User Manual
Manual Title:
Print Date:
Revision/Date:
This supplement contains information necessary to ensure the accuracy of the
above manual. This manual is distributed as an electronic manual on the
following CD-ROM:
© 2009-2016 Fluke Corporation. All rights reserved.
Manual Supplement
5320A Users
September 2006
2, 10/08
CD Title:
CD Rev. & Date:
CD PN:
Supplement Issue:
Issue Date:
Page Count:
5320A
2, 1/09
2634346
9
2/16
7
Advertisement
Related Manuals for Fluke 5320A
Summary of Contents for Fluke 5320A
- Page 1 This supplement contains information necessary to ensure the accuracy of the above manual. This manual is distributed as an electronic manual on the following CD-ROM: CD Title: 5320A CD Rev. & Date: 2, 1/09 CD PN: 2634346 © 2009-2016 Fluke Corporation. All rights reserved. ...
- Page 2 5320A Users Manual Supplement Change #1 On page 6-16, replace Table 6-11 with the following: Required Lower Nominal Standard Start Increment Upper Frequency Limit Current Ammeter Current Limit (mA) (mA) Accuracy 20 A 25 mA ac 0.2 % Line Freq.
- Page 3 Manual Supplement 5320A Users Change #4 On page 6-11, replace Figure 6-4 with the following: ewt090.eps Figure 6-4. Resistance Multiplier Verification Connectioons 11/09...
- Page 4 On page 6-14, replace Step 4 with: Set the multifunction calibrator to the same voltage as the voltage on the mains input of the Calibrator (5320A). 115 V or 230 V for example. Set the multifunction calibrator frequency to 55 Hz.
- Page 5 Ground Bond Resistance or Loop/Line Impedance functions are used daily. If these functions are used less often, relay cleaning should be performed every 90 days. If the 5320A has been powered off for more than 30 days, the relay cleaning procedure should be performed before usage.
- Page 6 2. Navigate to the Relay cleaning procedure as outlined above. Do not start the procedure. 3. Set the external power supply to 20 V and connect as shown to the PE and N terminals of the 5320A. It is best to use an external analog (linear) supply source. If a switching dc supply source is used, two resistors and one capacitor should be inserted between the power supply output and the 5320A input as shown in the diagram.
- Page 7 Manual Supplement 5320A Users Note For units with serial number lower than xx548xxxx, do not run the cleaning procedure without connecting the external power supply. When the cleaning procedure is performed without connecting the external power supply, the relay contact resistance may become even worse.
- Page 8 5320A Users Manual Supplement On page 6-4, replace Table 6-2 with: Table 6-2. Measurement Input Fuses Input Fuse Fluke Part No. F3.15H250 V (5 mm x 20 mm) 2743508 Leakage Current F100mL150 V (5 mm x 20 mm) 2743513 Meter T20H500 V (6.3 mm x 32 mm)
