Audiovox CDC-FDC Installation Manual

Models CDC-FDC
CAUTION:
FOLLOW THE CONNECTION SEQUENCE DESCRIBED BELOW TO ENSURE PROPER
RECOGNITION OF THE CD CHANGER BY THE FACTORY RADIO.
DO NOT FORCE CONNECTORS TOGETHER. LINE UP LOCATING TABS AND CAREFULLY
MATE CONNECTORS.
NOTE: Only works with 6 Disc CD Changer.
INSTALLATION INSTRUCTIONS FOR THE CDC-FDC: (Fig. 1)
IMPORTANT :
Installation must be done with vehicle and radio in OFF position.
1. Mount the Six Disc CD Changer at the desired location in the trunk following the installation instructions
supplied with the CD Changer.
2. Carefully connect the 8-pin circular din connector from the CDC-FDC to the mating socket on the Six Disc
CD Changer.
3. Route the CDC-FDC cable toward the existing factory CD Changer connector on back of radio.
4. With the vehicle off, carefully connect the CDC-FDC male connector to the female CD Changer connector
on back of factory radio.

OPERATION CHECK:

1. Load CD's into the CD Changer cartridge and insert the cartridge into the changer.
2. Start vehicle and allow CD Changer to cycle.
Perform a brief functional test to verify proper operation according to the owner's manual.
CDC-FDC Installation Diagram (Fig. 1)
FACTORY RADIO REAR VIEW
CD CHANGER
DATA CONNECTOR
INSTALLATION GUIDE FOR:
for 1999–2000 FORD VEHICLES
8-PIN DIN
CONNECTOR
CDC-FDC
SERIAL NO.
Audiovox Corporation
Hauppauge, N.Y. 11788
Made in China
l © 1999 Audiovox Corporation, 150 Marcus Blvd., Hauppauge, N.Y. 11788 l
CD CHANGER
INTERFACE CABLE
DIGITAL AUDIO 6 DISC COMPACT DISC CHANGER
CDC-FDC
Form No. 128-5659
6 DISC CHANGER
SP-6CD
Printed in China
