Display overview

End-user overview
The images in this daily user interface will depend on how the set-up is made. They will illustrate what is regulated.
For example: One or two suction groups, one condenser group, or a combination. See examples below:
1 suction
groupe
1 condenser
group
1 suction groups
and
1 condenser
group
Each of the 3 rows above is continued with three additional displays.
The arrow in the top corner of the display shows the way to the next display in the same area
of operation. By clicking the right arrow you can see these three displays:
Active alarms
When an alarm is sent
from the controller, you
must advance to this
display to see the
alarm text.
Select a line and press
"Enter" to see the details
of the alarm.
If the alarm needs to be
manually reset, press and
hold the "X" button for 3
seconds.
6 | RS8HA102 |
Cleared Alarms Information on the controller
