2.2 Installing the ADF Output Paper Tray
1.
Hold the Output paper tray some 30 degrees as shown in
below.
2.
Insert the right protrusion of the Output Paper Tray into
the hole on the front of the scanner.
3. Insert the left pin of the Output Paper Tray slightly into the
hole on the front of the scanner.
Output
Paper Tray
2-3
Quick Guide
Scanner
Hole
Pin
