Northern Hemisphere View or Southern Hemisphere View Moon Phase
You can select either of the settings below.
Northern hemisphere view (Moon to the south)
Southern hemisphere view (Moon to the north)
To specify Northern Hemisphere View or Southern Hemisphere View Moon Phase
1. In the Tide/Moon Mode, hold down A for at least two seconds.
SET Hold will fl ash on the display, and then the high tide time hour digits
will fl ash. Keep the button depressed until the hour digits fl ash.
High tide time (hour: minute)
E-104
Illumination
The display of the watch is illuminated for easy reading in the dark.
The watch's auto light switch turns on illumination automatically when
you angle the watch towards your face.
The auto light switch must be enabled (page E-108) for it to operate.
To turn on illumination manually
Press L in any mode to illuminate the display.
You can use the procedure below to select either 1.5 seconds or three
seconds as the illumination duration. When you press L, the display
will remain illuminated for about 1.5 seconds or three seconds,
depending on the current illumination duration setting.
The above operation turns on illumination regardless of the current
auto light switch setting.
If the display is illuminated, illumination will turn off automatically if an
alarm starts to sound.
After you turn on illumination once in the Diving Mode, you will not be
able to turn it on again until depth measurement is complete.
To change the illumination duration
1. In the Timekeeping Mode, hold down A for at least two seconds. SET Hold will fl ash on the middle
display, and then CITY will appear in the upper display. Keep A depressed until this happens.
The city code and the name of the currently selected city will scroll across the display.
E-106
Note
This watch features a "Full Auto Light", so the auto light switch operates only when available light is
below a certain level. It does not illuminate the display under bright light.
The auto light switch is always disabled, regardless of its on/off setting, when any one of the following
conditions exists.
While an alarm is sounding
While a compass reading operation is in progress
While calibrating in the Digital Compass Mode
While a receive operation is in progress in the Receive Mode
While measuring Tide/Moon values
While in a sensor mode, an auto light switch operation is performed after a sensor reading
To enable or disable the auto light switch
In the Timekeeping Mode, hold down L for at least three seconds to
toggle the auto light switch between enabled (LT displayed) and disabled
(LT not displayed).
The auto light switch enabled indicator (LT) is on the display in all
modes while the auto light switch is enabled.
The auto light switch becomes disabled automatically whenever
battery power drops to Level 4 (page E-10).
Auto light switch
enabled indicator
E-108

Other Settings

The button operation tone sounds any time you press one of the watch's buttons. You can enable or
disable the button operation tone as desired.
Even if you disable the button operation tone, the alarm, Hourly Time Signal, Rapid Ascent Alarm, and
Countdown Timer Mode alarm all operate normally.
To enable or disable the button operation tone
1. In the Timekeeping Mode, hold down A for at least two seconds. SET
will fl ash in the upper display and Hold will fl ash in the lower display.
Next, SET will fl ash in the middle display and then CITY will appear in
the upper display. Keep A depressed until this happens.
The city code and the name of the currently selected city will scroll
across the display.
2. Use C to cycle through settings on the display until the current button
operation tone (MUTE or KEY ) is displayed.
See the sequence in step 2 of the procedure under "To change the
current time and date settings manually" (page E-32) for information
about how to scroll through setting screens.
3. Press D to toggle the button operation tone between enabled (KEY )
and disabled (MUTE).
4. After all of the settings are the way you want, press A to exit the
setting screen.
Note
MUTE is displayed in all modes when the button operation tone is
Mute indicator
disabled.
E-110
Operation Guide 3445
2. Press C twice.
This displays a screen for selecting Northern Hemisphere view or Southern Hemisphere view for
the Moon phase.
3. Press D to toggle between Northern Hemisphere view and Southern Hemisphere view.
[N
S]: Northern Hemisphere
view (Moon to the south)
4. Press A to exit the setting screen.
2. Use C to cycle through the setting screens until LIGHT appears in the upper display.
The current illumination duration setting (1 or 3) will be fl ashing in the lower display.
See the sequence in step 2 of the procedure under "To change the current time and date
settings manually" (page E-32) for information about how to scroll through setting screens.
3. Press D to toggle the illumination duration between three seconds (3 displayed) and 1.5 seconds (1
displayed).
4. After all of the settings are the way you want, press A to exit the setting screen.
About the Auto Light Switch
Turning on the auto light switch causes illumination to turn on,
whenever you position your wrist as described below in any mode.
Moving the watch to a position that is parallel to the ground and
then tilting it towards you more than 40 degrees causes
illumination to turn on.
Warning!
Always make sure you are in a safe place whenever you are reading the display of the watch
using the auto light switch. Be especially careful when running or engaged in any other activity
that can result in accident or injury. Also take care that sudden illumination by the auto light
switch does not startle or distract others around you.
When you are wearing the watch, make sure that its auto light switch is disabled before riding on
a bicycle or operating a motorcycle or any other motor vehicle. Sudden and unintended
operation of the auto light switch can create a distraction, which can result in a traffi c accident
and serious personal injury.
Illumination Precautions
The LED that provides illumination loses power after very long use.
Illumination may be hard to see when viewed under direct sunlight.
Illumination turns off automatically whenever an alarm sounds.
Frequent use of illumination runs down the battery.
Auto light switch precautions
Wearing the watch on the inside of your wrist, movement of your arm, or vibration of your arm can
cause frequent activation of the auto light switch and illumination of the display. To avoid running down
the battery, disable the auto light switch whenever engaging in activities that might cause frequent
illumination of the display.
Note that wearing the watch under your sleeve while the auto light switch is enabled can cause
frequent illumination of the display and can run down the battery.
Illumination may not turn on if the face of the watch is more than 15 degrees above
or below parallel. Make sure that the back of your hand is parallel to the ground.
Illumination turns off after the preset illumination duration (page E-106), even if you keep
the watch pointed towards your face.
Static electricity or magnetic force can interfere with proper operation of the auto
light switch. If illumination does not turn on, try moving the watch back to the
starting position (parallel with the ground) and then tilt it back towards your face
again. If this does not work, drop your arm all the way down so it hangs at your
side, and then bring it back up again.
You may notice a very faint clicking sound coming from the watch when it is shaken
back and forth. This sound is caused by mechanical operation of the auto light
switch, and does not indicate a problem with the watch.
To enable or disable Power Saving
1. In the Timekeeping Mode, hold down A for at least two seconds. SET
will fl ash in the upper display and Hold will fl ash in the lower display.
Next, SET will fl ash in the middle display and then CITY will appear in
the upper display. Keep A depressed until this happens.
The city code and the name of the currently selected city will scroll
across the display.
2. Use C to cycle through the setting screens until the current power
saving setting (On or OFF) is displayed.
POWER SAVING will scroll across the upper display at this time.
Power saving
See the sequence in step 2 of the procedure under "To change the
enabled indicator
current time and date settings manually" (page E-32) for information
about how to scroll through setting screens.
3. Press D to toggle Power Saving between enabled (On) and disabled
(OFF).
4. After all of the settings are the way you want, press A to exit the
setting screen.
Note
The Power Saving on indicator (PS) is on the display in all modes
while Power Saving is enabled.
[N
S]: Southern Hemisphere
view (Moon to the north)
D
More than
40°
Wear the watch on the
outside of your wrist
E-105
E-107
E-109
E-111
