INSTALLATION AND OWNER GUIDE
Model 961
Inset live fuel effect gas fire
Incorporating the Wonderfire Premier
Fitted with one of the following fascia:
Bauhaus, Bloomsbury
Ebony.
(G.C. Number 32-032-88)
We trust that this guide gives
sufficient details to enable this
appliance to be installed and
maintained satisfactorily. However, if
further information is required, our
Wonderfire Premier Technical
Helpline will be pleased to help.
Telephone 0844 8711 554 (National
call rates apply in the United
Kingdom).
In the Republic of Ireland
Telephone 0044 844 8711 554.
INSTALLER: Please leave this guide with the owner
© Baxi Heating U.K. Limited 2010.
5137994/01
Control.
or
