How is an ascent rate alarm warning indicated?
The watch will sound a Rapid Ascent Alarm for fi ve seconds, and the
Flashing graphic dial
graphic dial and the text SLOW will fl ash on the display.
and text
After the alarm stops sounding, SLOW and the graphic dial will
continue to fl ash for an additional fi ve seconds (10 seconds total).
To stop the alarm tone, press any button.
Current water
depth
Dive time
E-56
3. Press D to change the unit settings as shown below.
Press D to toggle between these settings:
To specify this unit:
Temperature
°C (Celsius) and °F (Fahrenheit)
Water depth
m (meters) and ft (feet)
4. After all of the settings are the way you want, press A to exit the setting screen.
E-58
The fi gure below shows how a record's data is displayed.
Log record number
Dive start time
Dive start date
(month, day)
2 seconds
* Pressing A displays the recoded dive start date (year, month, day) and time for two seconds.
E-60
To delete all log records
1. Enter the Diving Log Mode.
2. Hold down A for about fi ve seconds. First, CLEAR ALL Hold will fl ash on the display. After that,
CLEAR ALL will stop fl ashing and remain display. Release A when CLEAR ALL stops fl ashing.
The message NO-DATA will scroll on the display to indicate that all log records have been
deleted.
Troubleshooting when a Flashing Warning Mark ( ) Appears
A fl ashing warning mark ( ) in the Diving Mode means some problem occurred during a measurement, or
that there was some operation error. The warning mark also will appear (without fl ashing) whenever the
log data that was recording during the measurement problem or operation error is displayed. Log data for
which the warning mark appears should not be used for dive planning or other purposes because it
contains large error. Also, data that is stored in the Diving Mode while the warning mark is fl ashing is
assigned a CAUTION number (which also appears in the log data record), which identifi es the type of
problem that occurred.
For details about each type of problem, refer to the pages in the table below.
CAUTION Number
Description
C-1
Water depth measurement
start error
C-2
Negative water depth error
C-3
Battery error (H, M, L
fl ashing)
E-62
Operation Guide 3445
Low water temperature
2 seconds
Dive time
Maximum Depth
A*
Dive start year
Possible Cause
Diving Mode entered while under water (Depth:
1.5 meters or greater).
Surfacing after Diving Mode was entered while
at a depth of 1.4 meters or less
Extreme temperature or pressure change after
entering the Diving Mode
Battery is low so measurement is impossible.
Specifying Temperature and Water Depth Display Units
Use the procedure below to specify the temperature and water depth display units to be used in the
Thermometer Mode and the Diving Mode.
Viewing Diving Log Records
You can use the Diving Log Mode to view the dive start date and time, dive time, maximum depth, and low
water temperature data that is recorded in the Diving Mode.
To view log records
Log record number
Dive start time
Dive start date
(month, day)
To delete a specifi c log record
1. Enter the Diving Log Mode.
2. Use D to display the log record you want to delete.
Important!
Note that holding down A for more than fi ve seconds in step 3 will delete all log records.
Once a record is deleted, it cannot be recovered.
3. Hold down A for about two seconds. First, CLEAR Hold will fl ash on the display. After that, CLEAR
will stop fl ashing and remain display. Release A as soon as CLEAR stops fl ashing.
Deleting a record displays the record that comes after it.
If the record you delete is the last one stored in memory, the message NO-DATA will scroll on the
display.
CAUTION Number
Description
C-4
Water depth measurement
start error
+
Negative water depth error
C-5
Water depth measurement
start error
+
Battery error
C-6
Negative water depth error
+
Battery error
C-7
Water depth measurement
start error
+
Negative water depth error
+
Battery error
Page
Err-1
Water depth sensor error
E-42
E-47
Frequent appearance of Err-1 can indicate watch malfunction. Contact an authorized CASIO service
center.
Appearance of C-1 through C-7 indicates an operation error. Refer to the applicable pages for
E-10
information.
Important!
When TYO (Tokyo) is selected as the Home City, the water depth unit
is set automatically to meters (m) and the temperature unit to Celsius
(°C). These settings cannot be changed.

To specify temperature and water depth display units

1. In the Timekeeping Mode, hold down A for at least two seconds.
First, SET Hold will fl ash on the display, and then CITY will appear
in the upper display. Keep A depressed until CITY is displayed.
After that, the currently selected city code and city name will scroll
across the upper display.
2. Press C as many times as necessary until UNIT appears on the
display.
See the sequence in step 2 of the procedure under "To change the
current time and date settings manually" (page E-32) for information
about how to scroll through setting screens.
1. In the Timekeeping Mode, press C once.
This enters the Diving Log Mode. LOG appears on the display for
two seconds, followed by the newest log record.
Refer to page E-26 for information about navigating between modes.
2. Use D to select the record you want.
Each press of D scrolls through log records in sequence, from
newest (record number -01-) to the oldest (record number -20-). If
there are already 20 log records in memory, the oldest log record
is deleted automatically to make room for the new one.
Pressing D displays the previous record, pressing again displays
the record before that one, and so one.
Holding down D scrolls the records at high speed.
Log record numbers are lower for older data.
Possible Cause
C-1 and C-2 compound error
C-1 and C-3 compound error
C-2 and C-3 compound error
C-1, C-2, and C-3 compound error
Sensor malfunction or faulty connection making
measurement impossible
Detected pressure outside of the sensor's
allowable range, etc.
E-57
E-59
E-61
Page
E-42
E-47
E-42
E-10
E-47
E-10
E-42
E-47
E-10
E-48
E-63
