Jazz
&
Jazz "Impact"
DECORATIVE LOG EFFECT ROOM HEATER
User Instructions
These instructions should be read by the user before operating the
appliance and retained for future reference
Model No. FJZL**RN is for use on Natural Gas (G20) at a supply pressure of
20 mbar in G.B. / I.E.
** Denotes trim & colour variant

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Jazz "Impact" and is the answer not in the manual?

Questions and answers

Related Manuals for Flavel Jazz "Impact"

Summary of Contents for Flavel Jazz "Impact"

  • Page 1 Jazz & Jazz “Impact” DECORATIVE LOG EFFECT ROOM HEATER User Instructions These instructions should be read by the user before operating the appliance and retained for future reference Model No. FJZL**RN is for use on Natural Gas (G20) at a supply pressure of 20 mbar in G.B.

  • Page 2: Installation Information

    INSTALLATION INFORMATION CONDITIONS OF INSTALLATION It is the law that all gas appliances are installed only by a competent (e.g. GAS SAFE Registered) Installer, in accordance with the installation instructions and the Gas Safety (Installation and Use) Regulations 1998 as amended. Failure to install appliances correctly could lead to prosecution.

  • Page 3: Important Safety Information

    ABOUT YOUR NEW JAZZ ROOM HEATER The Flavel Jazz decorative fuel effect room heater incorporates a unique and highly developed fuel bed which gives the realism of a loose log layout combined with realistic flames and glow. The use of durable hard ceramic material in the construction of the fuelbed components ensures long and trouble free operation.

  • Page 4: Operating The Fire

    In the event of repeated operation a GAS SAFE registered gas installer must be called to investigate and rectify the cause. The fuel bed remains hot for a considerable period after use and sufficient time should be allowed for the fire to cool before cleaning etc. The fire must only be operated with the trim as supplied, in position.
  • Page 5 Lighting the Main Burner (via the Remote Handset) With the pilot burner established it is possible to light the main burner and adjust the gas rate between high and low with the remote control handset. Press the “up” button to light the main burner and adjust the heat input to the maximum setting.

  • Page 6: Cleaning The Fuel Bed

    NOTE : THIS APPLIANCE IS DESIGNED TO WORK SAFELY AND EFFECTIVELY DURING ADVERSE WEATHER CONDITIONS. HOWEVER, DURING SUCH TIMES FLAME DISTURBANCE MAY BE NOTICED. THIS IS NORMAL AND DOES NOT EFFECT OR IMPAIR THE SAFETY OF THE APPLIANCE. CLEANING WARNING : Before attempting any cleaning operation ensure that the fire has been allowed to fully cool.

  • Page 7: Cleaning The Glass Panel

    CLEANING THE GLASS PANEL To clean the glass panel, first ensure that the fire is cool, please note that the glass panel will remain hot for a considerable period when the fire has been switched off. To remove the glass panel, follow the instructions below for removal and re-fitting.
  • Page 8 REMOVAL & RE-FITTING OF THE FUEL-BED LOGSET The gravel material should then be first layed around the base of the combustion chamber as shown below in Fig. 5, leaving the rear section as shown to allow the fitting of Log “A” Fig.
  • Page 9 Fit Log “B” into position on right hand side of the fuel-bed base log “A”as shown below in Fig. 7, using the groove in Log “B” as a guide for placement, and locate the in slot the fork of the log into the upturn in the base plate.
  • Page 10 Fit Log “D” into position on left hand side of the fuel-bed base log “A”as shown below in Fig. 9, using the groove in Log “A” as a guide for placement. Fig. 9 Slot in log to locate in the base plate upturn Fit Log “E”...

  • Page 11: Important Note

    IMPORTANT NOTE HAVING FITTED THE GRAVEL MATERIAL IN THE BASE OF THE COMBUSTION CHAMBER, ENSURE THAT NONE OF IT IS ON THE BURNER FLAME STRIP OR IN THE PILOT ASSEMBLY. IF MATERIAL IS OBSERVED VISUALLY ON THESE COMPONENTS, REMOVE THE FUEL-BED LOGSET, REMOVE THE GRAVEL MATERIAL FROM THE BURNER AND OR PILOT AND RE-FIT THE LOGS AS DETAILED IN ABOVE.
  • Page 12 REMOVAL & RE-FITTING OF THE JAZZ “IMPACT” FASCIA IMPORTANT NOTE : The trim assembly of this product is a working surface and as such will become hot in use. Allow the product and trim to fully cool prior to attempting to remove it. The Jazz “Impact”...
  • Page 13 REMOVAL & RE-FITTING OF THE JAZZ FASCIA IMPORTANT NOTE : The trim assembly of this product is a working surface and as such will become hot in use. Allow the product and trim to fully cool prior to attempting to remove it. The Jazz fascia is fitted to the product via hooking the fascia onto the mounting flange slots at the top.

  • Page 14: User-Replaceable Parts

    USER REPLACEABLE PARTS The only user replaceable parts on this fire are the fuelbed / log form, as descibed in pages 8 to 11 and the handset batteries, which may be replaced as described below. Replacement of any other parts must be carried out by a competent person such as a GAS SAFE registered gas installer.
