Programming

Preparation of Garage Door for opener.
First step, open and close the door manually, the door should be running
smoothly, and door is well balanced.
Do not install opener on Garage Door, unless the door runs smoothly in manual
operation.

Programming the motor unit

8 LED lamps and 3 buttons are used for pro-
gramming: "P" "+" "-"
Instruction:
State of lamp:
Always Lamp
bright

Programming the open and closed positions of the door

Press the "P" button. LED no. 2 will flash. Press "+" and hold it down so
that the door runs to the position that you want as the open position.
Press the "P" button once to indicate the opening position, and LED no. 4 will
flash. Press the "-" button and hold it to bring the door to the desired lowest po-
sition. Then press the "P" button. The door will run to the opening position and
then back to the closed position. The automatic cycle registers the weight of the
door and sets the traction power automatically. LED no. 3 will remain on when
programming is completed.
Dark
State of buttons:
No press Press Always press
