- Page 1 R290DS Dual Source Power Amplifi er Installation Manual...
-
Page 2: Safety Instructions
Cet appareil numérique de la classe B est conforme à la norme Quick stops, excessive force and uneven inspection. surfaces may cause the appliance and cart NMB-003 du Canada. Russound R290DS Installation Manual... -
Page 3: Table Of Contents
System Confi guration - Stereo Mode ................6 System Diagram - Stereo Mode..................7 System Confi guration - Bridged Mode ................8 System Confi guration - External Volume Control ............9 Technical specifi cations ......................10 Warranty ...........................11 Russound R290DS Installation Manual... -
Page 4: Product Overview
(e.g., large outdoor zones). Rack Mounting The R290DS is rated at 90 watts per channel into 8 ohms, and 110 watts into 4 The R290DS amplifi er can be rack mounted using the included rack-mount ohms. With the Stereo/Bridge Mono switch in the Bridge Mono position, both ears and hardware to attach the ears to the amplifi er. -
Page 5: Front And Rear Panels
Stereo / Bridge Switch Power Switch Left and Right Channel Controls Power Inlet & Fuseholder 12V Trigger In / Out Delay Time Speaker Output Speaker Level Line Input Switch Voltage Selector Speaker Level Input (Screw Down Connector) Russound R290DS Installation Manual... -
Page 6: System Configuration - Stereo Mode
Stereo Mode Note: If there are two inputs assigned as Primary (Speaker and Line) the Line The R290DS can be confi gured as a power upgrade for specifi c zones, for input will take priority. use with large speaker selectors, and for long parallel speaker runs (outdoor zones) 1. -
Page 7: System Diagram - Stereo Mode
SYSTEM DIAGRAM - STEREO MODE Line Out MCA-C5 Multizone Controller RCA Cable R290DS Amplifier Speaker Cable Line Out RCA Cable Source 8 ohm Speakers Stereo Mode Confi guration with Dual Sources (CD player signal takes precedence) Russound R290DS Installation Manual... -
Page 8: System Configuration - Bridged Mode
2. Set the Stereo/Bridge switch to Bridge Mono. 3. Connect the line out from a preamplifi er or source to the Left Primary input jack of the R290DS. Do not connect any input to the right side, it will be ignored. -
Page 9: System Configuration - External Volume Control
SYSTEM CONFIGURATION - EXTERNAL VOLUME CONTROL System Confi guration with External Volume Control The R290DS can be confi gured for large autoformer-based volume control systems/speaker selectors. R290DS Amplifier Line out from Source Autoformer-based RUSSOUND RUSSOUND Volume Control SPEAKERS SPEAKERS SPEAKERS... -
Page 10: Technical Specifications
IEC 320 type connector with 3 terminal detachable power cord Standby Power: <0.5W Dimensions: 17” W x 14”D x 4.125”H (43 x 35.5 x 10.5 cm) Weight: 17.2 lbs. (7.8 kg) The R290DS Amplifi er meets EU Standby Power Requirements Russound R290DS Installation Manual... -
Page 11: Warranty
WARRANTY Warranty Before returning a unit for repair, call Russound at (603) 659-5170 for a Return The Russound R290DS Power Amplifi er is fully guaranteed against all defects Authorization number. Write this number on the shipping label and ship to: in materials and workmanship for two (2) years from the date of purchase. - Page 12 All trademarks are the property of their respective owners. 5 Forbes Road, Newmarket, NH 03857 Specifi cations are subject to change without notice. tel 603.659.5170 • fax 603.659.5388 Russound is not responsible for typographical errors or omissions. email: tech@russound.com www.russound.com 28-1318 Rev. 3 01/24/14...
