OP710

Overview

The OP710 offers an economical approach for optical power measurement
applications where multiple channels are needed. Unlike other systems this
instrument is built up with individual power meters allowing for unparalleled
simultaneous data acquisition over all channels with a sampling rate of up to 10
samples per second.
It is available starting at 1 channel up to 24 channels and can be configured for a
variety of detector and connector interfaces. With the rack mount option multiple
instruments can be combined and configured for even higher channel count.
Available detector options:
IN1
IN3
IN5
IN10
HP
SI3
R
S
1mm InGaAs detector with 5/8" Adapter
3mm InGaAs detector with 5/8" Adapter
5mm InGaAs detector with 5/8" Adapter
10mm InGaAs detector with 5/8" Adapter
2mm High Power InGaAs detector with 5/8" Adapter
3mm Silicon detector with 5/8" Adapter
Electrical port for Remote Head Detector
Digital port for Integrating Sphere
3 of 11
