MA1209-EA
• Note that the product illustrations in this manual are intended for reference only, and
so the actual product may appear somewhat different than depicted by an
illustration.
E-2
Procedure Lookup
The following is a handy reference list of all the operational procedures contained in
this manual.
To set the time and date ......................................................................................... E-9
To toggle the Timekeeping Mode time between DST and Standard Time ....... E-11
To toggle between 12-hour and 24-hour timekeeping ....................................... E-12
To measure times with the stopwatch
(Stopwatch Mode (ST1) and Stopwatch Mode (ST2)) .................................... E-14
To use Auto-Start (ST1) ........................................................................................ E-15
To configure the countdown timer ...................................................................... E-19
To use the countdown timer ................................................................................ E-21
To set an alarm time ............................................................................................. E-24
To test the alarm ................................................................................................... E-26
To turn an alarm on and off ................................................................................. E-27
E-4
General Guide
• Press C to change from mode to mode.
• In any mode (except when a setting screen is on the display), press B to illuminate
the display.
Timekeeping Mode
E-6
Timekeeping
Day of week
Month – Day
Seconds
Hour : Minutes
PM indicator
E-8
Operation Guide 3402
Stopwatch Mode (ST1)
Stopwatch Mode (ST2)
Use the Timekeeping Mode to set and view the current
time and date.
Read This Before You Set the Time and Date !
The times displayed in the Timekeeping Mode and World
Time Mode are linked. Because of this, make sure you
select a Home Time zone before you set the time and
date.
About This Manual
• Depending on the model of your watch, display text
appears either as dark figures on a light background or
light figures on a dark background. All sample displays
in this manual are shown using dark figures on a light
background.
• Button operations are indicated using the letters shown
in the illustration.
• Each section of this manual provides you with the
information you need to perform operations in each
mode. Further details and technical information can be
found in the "Reference" section.
Contents
General Guide ......................................................................................................... E-6
Timekeeping ............................................................................................................ E-8
Stopwatches .......................................................................................................... E-13
Countdown Timer ................................................................................................. E-16
Alarms .................................................................................................................... E-22
World Time ............................................................................................................ E-29
Illumination ............................................................................................................ E-31
Reference .............................................................................................................. E-35
Specifications ....................................................................................................... E-44
To turn the Hourly Time Signal on and off ......................................................... E-28
To view the time for another city code ............................................................... E-29
To toggle a city code time
between Standard Time and Daylight Saving Time ....................................... E-30
To illuminate the display manually ..................................................................... E-31
To specify the illumination duration ................................................................... E-32
To turn the auto light switch on and off ............................................................. E-34
To turn Flash Alert on and off .............................................................................. E-37
To turn the button operation tone on and off ..................................................... E-38
Countdown Timer Mode
Alarm Mode
To set the time and date
1. In the Timekeeping Mode, hold down A until the
seconds start to flash, which indicates the setting
screen.
2. Press C to move the flashing in the sequence shown
below to select other settings.
Home Time zone
Seconds
DST
Day
Month
E-1
E-3
E-5
World Time Mode
E-7
Home Time zone
Hour
Year
Minutes
E-9

Advertisement

loading

  Summary of Contents for Casio 3402

  • Page 1 MA1209-EA Operation Guide 3402 About This Manual • Depending on the model of your watch, display text appears either as dark figures on a light background or light figures on a dark background. All sample displays in this manual are shown using dark figures on a light background.
  • Page 2: Countdown Timer

    Operation Guide 3402 3. When the setting you want to change is flashing, use D and B to change it as 4. Press A to exit the setting screen. described below. • The day of the week is displayed automatically in accordance with the date (year, month, and day) settings.
  • Page 3: Alarm Types

    Operation Guide 3402 3. When the setting you want to change is flashing, use B and D to change it as To use the countdown timer Press D while in the Countdown Timer Mode to start the described below. countdown timer.
  • Page 4 Operation Guide 3402 To toggle a city code time between Standard Time and Daylight Saving Time Illumination 1. In the World Time Mode, use D (east) to display the The display of the watch is illuminated by an LED (light-...
  • Page 5: Specifications

    Operation Guide 3402 • The letters “UTC” is the abbreviation for “Coordinated Universal Time”, which is the Timekeeping world-wide scientific standard of timekeeping. It is based upon carefully maintained • Resetting the seconds to while the current count is in the range of 30 to 59 atomic (cesium) clocks that keep time accurately to within microseconds.
  • Page 6 Operation Guide 3402 * As of June 2012, the official UTC offset for Caracas, Venezuela (CCS) has been City City Other major cities in same time zone Code Differential changed from –4 to –4.5, but this watch still uses an offset of –4 (the old offset) Kabul +4.5...
