normal operation for power modu- Fault on one of the two power modules: Service code display (e.g. „Status 515“) Alternate Important! The service code and „Enter“ are displayed alternately. Press “Enter” key twice The status display for the power modules is shown, „Status PS“...

  • Page 65: Class 1

    Service codes in service class 1 generally only arise momentarily, and are caused by the public mains network. The initial response of the FRONIUS IG in this case is to disconnect itself from the mains. The mains is subsequently checked for the stipulated monitoring period. If no further problem has been detected by the end of this period, then the FRONIUS IG will resume feeding power into the mains.

  • Page 66: Class 2

    Class 2 service codes are also related to the mains parameters. Therefore, some of the testing methods overlap with those for service class 1. The FRONIUS IG will react in exactly the same way as with class 1 service codes.

  • Page 67: Class 3

    The FRONIUS IG disconnects automatically from the mains, the mains are then monito- red as specified, and the FRONIUS IG then attempts to resume feeding power in. Code...

  • Page 68: Class 4

    Class 4 Some of the Class 4 service codes necessitate intervention by a FRONIUS-trained service technician. Code Designation Manifestation Remedy Communication with The power module will au- If a service code appears power module not pos- tomatically attempt to con-...
  • Page 69 Earth current at the solar Check cabling on the DC modules side and fuse on the FRONIUS IG Transformer not con- FRONIUS IG is not con- If a service code appears nected nected to the mains frequently: Notify FRO- NIUS-trained service...

  • Page 70: Class 5

    Class 5 service codes do not generally interfere with feeding power into the mains. A service code is displayed until it is acknowledged by pressing a key (however, the FRONIUS IG continues to operate normally in the background). Press any key...
  • Page 71 Sensor card settings have Reconfigure measuring been reset to their defaults channels if necessary Too many power mo- Too many power modules Notify FRONIUS-trained dules on the system have been detected on the service engineer system No communication with Warning message issued by...

  • Page 72: Customer Service

    Roof fans not working, pos- sible power derating Customer service Important! If a fault occurs frequently or for a long period and the fault is not listed in the tables, consult your FRONIUS dealer or FRONIUS-trained service agent.

  • Page 73: Technical Data

    Manifestation of DC overload Operating point repositioned The values shown are defaults: Your FRONIUS IG has been configured specifically to suit the requirements in your country If the ambient temperature rises to above 35 °C or thereabouts (depending on voltage at the solar module), the AC output power is reduced (power derating).

  • Page 74: Standards And Directives With Which The Equipment Complies

    In the country-specific versions, the standard measurement and safety procedures integrated into the FRONIUS IG ensure that, in the event of a mains failure (switch-off by the energy supplier or damage to lines), the feeding in of power is immediately interrup- ted.

  • Page 75: Warranty And Liability

    Unauthorised modifications to the FRONIUS IG and accessories Damage by foreign bodies and force majeure To uphold a warranty claim, repairs and servicing must be carried out by FRONIUS or by FRONIUS-trained on-site service engineers. If equipment or components need to be returned to FRONIUS, use the original or similar packaging.

  • Page 76: Warranty Period

    Purchase date on the invoice, date the unit was provided/commissioned, and report from ty purposes the power supply company Disposal Recycling If you decide in the future to replace your inverter, FRONIUS will take back the old unit and arrange for it to be recycled in an appropriate way.
  • Page 77 Produkt: responsibility that the following que le produit suivant: product: IG 300 / 390 / 400 / 500 IG 300 / 390 / 400 / 500 IG 300 / 390 / 400 / 500 Solar-Wechselrichter Photovoltaic-inverter Onduleur solaire auf das sich diese Erklärung...
  • Page 78 43,0004,2838 43,0001,3283 43,0001,1228,Z 42,0300,2659 40,0005,0179 FRONIUS IG 300 / 390 / 400 / 500 Ersatzteilliste / Spare parts list / Listes de pièces de rechange / Lista de repuestos / Lista de pecas sobresselentes / Lista dei Ricambi el_fr_se_ns_01168 012006...
  • Page 79 * Bitte wenden sie sich an den Fronius Technischen Support * please consult your Fronius technical support 4,240,001,Z - COM-CARDA 43,0003,0922 4,070,887,Z - FANCONTROL IG CTRL * 43,0004,2839 4,070,762,Z - SDI SPM 42,0407,0577 42,0201,1960 43,0001,1116 4,070,758,Z - POWER19B 4,070,986 - UESP3...
  • Page 80 Fronius USA LLC Solar Electronics Division 4600 Wels-Thalheim, Günter-Fronius-Straße 1, Austria 10421 Citation Drive, Suite 1100, Brighton, MI 48116 E-Mail: pv@fronius.com E-Mail: pv-us@fronius.com http://www.fronius.com http://www.fronius-usa.com Under http://w w w.fronius.com/addresses you w ill find all addresses of our sales branches and partner firms! ud_fr_se_so_00913 012007...
